PRODUCT & INSTALLATION

GUIDE

INSTALLATION GUIDE

Custom Install Trimless Series Features

All models feature our new ‘Trimless’ grilles, held in place by high strength Neodynium magnets covering the entire product

for that true trimless, stealth look.

All models also feature our unique Tri-Grip

ﬁxing design. This ‘dog’ style ﬁxing provides a greater contact surface area

than other types in no less than 3 different areas on the single ﬁxing. The Tri-Grip ﬁxings are made from a tough re-enforced

polymer, giving a secure ﬁxing.

Pre-construction brackets can be purchased for all models. These are ﬁtted prior to plaster board (sheet rock) ﬁxing and

provide a guide to cut around.

300 Series

s Second generation RST

bass drivers. The 300 Series is also the ﬁrst range of speakers to feature a 8” version of the RST driver.

s C-CAM

gold dome tweeter. Monitor Audio’s famous 25mm gold C-CAM dome. Improvements to the surround and

motor system have extended the frequency response to beyond 30 kHz

s The LCR models employ a unique Inverted Dual Concentric (IDC

) pivoting mid-range/tweeter module, providing up to

18 degrees of movement and allowing the sound to be directed towards the desired listening zone. These models offer

superior performance and ﬂexibility over typical 2-way or ﬁxed angle speaker designs

s The FX model features a switchable di-pole mode. There is a three position switch to control this feature. It can be set to

bi-pole (normal operation), di-pole, or trigger. When set to trigger, the di-pole mode is controlled by a 12v trigger found

in high end AV ampliﬁers/receivers

s The high frequency level, mid frequency level (not on FX) and boundary compensation controls facilitate a wider range

of possible adjustments.

200 Series

s C-CAM

bass drivers. The renowned C-CAM (Ceramic Coated Aluminium Magnesium alloy) is an innovative alloy

material that exhibits ideal mechanical properties for use in high performance loudspeaker cones and diaphragms

s C-CAM

gold dome tweeter. The pivoting tweeter is based on Monitor Audio’s famous 25mm gold C-CAM dome.

Improvements to the surround and motor system have extended the frequency response to beyond 30 kHz

s The LCR models employ a unique Inverted Dual Concentric (IDC

) pivoting mid-range/tweeter module, providing up to

18 degrees of movement and allowing the sound to be directed towards the desired listening zone. These models offer

superior performance and ﬂexibility over typical 2-way or ﬁxed angle speaker designs

s The FX model features a switchable di-pole mode. This is manually set by changing the position of the switch on the

product. A front mounted switch is provided to select between bi-pole (monopole) or di-pole operation, dependant on

system installation. This enhances the whole movie experience when used in a 7.1 channel system

s High frequency level and boundary compensation (excluding the FX model) controls facilitate a wider range of possible

adjustments.

100 Series

s MMP

II cone technology. The MMPII (Metal Matrix Polymer) cone material uses a high-pressure injection moulding

process to achieve different thicknesses at critical points in the cone geometry

s C-CAM

tweeter. The new tweeter utilises a pivoting action to provide optimum imaging and ﬂexible set-up options.

High frequency level control is provided to offer a degree of balance adjustment once installation is completed.

Painting the Grilles

NOTE: If choosing to paint the grille, we recommend you follow these simple steps:

1. Remove the membrane scrim from the inside of the grille.

2. Paint all grilles required for the installation with the same batch of paint (if they are to be the same colour). Spray paint

is easier to apply or use a stippling action when brushing to avoid blocking the holes of the grille.

3. When dry, attach the spare membrane scrim (supplied) into the inside of the grille.

4. Fit the grille to the speaker (s).
