INSTALLATION INSTRUCTIONS FOR PART RFASWC
METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
REV. 7/8/2014 INSTRFASWC
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• Designedtobecompatiblewithmostmajorradiobrands
• Autodetectsradiobeingconnected,andpresetscontrols
• Abilitytodualassignsteeringwheelcontrolbuttons
• Retainssettingsevenafterthebatteryhasbeendisconnected
FEATURES
•Cuttingtool•Crimpingtool•Tape•Connectors
(example:butt-connectors,bellcaps,etc.)
TOOLS REQUIRED
Wireless SWC universal add-on
RFASWC
•A)RFASWCTransmitter•B)RFASWCinterface•C)Keypad•D)Trimring•E)RFASWCharness
•F)Female3.5mmconnectorwithBrownandBrown/Whitewires•G)12k-ohmResistor(notshown)
INTERFACE COMPONENTS
A B C D
E F
US.PAT.NOS.8014920and8214105
RFASWC
2
Table of Contents
What you need to know before you begin
1) Besurethattheradioyouareinstallingissteeringwheelcontrolcompatible.
Additionally,refertotheRadioLegendandyourradio’sinstallationmanual.
2) UpdatetheRFASWCtothelatestsoftware.
Note: To update the RFASWC, go to axxessinterfaces.com and download the
WebXXpress Updater.
Preface
Preface..................................................................................................................2
Overview
– IntroductiontotheRFASWCInterfaceandWiringHarness...................................2
– MountingtheRFASWCTransmitter......................................................................3
RFASWC Installation
–ConnectionstobeMade......................................................................................4
SettinguptheRFASWC...................................................................................5
–Programming......................................................................................................5
–RemappingtheSWC(steeringwheelcontrol)Buttons......................................... 5-6
ButtonAssignmentLegend.............................................................................6
–ChangingRadioType....................................................................................... 6-7
RadioLegend.................................................................................................7
– DualAssignment............................................................................................. 7-8
DualAssignmentLegend................................................................................8
RFASWC Troubleshooting
................................................................................. 8-9
–LEDFeedback.....................................................................................................9
Caution: Metra recommends disconnecting the negative battery terminal before
beginning any installation. All accessories, switches, and especially air bag indicator
lights must be plugged in before reconnecting the battery or cycling the ignition.
Introduction to the RFASWC Interface and Wiring Harness
OntopoftheRFASWCinterfacetherearethreepointsofinterest:
•1)ProgrammingLED•2)Resetbutton•3)Updateportcover (slide to open)
Overview
UpdatePortCover ResetButton ProgrammingLED
USB-CAB
