Package overview

1 . 1 Monitor & accessories

Duex Max Magnetic Plates

Metallic Plates

Screen

Interchangeable usb Type-C ports

Backcharging port And signal port

Menu Buttons

Magnetic Plates

Adhesive stickers

USB Type-C Cable to type A

USB Type-C Cable to type C

Accessories

4 . 1 Attachment mode

First connect the original

power cable of your

switch/android device to

Duex Max, then connect

Switch/Android device

to Duex Max

2 . 1 Windows installation guide

Driver installation guide

When using USB C to connect, driver installation is not necessary.

Connect Windows Laptop to Mobile Pixels Duex Max Monitor, wait 20 secs and the monitor should

turn on. In the event the monitor does not turn on, please follow the steps below:

Double click and launch the installer. Click “Yes”

in the window below.

2. Click in the Window below:”Next”

Please download the correct windows driver

from:

1. WWW.MOBILEPIXELS.US/PAGES/DOWNLOAD-DRIVERS

Please select “I accept the terms of the license

agreement” and click Next

4. Please select “Yes, I want to restart my computer

now” and click Finish

3.The system should pop‐up a screen “System Extension Blocked” after installation asks the user to enable these

extensions for the ﬁrst time .Click “Open Security Preference” to go setting.

Important: This warning is not always shown. Even if it is not shown, for new installations the user must “Allow” to

install the Mobile Pixels driver and restart the laptop

2 . 2 Apple OS installation guide

Do not plug the Mobile Pixels Device into your mac before executing the driver installation

Click Mobile_Pixels_Graphics_Driver-3.3-2021-04-19.pkg,

please follow the instructions to install the device

driver.

2.1. Please download the Mac driver from the link below.

Run the ﬁle to "Mobile_pixels_3.3-2021-04-19.dmg"

load the drivers to the mac folder

WWW.MOBILEPIXELS.US/PAGES/DOWNLOAD-DRIVERS

(After System Reboot) Connect Mobile Pixels device

to Mac computer, a screen recording prompt should

pop up “Click Open System Preferences”

Go to System Preferences > Security & Privacy >

Privacy

5. Click on the “ to make changesLock”

Scroll and select and check “Screen Recording”

“DJTVirtualDisplayAgent”

7. Click on the Lock to save changes Click “Quit Now”

and restart the laptop.

Open the laptop monitor.

4 . 3 Portrait Mode

4 . 2 Rotated monitor

4 . 4 Presentation Mode

4 . 5 Nintendo Switch & Android mode Duex Max Only

To use it on the other side, rotate 180 degrees. Snap

into the back of the laptop.

Slide it and you are ready to work.

Slide Duex Max Rotate around 110° degrees

Slide Duex Max and rotate it To access presentation mode, simply swivel Duex

Max 180 degrees to the back of the laptop.

Slide Duex Max and swivel the screen.

*USB Cable omitted

Connect

Duex Max

to the Pc and use it in

portrait mode Go to Display settings to rotate

display

*USB Cable omitted

Attachment Guide

Center and square the

template on the back of

your laptop.

Clean laptop surface with included alcohol pad. Wait 10 secs for surface to dry.

Place/ adhere magnet(s) into

unﬁlled holes and press Down

to make sure it is ﬁrmly

adhered, then remove

template and mount your MP

monitor

Instruction for laptops under 16” monitor

Monitor positioning guide

Decide whether you want

the screen to extend left or

right Align the edge of the

template to the edge of the

laptop on the side you

chose.

Place/Adhere magnet(s) into

unﬁlled holes and press Down

to make sure it is ﬁrmly adhered,

then proceed to remove the

template and mount your MP

monitor

Instruction for laptops above 16” monitor

DUEX

MAX

Portable Laptop Monitor

5 . 1 Duplicate Mode to Extend Mode for Windows

Display Settings

Technical Information

-Right click on your desktop while Duex Max Is

connected and choose “Display Setting”

-Then you should either see this screen or the one at

next Section

-If you have a duplicate screen and want to change it to

extend mode, click on the “Duplicate these displays”

from the drop down box

-When the drop down box is opened, choose “Extend

these displays”

-Then click “Apply”

-Now you are in Extend Mode

5 . 2 Duplicate Mode to Extend Mode for Mac OS

5 . 3 Rotate Display and Layout set up for Windows

5 . 4 Rotate Display and Layout set up for Mac OS

5 . 5 Change Display Settings to Adjust Content Size for Windows

5 . 6 Change Display Settings to Adjust Content Size for Mac OS

6 . 2 Safety and Handling

- Click on system preference and go to Displays - Checking the “Mirror Displays” box will switch

between duplicate and extend mode for Duex Max

First click on the 2nd screen icon

Then open the Orientation drop down box and

change it from “Landscape” to “Landscape

(ﬂipped)”; Choose "Portrait" for Portrait Mode".

Then click “Apply”

-Now your screen is upside down and ready to be use

on the left with 1 extra step.

-Move the 2nd display icon from the right to the left of

the 1st display by simply “Drag and Drop” it.

-Click “Apply” to ﬁnish the setting of the lay out.

If you are already in “Extend mode” and want to use

Duex Max on the left

- To position the display on either left or right, simply drag

and drop it to the side you want.

DRAG AND DROP

- To rotate the display, go to the Duex Max display

window and choose the suitable “Rotation” options.

DUEX PLUS

Scroll Down

To adjust content size on Duex Max monitor, ﬁrst click

on the number “2” monitor under Display setting.

Scroll down and look for “scale and layout” options

Default size of text is set at 125% and user can

increase it up to 175% or reduce back to 100% base

on user preference.

Click System Preferences Click Displays

Hold down “Option” key and click “Scaled”

3. Select the resolution that ﬁts your need

Model

Size

Weight

Thickness

Thinnest

Hybrid Signals

Eye-Care Mode

Auto-Rotation

Nintendo Switch

Android Phones

Duex Max

*Speciﬁcations are subject to change without notice.

14.1 In

1.8 Lbs

0.60 In

0.35 In

Yes

yes

Yes

DUEX MAX and accessories contain small parts that may

present a choking hazard to small children, please keep

them out of reach from small children.

CHOKING HAZARD

The DUEX MAX contains magnets. The DUEX MAX also

contain components and radios that emit

electromagnetic ﬁelds. It may interfere with personal

medical devices, e.g. pacemakers or deﬁbrillators. Keep

a safe distance between the DUEX MAX and your

medical device. Consult a physician or medical device

manufacturer for speciﬁc details of your medical device.

Stop using DUEX MAX if the interference is observed

with your personal medical devices. Items with

magnetically-stored data such as credit cards and hard

drives may be sensitive to magnetic or electromagnetic

ﬁelds, hence should be kept at a distance from DUEX

MAX.

MEDICAL DEVICE INTERFERENCE

Carefully go through the user manual and other

documentation before setting up the DUEX MAX. If any

part is broken or damaged, do not try to open DUEX MAX

or attempt to ﬁx it yourself, please contact the retailer, a

qualiﬁed service technician or email us directly at

contact@mobilepixels.us. Store DUEX MAX under

appropriate conditions, avoid exposure to extreme heat,

moisture and dust. We recommend you to place DUEX

MAX on a stable surface and keep your DUEX MAX in a

sleeve to protect it during transport. Never spill liquid of

any kind onto the surface or into the openings of the

DUEX MAX. Do not spray any cleaner on the screen to

avoid an electric shock. If your DUEX MAX gets wet,

unplug all cables and reconnect till the DUEX MAX is

completely dry. Carefully unplug all cables before

cleaning DUEX MAX. Clean with a soft, dry, lint-free cloth.

To ensure satisfactory experience, use the DUEX MAX

with recommended display size of your laptop. Please

disconnect the cables when you reverse the position of

DUEX MAX, decouple the DUEX MAX from the backplane

of your laptop, rotate 180 About a vector normal to the 。

backplane, and re-couple to the backplane of the laptop

computer.

IMPORTANT SAFETY INFORMATION

For detailed troubleshooting information, contact:

SUPPORT

CONTACT@MOBILEPIXELS.US

Mobile Pixels INC warrants this product for a period of 1

year upon the original date of purchase. Product or

service warranty will not be extended to any losses or

damages that are due to improper installation, misuse,

neglect, modiﬁcation, alteration by non-authorized third

party, improper environment, or other irregularities.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1_This device may not cause harmful interference.

2_This device must accept any interference received

including interference that may cause undesired

operation. Note: This equipment has been tested and

found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against

harmful interference in a residential installation.This

equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

1_Reorient or relocate the receiving antenna.

2_Increase the separation between the equipment and

receiver. 3_Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected. 4_Consult the dealer or an experienced

radio/TV technician for help.

FCC COMPLIANCE STATEMENT

WARRANTY

User Guide

Copyright @ 2021 MOBILE PIXELS INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of MOBILE PIXELS INC. Product warranty or service will not be extended if: (1) the product

is repaired, modiﬁed or altered, unless such repair, modiﬁcation of alteration is authorized in writing by MOBILE PIXELS INC.; or (2) the serial number of the product is defaced or missing. MOBILE PIXELS INC. PROVIDES THIS MANUAL

“AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT

SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR

DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF MOBILE PIXELS INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND

INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY MOBILE PIXELS INC.

MOBILE PIXELS INC ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names

appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identiﬁcation or explanation and to the owners’ beneﬁt, without intent to infringe.

Produkt Specifikationer

Mærke:	Mobile Pixels
Kategori:	Skærm
Model:	Duex Max
Brugervejledning:	Ja
Produktfarve:	Grå
Skærm diagonal:	14.1 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ingen
HD-type:	Fuld HD
Skærmteknologi:	LCD
Naturligt aspektforhold:	16:9
Skærm form:	Flad
Indbyggede højttaler(e):	Ingen
VESA montering:	Ingen
Strømforbrug (standby):	- W
Strømforbrug (typisk):	4.5 W
Bredde (uden stativ):	320.04 mm
Dybde (uden stativ):	6.35 mm
Højde (uden stativ):	226.06 mm
Vægt (uden stativ):	816 g
Husmateriale:	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
Kabler inkluderet:	USB
Energiforbrug (SDR) pr. 1000 timer:	5 kWh
Energieffektivitetsklasse (SDR):	B
Energieffektivitetsklasse (HDR):	B
Energiforbrug (HDR) pr. 1000 timer:	5 kWh
Energieffektivitetsskala:	A til G
HDMI:	Ingen
Indbygget kamera:	Ingen
Paneltype:	IPS
Maksimal opdateringshastighed:	60 Hz
Skærmens lysstyrke (typisk):	300 cd/m²
Indbygget USB-hub:	Ja
Udgang til hovedtelefoner:	Ingen
Højdejustering:	Ingen
Kapabilitet:	macOS / Windows / Android
Antal upstream-porte:	2
USB upstream port type:	USB Type-C
Kode for europæisk produktregister for energimærkning (EPREL):	1502495
