Side 1/102

Data Sheet

DS00003831E - 1

Overview

This datasheet covers the electrical AC and DC specications for four temperature grades of devices (part

number prexes MPF050, MPF100, MPF200, MPF300, and MPF500). AC and DC electrical characteristics and

parametric values, unless otherwise noted, apply to all temperature grade devices. For example, worst-case

STD speed grade applies to all temperature grade devices and –1 speed grade applies to all temperature grade

devices except Military. In addition, Low-Power (L) devices are equivalent in performance to STD speed grade

devices where oered. Users are expected to close timing using SmartTime for the speed and temperate grade

of the device chosen.

Table 1. PolarFire Minimum and Maximum Juncon Temperatures by Temperature Grade

Temperature Grade Minimum Junction Temperature Maximum Junction Temperature

Extended Commercial (E) 0 °C 100 °C

Industrial (I) –40 °C 100 °C

Automotive AECQ-100 (T2) –40 °C 125 °C

Military (M) –55 °C 125 °C

Table 2. PolarFire Speed Grade Opons by Temperature Grade

Temperature Grade Standard Speed Grade –1 Speed Grade

Extended Commercial (E) Available Available

Industrial (I) Available Available

Automotive T2 (T2) Available Available

Military (M) Available Not Available

Table 3. PolarFire Package Ball Composion by Temperature Grade

Temperature Grade Ball Material Composition Package Decoupling Capacitor Solder Paste (FC484, FC784, FC1152)

Extended Commercial (E) RoHS RoHS

Industrial (I) RoHS RoHS

Automotive T2 (T2) RoHS RoHS

Military (M) Lead, Tin Lead, Tin

PolarFire device programming functions (programming, verify, and digest check) are only allowed over

the Industrial temperature range regardless of the temperature grade of the device selected. Retention

characteristics for each temperature range explicitly describe the retention characteristics for that temperature-

grade device. You cannot, for example, use the retention characteristics at 110 °C and apply them to the

Extended Commercial or Industrial devices with a maximum T

of 100 °C. Retention characteristics for Military-

grade devices and Automotive-grade devices at the absolute maximum junction temperature of 125 °C can

be proled using the PolarFire Retention Calculator, which can be obtained by contacting technical support at

microchip.com/support.

PolarFire

FPGA

Data Sheet

DS00003831E - 2

Table of Contents

Overview................................................................................................................................................................................ 1

1. References......................................................................................................................................................................3

2. Device Oering.............................................................................................................................................................. 4

3. Silicon and Libero

Tool Status.................................................................................................................................... 5

4. DC Characteristics......................................................................................................................................................... 7

4.1. Absolute Maximum Rating................................................................................................................................7

4.2. Recommended Operating Conditions.............................................................................................................7

4.3. Input and Output............................................................................................................................................. 15

5. AC Switching Characteristics...................................................................................................................................... 24

5.1. I/O Standards Specications...........................................................................................................................24

5.2. Clocking Specications.................................................................................................................................... 38

5.3. Fabric Specications........................................................................................................................................ 49

5.4. Transceiver Switching Characteristics........................................................................................................... 52

5.5. Transceiver Protocol Characteristics............................................................................................................. 64

5.6. Non-Volatile Characteristics........................................................................................................................... 71

5.7. System Services................................................................................................................................................78

5.8. Fabric Macros................................................................................................................................................... 79

5.9. Power-Up to Functional Timing......................................................................................................................83

5.10. Dedicated Pins..................................................................................................................................................87

5.11. User Crypto.......................................................................................................................................................89

6. Revision History...........................................................................................................................................................94

Microchip Information....................................................................................................................................................... 99

The Microchip Website............................................................................................................................................... 99

Product Change Notication Service........................................................................................................................ 99

Customer Support.......................................................................................................................................................99

Microchip Devices Code Protection Feature............................................................................................................ 99

Legal Notice..................................................................................................................................................................99

Trademarks................................................................................................................................................................ 100

Quality Management System.................................................................................................................................. 101

Worldwide Sales and Service...................................................................................................................................102
