Side 1/4

Product Disposal—

Certain international, nationa l

and/or local laws and/or reg -

ulations may apply regarding the

disposal of this product. For furthe r

detailed information, pleas e

contact the retailer where yo u

purchased this product or the Morel

Distributor in you r

Morel’s distributors can be found

at the website:

country.

morelhi.com

IMPORTANT SAFETY INSTRUCTION S

READ BEFORE OPER TING EQUIPMEN A T

1. .Read these instructions

2. .Keep these instructions

3. .Read all warnings

4. .Follow all instructions

5. Do not use the subwoofer near water.

6. Clean only with dry cloth .

7. Do not block any ventilation openings. Install in accordance with th e

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves ,

or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the othe r. A grounding type plug has two blades and a third

grounding prong. The wide blade or the third prong are provided for your safet y. If the provided

plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power. cord from being walked on or pinched particularly at plugs ,

convenience receptacles, and the point where they exit from the apparatus .

11 Only use attachments/accessories. specied by the manufacture r.

12 Use only with. the cart, stand, tripod, bracket, or table specied by th e

manufacturer, or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-ove r.

13 Unplug this apparatus. during lightning storms or when unused for long periods

of time.

14 Refer all servicing. to qualied service personnel. Servicing is required when the apparatus

has been damaged in any wa y, rsuch as powe -supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed

to rain or moisture, does not operate normall y, or has been dropped.

15. WARNING: To reduce the risk of re or electric shock, this apparatus should not be exposed to

rain, moisture and objects lled with liquids. should not be placed on this apparatus.

16. To completely disconnect this equipment from the mains, disconnect the power supply cord

plug from the receptacle.

17 The main plug. of the power supply cord shall remain readily operable.

Construction

Dim sionsen 10.6”x11.6”x10.6”

( x .5x cm)27 29 27

Drive itun

Fr cy res seequen pon 35-160Hz

Ampli erﬁ

In tpu

Vo aglt e 220-240 50VAC Hz

Net weight 16.5 lbs (7.5 Kg)

80 on nuou paW,class AB, c ti s power, ll formats com a tible

with tomatic on/off switch, level, crossover and p se au ha

c trols.on

Less than 0.5W in standby.

One 8” subwoofer with 2” voice coil a nd

rear-v ted m t motor en agne

MDF coated paint nishpiano ﬁ

Line-level RCA p jack / Hi Level Inhono

Morel operates a product design improvement policy consequently speciﬁcations are subject to alterations without prior notice

SPECIFICATIONS

AC Power Connection

And AUTO ON/OFF (AUTO mute circuit)

Volume Level

Phase Switch

The SUB-8X features auto on/off circuitry , marked “AUTO”, that automatically turns your subwoofer on when it senses

a signal.

To activate it turn the Auto swith to the ON position. When no signal is present, the circuit turns the subwoofer off after a

few minutes. If you are concerned about the brief delay between when the music starts and when the subwoofer turns

on, simply maintain the main POWER switch in an ON position and turn the AUTO swith off position.

Adjust by ear using a wide variety of CDs and video sources. Adjust for deep, powerful but pleasant bass.

Have someone else switch between the two settings while you sit in your favorite listening position. Use music with good

bass and a deep male vocal. When you hear the best balance of deep bass and natural lower octaves of the male voice,

you have achieved optimum phase tuning.

SUBWOOFR ADJUSTMENTS

This control adjusts the frequency range over which the subwoofer operates. When using smaller main speakers, the

upper range of the control will probably yield the best results. With larger speakers, the lower end of the control range will

probably sound best, but always let your ear be the final judge. If male vocals sound “thin,” turn this control up until the

voice sounds rich but not boomy. If male vocals sound too “thick” or “chesty,” turn this control down until the voice sounds

natural.

Frequency
