Installation instructions for part GMOS-LAN-04

REV. 4/4/2017 INSTGMOS-LAN-04

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Pre-wired ASWC-1 harness (ASWC-1 sold

separately)

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• USB-CAB (sold separately) updatable

05;,9-(*,-,(;<9,:

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

;663:9,8<09,+

GMOS-LAN-04

GM Data Interface

2006-2012

(7730*(;065:

• GMOS-LAN-04 interface • GMOS-LAN-04 harness

• 16-pin harness with stripped leads

05;,9-(*,*64765,5;:

Connections to be made .........................................2

Installing the GMOS-LAN-04 ..................................3

Initializing the GMOS-LAN-04 ................................3

Adjusting the GMOS-LAN-04 ..................................3

Table of Contents

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G6 2010

G6 (5th digit of VIN must

be a J, K, or L) 2009

G5 2007-2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2007-2009

GMOS-LAN-04

Connections to be made

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the Red wire to the accessory wire.

Note: If installing an ASWC-1 (sold separately), there will be an accessory wire

there to connect as well.

• Connect the Blue/White wire to the amp turn on wire. This wire must be

connected to hear sound from the factory amplifier.

•

If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative output.

The following (3) wires are only for multimedia/navigation radios that require these wires

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

From the GMOS-LAN-04 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

Note: The relay attached to the GMOS-LAN-04 harness is only for audible turn signal

clicks. No extra steps are required to retain this feature, so leave the relay as-is

12-pin pre-wired ASWC-1 harness:

•

This harness is to be used along with the optional ASWC-1 (not included) to retain steering

wheel audio controls. If the ASWC-1 is not being used, disregard this harness. If it will be

used, please refer to the ASWC-1 instructions for radio connections and programming.

Note: Disregard the harness that comes with the ASWC-1.

• Connect the Red wire to the accessory wire.

• The following wire must be cut before programming the ASWC-1:

•

CHEVROLET

HHR 2006-2009

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 2010

G6 (5th digit of VIN must

be a J, K, or L) 2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009
