Side 1/12
If you have questions,call 800.GE.CARES or visit our website at: www.monogram.com
Installation
Instructions
Professional Gas Cooktops
48" Natural Gas Models
ZGU48N4G
ZGU48N6R
ZGU48N6D
48" LP Gas Models
ZGU48L4G
ZGU48L6D
36" Natural Gas Models
ZGU36N6
ZGU36N4R
ZGU36N4D
36" LP Gas Models
ZGU36L6
ZGU36L4D
Installation Instructions
CAUTION:
THESE COOKTOPS SHOULD BE INSTALLED
IN CONJUNCTION WITH A SUITABLE
OVERHEAD VENT HOOD. Due to the high heat capacity
of this unit, particular attention should be paid to the
hood and duct work installation to assure it meets
local building codes.
MISE EN GARDE :
CES CUISINIÈRES DOIVENT ÊTRE
MONTÉES CONJOINTEMENT AVEC UNE
HOTTE À ÉVACUATION DE PLAFOND APPROPRIÉE.
Étant donné la grande capacité thermique de cet
appareil, une attention particulière doit être portée
au montage de la hotte et du système de gaines pour
s’assurer qu’il est conforme aux codes du bâtiment
locaux.
Standard countertop and island installations:
A 1200 CFM hood is recommended for 48" cooktops.
A 600 CFM hood is recommended for 36" cooktops.
Hoods should be 24" min. deep and the same width
as the cooktop.
Island installations:
Check local building codes for the proper method of
gas cooktop installation. Local codes vary. Installation,
electrical connections and grounding must comply
with applicable codes. In the absence of local codes,
the cooktop should be installed in accordance with the
National Fuel Gas Code ANSI 223.1-1990 and National
Electrical Code ANSI/NFPA 70-1990.
CAUTION:
These cooktops are extremely heavy. Due
to the weight and size of the cooktop and
to reduce the risk of personal injury or damage to the
product, TWO PEOPLE ARE REQUIRED FOR PROPER
INSTALLATION.
MISE EN GARDE :
Ces cuisinières sont extrêmement lourds.
Tout démontage réduira considérablement
leur poids. En raison du poids et de la taille de la
cuisinière, dont la manipulation risque d’entraîner
des lésions corporelles ou des dommages au produit,
DEUX PERSONNES SONT NÉCESSAIRES POUR
PROCÉDER À UN MONTAGE ADÉQUAT.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
• IMPORTANT – Save these instructions for
local inspector’s use.
• IMPORTANT – Observe all governing codes
and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these instructions for
future reference.
•Skill Level – Installation of this cooktop requires
basic mechanical and electrical skills.
•Completion time – 1 to 3 hours.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
WARNING:
This appliance must be properly grounded.
See “Electric Supply”, page 6.
AVERTISSEMENT :
Cet appareil doit être mis à la terre
adéquatement. Voir la section « Alimentation
électrique » à la page 6.
For Monogram local service in your area,
1.800.444.1845.
For Monogram Service in Canada, call
1.888.880.3030.
For Monogram Parts and Accessories, call
1.800.626.2002.
If you received a damaged cooktop, you should contact
your dealer.
In the Commonwealth of Massachusetts:
• This product must be installed by a licensed plumber
or gas fitter.
• When using ball type gas shut off valves, they shall
be T-handle type.
• A flexible gas connector, when used, must not
exceed 3 feet.
2
