INSTXSVI-6502-NAV

1-800-221-0932 metraonline.com

REV. 4/15/14

XSVI-6502-NAV

2004-2010 Chrysler accessory and NAV output CAN harness

• Providesaccessory(12volt10amp)

• RetainsR.A.P.(retainedaccessorypower)

• Usedinnon-amplifiedsystems,orwhenreplacingamplifiedsystem

• Provides outputs(parkingbrake,reverse,andV.S.S.)NAV

• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)

• Highlevelspeakerinput

• USBupdatable

CHRYSLER

300 2005-2007

Aspen 2007

PT Cruiser 2006-2010 

DODGE

Caliber 2007-2008

Charger 2006-2007

Dakota 2005-2007

Durango 2004-2007

Magnum 2005-2007

Ram 1500 2006-2008 

Ram 2500/3500 2006-2009 

JEEP

Commander 2006-2007

Compass 2007-2008

Grand Cherokee 2005-2007 

Patriot 2007-2008

MITSUBISHI

Raider 2006-2007

APPLICATIONS

WIRING THE XSVI-6502-NAV

• Connect the Yellowwire to the radio’s 12 volt battery or memory wire.        

• Connect the wire to the radio’s ground wire. Black     

• Connect the wire to the ignition wire of the aftermarket radio. Red        

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange           

aftermarket radio has no illumination wire, tape off the wire.        Orange

• Connect the wire to the antenna turn on wire of the aftermarket radio. Blue          

• Connect the wire to the White   left front positive speaker output of     the aftermarket radio. 

INSTXSVI-6502-NAV

1-800-221-0932 metraonline.com

REV. 4/15/14

• Connect the wire to the left front negative speaker output of White/Black         

the aftermarket radio. 

• Connect the wire to the right front positive speaker output of the Gray          

aftermarket radio.

• Connect the wire to the right front negative speaker output of the Gray/Black           

aftermarket radio.

• Connect the wire to the radio’s left rear positive speaker output. Green        

• Connect the wire to the radio’s left rear negative speaker output. Green/Black        

• Connect the wire to the radio’s right rear positive speaker output. Purple        

• Connect the wire to the radio’s right rear negative speaker output. Purple/Black        

The following wires are for the aftermarket radios that have navigation built in.           

• Connect the wire to the parking brake wire of the aftermarket  Light Green         

navigation radio (if applicable).  

• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink           

navigation radio (if applicable).  

• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple         

radio (if applicable). 

• Cycle the key, by turning the ignition on for 30 seconds.          Then off and on again to test      

the radio.

ASWC-1 (if installing)

After the XSVI is initialized, plug in the ASWC-1 into the 12-pin harness of the              

XSVI-6502-NAV and refer to the ASWC-1 instructions.     

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

K PNOWLEDGE IS OWER

Enhance your installation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians
