Cat. No. / No de cat.

2257-20

102 X 77 SPOT INFRARED IMAGER

102 X 77 INSTRUMENT D’IMAGERIE DE POINTS CHAUDS À

INFRAROUGE

REPRODUCTOR DE IMÁGENES INFRARROJO DE

IMAGEN ÚNICA DE 102 X 77

OPERATOR'S MANUAL

MANUEL de L'UTILISATEUR

MANUAL del OPERADOR

WARNING To reduce the risk of injury, user must read and understand operator's manual.

AVERTISSEMENT An de réduire le risque de blessures, l'utilisateur doit lire et bien

comprendre le manuel.

ADVERTENCIA Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual.

IMPORTANT SAFETY

INSTRUCTIONS

WARNING

READ ALL SAFETY WARNINGS

AND INSTRUCTIONS. Failure to

follow the warnings and instructions may result

in electric shock, re and/or serious injury. Save

these instructions - This operator’s manual con-

tains important safety and operating instructions

for the MILWAUKEE Visual Infrared Imager. Be-

fore using the Visual Infrared Imager, read this

operator’s manual and all labels on the Visual

Infrared Imager.

WORK AREA SAFETY

• Keep children and bystanders away while oper-

ating imager. Store idle imager out of the reach

of children and do not allow persons unfamiliar

with the tool or these instructions to operate

them.

• Avoid dangerous environments. Do not use in

rain, snow, damp or wet locations. Do not use in the

presence of explosive atmospheres (gaseous fumes,

dust or ammable materials) because sparks may

be generated when inserting or removing batteries,

possibly causing re.

PERSONAL SAFETY

• Stay alert, watch what you are doing and use

common sense when operating imager. Do not

use a power tool while you are tired or under

the inuence of drugs, alcohol or medication. A

moment of inattention while operating power tools

may result in serious personal injury.

• Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

BATTERY TOOL USE AND CARE

• This tool is designed to be powered by one (1)

9V battery properly inserted into the imager. Do

not attempt to use with any other voltage or power

supply.

•Do not leave battery within the reach of children.

• Install battery according to polarity (+ / –)

diagrams.

• Properly dispose of used batteries immediately.

•Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact ac-

cidentally occurs, ush with water. If liquid con-

tacts eyes, additionally seek medical help. Liquid

ejected from the battery may cause irritation or burns.

SERVICE

• Have your imager serviced by a qualied repair

person using only identical replacement parts.

This will ensure that the safety of the power tool is

maintained.

• Do not disassemble. Incorrect reassembly may

result in the risk of electric shock or re. If it is dam-

aged, take it to a MILWAUKEE service facility.

• Store in a cool, dry place. Do not store where

temperatures may exceed 140°F (60°C) such as

in direct sunlight, a vehicle or metal building during

the summer.

• Do not remove or deface labels. Maintain

labels and nameplates. These carry important

information. If unreadable or missing, contact a

MILWAUKEE service facility for a free replacement.

Federal Communications Commission

WARNING

Changes or modications to this unit

not expressly approved by the party

responsible for compliance could void the user’s

authority to operate the equipment.

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful in-

terference in a residential installation. This equipment

generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance

with the instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or televi-

sion reception, which can be determined by turning

the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Consult the dealer or an experienced radio/TV technician

for help.

SPECIFICATIONS

Cat. No. 2257-20 .....................................................

Voltage 9 DC............................................................

Temperature Measurement

Infrared (IR) Resolution ...................102 x 77 pixels

(Picture Elements or Data Points)

Object Temperature Range 2 ............14°F to 626°F

(-10°C to 330°C)

Thermal Sensitivity ..................... 0.1°C/25°C NETD

(Noise Equivalent Temperature Difference)

Spatial Resolution............................3.0 mrad IFOV

(Instantaneous Field of View)

Accuracy ................................ ±5°C or 5% @ 25°C,

whichever is greater

Emissivity 0.95 .........................................................

Infrared (IR) Detector Type .......................Uncooled

Microbolometer focal-plane array (FPA)

Spectral Range ................................... 7.5 to 14 μm

Distance to Spot Radio 56 to 1" ...............................

Thermal Imaging

Field of View (FOV) ......26.8° (Horiz.) X 35.4°(Vert)

Focus Method ......................................Fixed Focus

Minimum Distance in Focus .............36" (91.4 mm)

Thermal frame rate ............................................. 8 Hz

Physical and Environmental

Drop Test .........................6' (2 m) Drop to concrete

Operating Temperature Range ..........14°F to 122°F

(-10°C to 50°C)

Operating Storage Humidity Range......... 10%-90%

Non-condensing

General

Display ..........................Color TFT-LCD 1.8" (4.6 cm)

measured diagonally

NOTE: Displayed readings < -10°C and > 330°C

are not specied.
