CHRYSLER CAN BUS INTERFACE

1-800-221-0932

www.metraonline.com

CHTO-013

INSTALLATION INSTRUCTIONS

*IMPORTANT WARNING

THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION

WHICH MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS

ARE WORDED IN SUCH A MANNER TO ASSUME THAT THE

INSTALLER IS CAPABLE OF COMPLETING THESE TYPE OF

ELECTRONIC INSTALLATIONS. IF YOU ARE UNCLEAR AS TO

WHAT YOU ARE INSTRUCTED TO DO OR BELIEVE THAT YOU DO

NOT UNDERSTAND THE INSTRUCTIONS SO AS TO PROPERLY

AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD

CONSULT A TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE

AND UNDERSTANDING.

FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY

AND TO INSTALL THE INTERFACE AS DESCRIBED COULD

CAUSE HARM TO THE VEHICLE OR TO SAFETY SYSTEMS

ON THE VEHICLE. INTERFERENCE WITH CERTAIN SAFETY

SYSTEMS COULD CAUSE HARM TO PERSONS AS WELL.

IF YOU HAVE ANY QUESTIONS IN THIS REGARD PLEASE

CALL THE HELP LINE OR THE METRA AT 1-800-221-0932

FOR ASSISTANCE.

CHTO-013 CHTO-013

* READ IMPORTANT WARNING INSIDE

BEFORE ATTEMPTING ANY INSTALLATION

THE CHTO-013 IS DESIGNED TO BE USED WITH

VEHICLES THAT HAVE A FACTORY AMPLIFIED

SYSTEM. THE CHTO-013 WILL PROVIDE A 12-VOLT

SWITCHED WIRE FOR PROPER RADIO OPERATION.

THE CHTO-013 NOW PROVIDES MUTE, PARKING

BRAKE, VSS OR SPEED SENSE, AND A REVERSE

OUTPUT TO MAKE INSTALLING AN AFTERMARKET

NAVIGATIONAL RADIO SIMPLER AND LESS TIME

COMSUMING.

Cutting Tool • Tape • Crimping Tool • Connectors

TOOLS REQUIRED FOR INSTALLATION

When using the CHTO-013 with a radio that has a high audio

pre-out voltage, usually greater than 2 volts, the audio signal

may become distorted. To resolve this follow these steps:

1. Make sure the ignition is turned to the “off” position.

2. Disconnect both of the harnesses from the CHTO-013.

3. Locate the potentiometer next to the 14-pin connector at

the end of the CHTO-013.

4. Taking a small flat headed screwdriver, turn the

potentiometer counter-clockwise to lower the input

level going to the factory amplifier.

5. After making the adjustment reconnect the wire harnesses.

REV. 03-17-11 INSTCHTO-013

POTENTIOMETER

AUDIO LEVEL

ADJUSTMENT

INTERFACE COMPONENTS

• CHTO-013 • 14-PIN HARNESS WITH RCA’S

• (2) 12-PIN HARNESSES TO 22-PIN CHRYSLER HARNESSES

AUDIO LEVEL CONTROL

CONNECTIONS TO BE MADE ON THE

14-PIN HARNESS

1. Connect the blue/white wire to the radio’s amplifier turn-on wire.

2. Connect the red wire to the radio’s Igniton or accessory wire.

3. Connect the RCA cables to the radio’s RCA outputs. If no RCA

outputs are available, use the Metra line output converter, part #

ALOC648, (SOLD SEPARATELY).

4. The white RCA goes to the left front RCA output of the radio.

5. The gray RCA goes to the right front RCA output of the radio.

6. The green RCA goes to the left rear RCA output of the radio.

7. The purple RCA goes to the right rear RCA output of the radio.

The following wires on the 14-pin harness are for the

aftermarket radios that have navigation built in:

Connect the brown wire to the mute wire of the aftermarket radio.

Connect the green wire to the parking brake wire of the

aftermarket radio.

Connect the blue/pink wire to the VSS or speed sense wire of the

aftermarket `radio.

Connect the green/purple wire to the reverse wire of the

aftermarket radio.

When completed, plug the 14-pin harness into the CHTO-013.

INSTALLING THE CHTO-013

1. With all connections completed to the aftermarket radio, plug the

22-pin connector into the vehicle’s corresponding wiring harnesses.

2. Cycle the key by turning the ignition on then back off, then back on

again to test the radio.

TESTING THE CHTO-013

1. Turn the ignition on then the radio to verify the radio works. Check

balance and fader controls for proper operation. If controls are

backwards, check to see if the RCA’s are in the correct location.

CHTO-013

WIRING UP THE CHTO-013

* Important: Before beginning any of the following, disconnect the

negative battery terminal to prevent accidental short circuit.

* NOTE: THE ACCESSORY POWER SOURCE OF MOST ALL

CHRYLSER VEHICLES KEEPS THE RADIO ON UNTIL ONE OF

THE DOORS IS OPENED. THIS IS CALLED R.A.P. (RETAINED

ACCESSORY POWER). THE CHTO-013 IS DESIGNED TO RETAIN

THIS FEATURE.

* NOTE: THE VEHICLES IGNITION SWITCH MUST BE IN THE OFF

POSITION BEFORE PLUGGING THE CHTO-013 MODULE IN.

ALSO THE KEY MUST BE CYCLED AT A MEDIUM PACE AT

LEAST TWO TIMES BEFORE BEGINNING TESTING.

CONNECTIONS TO BE MADE ON THE

22-PIN HARNESS:

1. Connect the yellow wire to the radio’s 12v battery or memory wire.

2. Connect the black wire to the radio’s ground wire.

3. Connect the orange wire to the radio’s illumination wire. If wire is

not present, tape up wire.

4. For the Caliber only, connect the blue/white wire to the

blue/white wire in the 14-pin harness, which connects to the

radio’s amplifier turn-on wire.

APPLICATIONS

* NOTE: THE CHTO-013 COMES WITH 2 DIFERENT CHRYSLER 22-PIN HARNESSES. THE

APPLICATIONS WITH A (*) USE THE BIGGER OF THE TWO HARNESSES. THE BIGGER OF.

THE TWO HARNESSES ALSO HAVE 2 LARGER TERMINALS, ONE AT EACH END OF

THE CONNECTOR.

Metra recommends MECP

certified technicians.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics sch ol in our industry.o

Log onto www.installerinstitute.com or ca l l

800-354-6782 for more information and take steps

towa a better tomorrord w.

CHRYSLER

300 2008-UP*

ASPEN 2008-09*

SEBRING 2007-10*

TOWN & COUNTRY 2008-UP*

DODGE

AVENGER 2008-UP*

CALIBER 2007-08 and 09-UP*

CHALLENGER 2009-UP*

CHARGER 2008-10*

DAKOTA 2008-UP*

DURANGO 2008-UP*

GRAND CARAVAN 2008*

JOURNEY 2009-UP*

MAGNUM 2008-09*

DODGE (cont.)

NITRO 2007-UP*

RAM 1500 2009-UP*

RAM 2500/3500 2010-UP*

JEEP

COMMANDER 2006-2007

and 08-10*

COMPASS 2007-08 and 09-UP*

GRAND CHEROKEE 2005-2007

and 08-UP*

PATRIOT 2007-08 and 09-UP*

WRANGLER 2007-UP*

MITSUBISHI

RAIDER 2006-07 and 08-09*
