AXDIS-GM13
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 3/6/23 INSTAXDIS-GM13
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape
• Wire cutter • Zip-ties
TABLE OF CONTENTS
Connections .........................................................2-3
Installation .............................................................3
Adjusting the AXDIS-GM13.....................................3
Programming .........................................................4
Steering wheel control settings ........................5-7
- L.E.D. feedback ....................................................5
- Changing radio type ...........................................5
- Remapping ..........................................................6
- Dual assignment instructions ............................7
Troubleshooting .....................................................8
GM Data Interface with SWC 2005-2011
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Designed for amplified models
• Retains balance and fade
• Micro-B USB updatable
INTERFACE COMPONENTS
• AXDIS-GM13 interface
• AXDIS-GM13 harness
• 16-pin harness
• 3.5mm adapter
CADILLAC
STS ...............................................................2005-2011
APPLICATIONS
Visit AxxessInterfaces.com for up-to-date
vehicle specific applications.
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
Product Info
