Introduction 1
Unpacking 1
SubConnect 1
AmpPanel 2
Positioning/InitialSetUp 4
SetUp 4
RS232 5
RS232WiringConguration 5
RS232CommunicationSet-UpParameters 5
CommandProtocol 5
CommandList 5
EQProles 6
InfraRedRemoteCodes 6
UpdateFirmwareonSub 6
BootloaderMode 6
AutomaticUpdate. 7
ManualUpdate 7
FactoryReset 8
Guarantee 8
Specications 9
TroubleShooting 10
OwnerInformation 10
ENGLISH
Introduction
Thank you for your purchase of the CW8 or CW10, which have been designed and constructed using quality systems and materials
to provide years of enjoyment, reliability and pride of ownership.
The subwoofers both use our own, proprietary in-house developed DSP and EQ proles to provide you with the all encompassing
Monitor Audio experience. With technology used in the agship range, the Platinum II Series, these subwoofers will ll the room
with ground shaking bass.
Please read through this manual to familiarise yourself with any safety advice and how to set up your subwoofer to achieve the
very best listening experience.
Please retain this manual for future reference.
Unpacking
Care must be taken at all times when handling the subwoofer due to the weight and the construction of the
product. We recommend a two-person lift wherever appropriate.
The mains power cord(s) and 12 volt trigger cable are contained separately in the packaging and should be removed prior to
unpacking the product.
To remove the subwoofer from its carton place some protective material on the oor and having removed any loose items (mains
lead(s) and 12 volt trigger lead) from the top of the packaging, carefully invert the carton. Also refer to the icons printed on the
carton. Gradually pull the carton upwards to expose the subwoofer, which will be presented with its base uppermost. Remove
xing tape from bag and expose the base/cabinet.
SubConnect
The Monitor Audio SubConnect application is a Windows only application that enables the end user to fully customise and control the
advanced features of the subwoofer. The application is downloadable from the Monitor Audio website (www.monitoraudio.co.uk). Here
you will nd full instructions on how to install and use it.
The application will be required should a rmware update be needed for the CW8 or CW10.
monitoraudio.com 1
