Installation instructions for part LC-GMRC-LAN-01

REV. 8/2/2016 INSTLC-GMRC-LAN-01

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

• Provides NAV outputs (parking

brake, reverse, and speed sense)

• Used in non-amplified models,

or when bypassing a factory

amplifier

•

Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

-,(;<9,:

• Wire cutter • Crimping tool • Tape • Solder gun

• Connectors (butt-connectors, bell caps, etc.)

;663:9,8<09,+

LC-GMRC-LAN-01

• LC-GMRC-LAN-01 interface

• LC-GMRC-LAN-01 harness

05;,9-(*,*64765,5;:

*Only for models without factory navigation.

Note: This interface will not retain OnStar.

Connections to be made ........................................ 2

Installing the Axxess Interface ............................. 3

Initializing the Axxess Interface ........................... 3

Table of Contents

(7730*(;065:

BUICK

Enclave 2008-up

Lucerne 2006-2011

CADILLAC

DTS 2006-2011

Escalade 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche 2007-2011

Avalanche 2012-2013*

Captiva Sport 2012-2015*

Equinox 2007-2009

Express 2008-2010

Express 2011-up*

Impala 2006-2013

Impala Limited 2014-2016

Monte Carlo 2006-2007

Silverado 2007-2011

Silverado 2012-2013*

Silverado 2500/3500 2014*

Suburban 2012-2014*

Suburban 2007-2011

Tahoe 2007-2011

Tahoe 2012-2014*

Traverse 2009-up

GMC

Acadia 2007-2016

Acadia Limited 2017-up

Savana 2008-2010

Savana 2011-up*

Sierra 2007-2011

Sierra 2012-2013*

Sierra 2500/3500 2014*

Yukon/Yukon XL 2007-2011

Yukon/Yukon XL 2012-2013*

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

VUE 2008-2010

SUZUKI

XL-7 2007-2009

LC-GMRC-LAN-01

From the LC-GMRC-LAN-01 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• Connect the Blue wire to the power antenna wire.

• If the aftermarket radio has an illumination wire, connect the Orange wire to it.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these

wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

Connections to be made
