SPLIT-TYPE AIR CONDITIONERS

INDOOR UNIT

MSZ-FH25VE MSZ-FH35VE MSZ-FH50VE

Русский

Türkçe

Svenska

Dansk

Português

Ελληνικά

Italiano

Español

Nederlands

Français

Deutsch

English

OPERATING INSTRUCTIONS For user

• To use this unit correctly and safely, be sure to read these operating in-

structions before use.

ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ Для пользователя

• В целях правильной и безопасной эксплуатации данного устройс-

тва обязательно перед его использованием прочтите настоящее

руководство по эксплуатации.

ÇALIŞTIRMA TALİMATLARI Kullanıcı için

• Bu üniteyi doğru ve güvenli bir biçimde kullanmak için, kullanmadan

önce bu işletim talimatlarını okuduğunuzdan emin olun.

BRUKSANVISNING För användaren

• Läs bruksanvisningen innan enheten tas i bruk så att den används sä-

kert och på rätt sätt.

BETJENINGSVEJLEDNING Til kunden

• Læs denne betjeningsvejledningen før brug, så enheden bruges korrekt

og sikkert.

INSTRUÇÕES DE OPERAÇÃO Para o utilizador

• Para utilizar esta unidade correctamente e com segurança, certi que-

se de que lê estas instruções de operação antes da utilização.

ΟΔΗΓΙΕΣ ΛΕΙΤΟΥΡΓΙΑΣ Για το χρήστη

• Για να χρησιμοποιήσετε αυτή τη μονάδα σωστά και με ασφάλεια, βεβαι-

ωθείτε ότι έχετε διαβάσει αυτό το εγχειρίδιο οδηγιών πριν από τη χρή-

ση.

LIBRETTO D’ISTRUZIONI Per gli utenti

• Per utilizzare correttamente ed in tutta sicurezza questo apparecchio,

leggere il presente libretto d’istruzioni prima dell’uso.

MANUAL DE INSTRUCCIONES Para los clientes

• Para utilizar esta unidad de forma correcta y segura, lea previamente

estas instrucciones de funcionamiento.

BEDIENINGSINSTRUCTIES Voor de klant

• Om dit apparaat correct en veilig te kunnen gebruiken moet u deze be-

dieningsinstructies voor gebruik eerst doorlezen.

NOTICE D’UTILISATION A l’attention des clients

• Pour avoir la certitude d’utiliser cet appareil correctement et en toute

sécurité, veuillez lire cette notice d’instructions avant de mettre le clima-

tiseur sous tension.

BEDIENUNGSANLEITUNG For den Anwender

• Für einen sicheren und ordnungsgemäßen Gebrauch des Geräts unbe-

dingt diese Bedienungsanleitung vor der Inbetriebnahme durchlesen.

English is original.

Übersetzung des

Originals

Traduction du texte

d’origine

Vertaling van het

origineel

Traducción del

original

Traduzione

dell’originale

Μετάφραση του

αρχικού

Tradução do

original

Oversættelse af

den originale tekst

Översättning från

originalet

Orijinalin çevirisi

Перевод

оригинала

En-1

● OPERATING INSTRUCTIONS ●

WARNING

Do not connect the power cord to an intermediate point, use

an extension cord, or connect multiple devices to a single

AC outlet.

• This may cause overheating, ﬁ re, or electric shock.

Make sure the power plug is free of dirt and insert it securely

into the outlet.

• A dirty plug may cause ﬁ re or electric shock.

Do not bundle, pull, damage, or modify the power cord, and do

not apply heat or place heavy objects on it.

• This may cause ﬁ re or electric shock.

Do not turn the breaker OFF/ON or disconnect/connect the

power plug during operation.

• This may create sparks, which can cause ﬁ re.

• After the indoor unit is switched OFF with the remote controller,

make sure to turn the breaker OFF or disconnect the power

plug.

Do not expose your body directly to cool air for a prolonged

length of time.

• This could be detrimental to your health.

The unit should not be installed, relocated, disassembled,

altered, or repaired by the user.

• An improperly handled air conditioner may cause ﬁ re, electric

shock, injury, or water leakage, etc. Consult your dealer.

• If the power supply cord is damaged, it must be replaced by the

manufacturer or its service agent in order to avoid a hazard.

When installing, relocating, or servicing the unit, make sure

that no substance other than the speciﬁ ed refrigerant (R410A)

enters the refrigerant circuit.

• Any presence of foreign substance such as air can cause abnor-

mal pressure rise and may result in explosion or injury.

• The use of any refrigerant other than that speciﬁ ed for the system

will cause mechanical failure, system malfunction, or unit break-

down. In the worst case, this could lead to a serious impediment

to securing product safety.

• Since rotating parts and parts which could cause an electric shock are used

in this product, be sure to read these “Safety Precautions” before use.

• Since the cautionary items shown here are important for safety, be sure to

observe them.

• After reading this manual, keep it together with the installation manual in a

handy place for easy reference.

Marks and their meanings

WARNING : Incorrect handling could cause serious hazard, such as

death, serious injury, etc. with a high probability.

CAUTION : Incorrect handling could cause serious hazard depending

on the conditions.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appli-

ance by a person responsible for their safety.

Children should be supervised to ensure that they do not play

with the appliance.

Do not insert your ﬁ nger, a stick, or other objects into the air

inlet or outlet.

• This may cause injury, since the fan inside rotates at high speeds

during operation.

In case of an abnormal condition (such as a burning smell),

stop the air conditioner and disconnect the power plug or turn

the breaker OFF.

• A continued operation in the abnormal state may cause a malfunc-

tion, ﬁ re, or electric shock. In this case, consult your dealer.

When the air conditioner does not cool or heat, there is a pos-

sibility of refrigerant leakage. In this case, consult your dealer.

If a repair involves recharging the unit with refrigerant, ask the

service technician for details.

• The refrigerant used in the air conditioner is safe. Normally, it does

not leak. However, if refrigerant leaks and comes in contact with

a heat source such as a fan heater, kerosene heater, or cooking

stove, it will create a harmful gas.

The user should never attempt to wash the inside of the indoor

unit. Should the inside of the unit require cleaning, contact

your dealer.

• Unsuitable detergent may cause damage to plastic material inside

the unit, which may result in water leakage. Should detergent

come in contact with electrical parts or the motor, it will result in

a malfunction, smoke, or ﬁ re.

CAUTION

Do not touch the air inlet or the aluminum ﬁ ns of the indoor/

outdoor unit.

• This may cause injury.

Do not use insecticides or ﬂ ammable sprays on the unit.

• This may cause a ﬁ re or deformation of the unit.

Meanings of symbols used in this manual

: Be sure not to do.

: Be sure to follow the instruction.

: Never insert your ﬁ nger or stick, etc.

Never step onto the indoor/outdoor unit and do not put anything on them.

: Danger of electric shock. Be careful.

: Be sure to disconnect the power supply plug from the power outlet.

: Be sure to shut off the power.

SAFETY PRECAUTIONS

CONTENTS

■ 1SAFETY PRECAUTIONS

■ 2DISPOSAL

■ NAME OF EACH PART 3

■ PREPARATION BEFORE OPERATION 3

■ I-SEE OPERATION 5

■ SELECTING OPERATION MODES 6

■ FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT 7

■ I-SAVE OPERATION 8

■ ECONO COOL OPERATION 8

■ NATURAL FLOW OPERATION 9

■ AIR PURIFYING OPERATION 9

■ POWERFUL OPERATION 9

■ TIMER OPERATION (ON/OFF TIMER) 9

■ WEEKLY TIMER OPERATION 10

■ CLEANING 11

■ WHEN YOU THINK THAT TROUBLE HAS OCCURRED 12

■ WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME 13

■ INSTALLATION PLACE AND ELECTRICAL WORK 13

■ SPECIFICATIONS 13

Produkt Specifikationer

Mærke:	Mitsubishi
Kategori:	Klimaanlæg
Model:	KIT-MSZ-FH35VE
Type:	Klimaanlæg indendørs enhed
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Produktfarve:	Hvid
Wi-Fi:	Ingen
Timer:	Ja
Inverter-teknologi:	Ja
Klimaanlæg funktioner:	Cooling,Dehumidifying,Heating
Kølekapacitet i watt (nominel):	3500 W
Kølekapacitet i watt (maks.):	4000 W
Opvarmingskapacitet i watt (maks.):	6300 W
Energiforbrug pr. time (køling):	- kWh
Energiforbrug pr. time (opvarmning):	- kWh
Årligt energiforbrug (køling):	138 kWh
Ioniseringsanlæg:	Ingen
Fjernbetjent:	Ja
Kølemedium:	R410A
Multi-split:	Ingen
Sæsonbestemt effektivitetsvurdering (køling) (SEER):	8.9
Sæsonbestemt virkningsgrad (opvarmning) (SCOP) (Gennemsnitlig fyringssæson):	5.1
Køling energieffektivitet (EER, W/W):	4.27
Opvarming energieffektivitet (COP, W/W):	5
Kølekapacitet i watt (min.):	800 W
Varmekapacitet i watt (nominel) (Varmere fyringssæsonen):	4000 W
Varme kapacitet i watt (nominel) (Gennemsnitlig fyringssæson):	- W
Varmekapacitet i watt (nominel) (Koldere fyringssæsonen):	- W
Opvarmningskapacitet i watt (min.):	1000 W
Energieffektivitetsklasse (køling):	A+++
Energiforbrug (opvarmning) (Varmere fyringssæson):	A+++
Energiforbrug (opvarmning) (Gennemsnitlig fyringssæson):	A+++
Årligt energiforbrug (opvarmning) (Varmere fyringssæsonen):	429 kWh
Årligt energiforbrug (opvarmning) (Gennemsnitlig fyringssæson):	986 kWh
Årligt energiforbrug (opvarmning) (Koldere fyringssæsonen):	- kWh
Designbelastning (køling):	- kW
Design belastning (opvarmning) (Varmere fyringssæsonen):	- kW
Designbelastning (opvarmning) (Gennemsnitlig fyringssæson):	- kW
Design belastning (opvarmning) (Koldere fyringssæsonen):	- kW
Indendørs enhedstype:	Kan monteres på væggen
Støjniveau for indendørs enhed (høj hastighed):	58 dB
Antal indendørs enheder:	1
Indendørs enhed bredde:	925 mm
Indendørs enhed dybde:	234 mm
Indendørs enhed højde:	305 mm
Indendørs enhedsvægt:	13500 g
Støjniveau for udendørs enhed:	- dB
Sæsonbestemt virkningsgrad (opvarmning) (Anvendelsesområde) (Varmere fyringssæsonen):	6.5
Driftstemperatur (køling) (T-T):	-10 - 46 °C
Slange, diameter:	6.35 mm
Driftstemperatur (opvarmning) (T-T):	-15 - 24 °C
