Side 1/90

 2014-2020 Microchip Technology Inc. DS20005347C-page 1

MCP3919

Features:

• Three Synchronous Sampling 24-Bit Resolution

Delta-Sigma A/D Converters

• 93.5 dB SINAD, -107 dBc Total Harmonic

Distortion (THD) (up to 35

Harmonic), 112 dBFS

SFDR for Each Channel

• Enables 0.1% Typical Active Power Measurement

Error Over a 10,000:1 Dynamic Range

• Advanced Security Features:

- 16-Bit Cyclic Redundancy Check (CRC)

Checksum on All Communications for Secure

Data Transfers

- 16-Bit CRC Checksum and Interrupt Alert for

- Register Map Lock with 8-Bit Secure Key

• 2.7V-3.6V AV

, DV

• Programmable Data Rate Up to 125 ksps:

- 4 MHz Maximum Sampling Frequency

- 16 MHz Maximum Master Clock

• Oversampling Ratio Up to 4096

• Ultra Low-Power Shutdown Mode with < 10 µA

• -122 dB Crosstalk Between Channels

• Low-Drift 1.2V Internal Voltage Reference:

9 ppm/°C

• Differential Voltage Reference Input Pins

• High-Gain PGA on Each Channel (up to 32 V/V)

• Phase Delay Compensation with 1 µs Time

Resolution

• Separate Data Ready Pin for Easy

Synchronization

• Individual 24-Bit Digital Offset and Gain Error

Correction for Each Channel

• High-Speed 20 MHz SPI Interface with Mode 0,0

and 1,1 Compatibility

• Continuous Read/Write Modes for Minimum

Communication Time with Dedicated 16/32-Bit

Modes

• Available in a 28-Lead 5 x 5 mm QFN and

28-Lead SSOP Packages

• Extended Temperature Range: -40°C to +125°C

Description:

The MCP3919 is a 3V three-channel Analog Front End

(AFE) containing three synchronous sampling Delta-

Sigma Analog-to-Digital Converters (ADC), three PGAs,

phase delay compensation block, low-drift internal volt-

age reference, Digital Offset and Gain Error Calibration

registers, and high-speed 20 MHz SPI-compatible serial

interface.

The MCP3919 ADCs are fully configurable with

features, such as: 16/24-bit resolution, Oversampling

Ratio (OSR) from 32 to 4096, gain from 1x to 32x,

independent shutdown and Reset, dithering and auto-

zeroing. The communication is largely simplified with

8-bit commands, including various continuous Read/

Write modes and 16/24/32-bit data formats that can be

accessed by the Direct Memory Access (DMA) of an 8,

16 or 32-bit MCU. A separate Data Ready pin is also

included that can directly be connected to an Interrupt

Request (IRQ) input of an MCU.

The MCP3919 includes advanced security features to

secure the communications and the configuration

settings, such as a CRC-16 checksum on both serial

data outputs and static register map configuration. It

also includes a register map lock through an 8-bit

secure key to stop unwanted WRITE commands from

processing.

The MCP3919 is capable of interfacing with a variety of

voltage and current sensors, including shunts, Current

Transformers (CTs), Rogowski coils and Hall effect

sensors.

Applications:

• Polyphase Energy Meters

• Energy Metering and Power Measurement

• Automotive

• Portable Instrumentation

• Medical and Power Monitoring

• Audio/Voice Recognition

3V Three-Channel Analog Front End
