ELECTRIC CHAIN HOIST

OPERATING, MAINTENANCE

& PARTS MANUAL

Before installing hoist, ﬁll in the information below.

Model Number.

Serial No.

Purchase Date

Please provide Serial Number when ordering parts.

Follow all instructions and warnings for inspecting,

maintaining and operating this hoist.

The use of any hoist presents some risk of personal injury

or property damage. That risk is greatly increased if proper

instructions and warnings are not followed. Before using

this hoist, each operator should become thoroughly familiar

with all warnings, instructions and recommendations in this

manual. Retain this manual for future reference and use.

Forward this manual to hoist operator. Failure to operate

equipment as directed in the manual may cause injury.

Assembled in USA with Imported and Domestic Components

MJC680-2 Rev AA April 2019

CATALOG NO:

9560

9561

9562

9565

9566

9567

9568

9570

9571

9572

9573

RATED LOAD:

1/2 TON

1 TON

2 TON

MJC680-2 Rev AA April 2019

Improper operation of a hoist can create a potentially

hazardous situation which, if not avoided, could result in

death, or serious injury. To avoid such a potentially hazardous

situation, THE OPERATOR SHALL:

1. NOT operate a damaged, malfunctioning or unusually

performing hoist.

2. NOT operate the hoist until you have thoroughly read and

understood tmanufacturer’s Operating and Maintenance

Instructions or Manuals.

3. NOT operate a hoist which has been modied without the

manufacturer’s approval or without certication that it is in

conformity with ANSI/ASME B30 volumes.

4. NOT lift more than rated load for the hoist.

5. NOT use hoist with twisted, kinked, damaged,

or worn load chain.

6. NOT use the hoist to lift, support, or transport people.

7. NOT lift loads over people..

8. NOT operate a hoist unless all persons are and remain

clear of the supported load.

9. NOT operate unless load is centered under hoist.

10. NOT attempt to lengthen the load chain or repair damaged

load chain.

11. Protect the hoists load chain from weld splatter or other

damaging contaminants.

12. NOT operate a hoist when it is restricted from forming a

straight line from hook to hook in the direction of loading.

13. NOT use load chain as a sling or wrap load chain around load.

14. NOT apply the load to the tip of the hook or to the hook latch.

15. NOT apply load unless load chain is properly seated in the

chain sprocket(s).

16. NOT apply load if bearing prevents equal loading on all load

supporting chains.

17. NOT operate beyond the limits of the load chain travel.

18. NOT leave load supported by the hoist unattended unless

specic precautions have been taken.

19. NOT allow the chain or hook to be used as an electrical or

welding ground.

20. NOT allow the chain or hook to be touched by a live

welding electrode.

21. NOT remove or obscure the warnings on the hoist.

22. NOT operate a hoist on which the safety placards or decals

are missing or illegible.

23. NOT operate a hoist unless it has been securely attached to

a suitable support.

24. NOT operate a hoist unless load slings or other approved

single attachments are properly sized and seated in the

hook saddle.

25. Take up slack carefully - make sure load is balanced and

load holding action is secure before continuing.

26. Shut down a hoist that malfunctions or performs unusually

and report such malfunction.

27. Make sure hoist limit switches function properly.

28. Warn personnel of an approaching load.

Improper operation of a hoist can create a potentially

hazardous situation which, if not avoided, could result

in minor or moderate injury. To avoid such a potentially

hazardous situation, THE OPERATOR SHALL:

1. Maintain a rm footing or be otherwise secured when

operating the hoist.

2. Check brake function by tensioning the hoist prior

to each lift operation.

3. Use hook latches. Latches are to retain slings, chains, etc.

under slack conditions only.

4. Make sure the hook latches are closed and not supporting

any parts of the load.

5. Make sure the load is free to move and will clear all

obstructions.

6. Avoid swinging the load or hook.

7. Make sure hook travel is in the same direction as shown

on the controls.

8. Inspect the hoist regularly, replace damaged or worn parts,

and keep appropriate records of maintenance

9. Use Milwaukee Tool recommended parts when repairing

the unit.

10. Lubricate load chain per hoist recommendations.

11. NOT use the hoist’s overload limiting clutch to measure load.

12. NOT use limit switches as routine operating stops. They are

emergency devices only..

13. NOT allow your attention to be diverted from operating

the hoist.

14. NOT allow the hoist to be subjected to sharp contact with

other hoists, structures, or objects through misuse.

15. NOT adjust or repair the hoist unless qualied to perform

such adjustments or repairs.

SAFETY PRECAUTIONS

Each Milwaukee Tool Electric Chain Hoist is built in accordance

with the specications contained herein and at the time of

manufacture complies with our interpretation of applicable

sections of *American Society of Mechanical Engineers Code

(ASME) B30.16 “Overhead Hoists,” the National Electrical Code

(ANSI/NFPA 70) and the Occupational Safety and Health Act

(OSHA). Since OSHA states the National Electrical Code applies to

all electric hoists, installers are required to provide current overload

protection and grounding on the branch circuit section in keeping

with the code. Check each installation for compliance with the

application, operation and maintenance sections of these articles.

*Copies of this standard can be obtained from

ASME Order Department, 22 Law Drive, PO Box 2300,

Faireld, NJ 07007- 2300, U.S.A., www.asme.org, 800-843-2763.
