Side 1/86

™

112D

User Guide

1280 Massachusetts Avenue

Cambridge, MA 02138

Business voice: (617) 576-2760

Business fax: (617) 576-3609

Web site: www.motu.com

Tech support: www.motu.com/support

Title Page

SAFETY PRECAUTIONS AND ELECTRICAL REQUIREMENTS FOR THE 112D (“PRODUCT”)

CAUTION! READ THIS SAFETY GUIDE BEFORE YOU BEGIN INSTALLATION OR OPERATION. FAILURE TO COMPLY WITH SAFETY INSTRUCTIONS

COULD RESULT IN BODILY INJURY OR EQUIPMENT DAMAGE.

HAZARDOUS VOLAGES: CONTACT MAY CAUSE ELECTRIC SHOCK OR BURN. TURN OFF UNIT BEFORE SERVICING.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR OTHER MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

WARNING: DO NOT PERMIT FINGERS TO TOUCH THE TERMINALS OF PLUGS WHEN INSTALLING OR REMOVING THE PLUG TO OR FROM THE OUTLET.

WARNING: IF NOT PROPERLY GROUNDED THE MOTU PRODUCT COULD CAUSE AN ELECTRICAL SHOCK.

The MOTU product is equipped with a three-conductor cord and grounding type plug which has a grounding prong, approved by Underwriters' Laboratories and the Canadian Standards Association.

This plug requires a mating three-conductor grounded type outlet as shown in Figure A below. If the outlet you are planning to use for the MOTU product is of the two prong type, DO NOT REMOVE

OR ALTER THE GROUNDING PRONG IN ANY MANNER. Use an adapter as shown below and always connect the grounding lug to a known ground. It is recommended that you have a qualiﬁed

electrician replace the TWO prong outlet with a properly grounded THREE prong outlet. An adapter as illustrated below in Figure B is available for connecting plugs to two-prong receptacles.

WARNING: THE GREEN GROUNDING LUG EXTENDING FROM THE ADAPTER MUST BE CONNECTED TO A PERMANENT GROUND SUCH AS TO A

PROPERLY GROUNDED OUTLET BOX. NOT ALL OUTLET BOXES ARE PROPERLY GROUNDED.

If you are not sure that your outlet box is properly grounded, have it checked by a qualiﬁed electrician. NOTE: The adapter illustrated is for use only if you already have a properly grounded two-prong

receptacle. Adapter is not allowed in Canada by the Canadian Electrical Code. Use only three wire extension cords which have three-prong grounding type plugs and three-prong receptacles which

will accept the MOTU product plug.

IMPORTANT SAFEGUARDS

1. Read these instructions. All the safety and operating instructions should be read before operating the product.

2. Keep these instructions. These safety instructions and the product owner’s manual should be retained for future reference.

3. Heed all warnings. All warnings on the product and in the owner’s manual should be adhered to.

4. Follow all Instructions. All operating and use instructions should be followed.

5. Do not use the product near water.

6. Cleaning - Unplug the product from the computer and clean only with a dry cloth. Do not use liquid or aerosol cleaners.

7. Ventilation - Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Heat - Do not install the product near any heat sources such as radiators, heat registers, stoves, or another apparatus (including an ampliﬁer) that produces heat.

9. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of ﬁre or electrical shock.

10. Grounding - Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade

or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult and electrician for replacement of the obsolete outlet.

11. Power cord - Protect the product power cord from being walked on or pinched by items placed upon or against them. Pay particular attention to cords and plugs, convenience receptacles, and the point where they exit from the unit.

12. Power switch - Install the product so that the power switch can be accessed and operated at all times.

13. Disconnect - The main plug is considered to be the disconnect device for the product and shall remain readily operable.

14. Accessories - Only use attachments/accessories speciﬁed by the manufacturer.

15. Placement - Use only with the cart, stand, tripod, bracket or table speciﬁed by the manufacturer, or sold with the product. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

16. Surge protection - Unplug the product during lightning storms or when unused for long periods of time.

17. Servicing - Refer all servicing to qualiﬁed service personnel. Servicing is required when the product has been damaged in any way, such as when a power-supply cord or plug is damaged, liquid has been spilled or objects have fallen

into the product, the product has been exposed to rain or moisture, does not operate normally, or has been dropped.

18. Power Sources - Refer to the manufacturer’s operating instructions for power requirements. Be advised that different operating voltages may require the use of a different line cord and/or attachment plug.

19. Installation - Do not install the product in an unventilated rack, or directly above heat-producing equipment such as power ampliﬁers. Observe the maximum ambient operating temperature listed below.

20. Power ampliﬁers- Never attach audio power ampliﬁer outputs directly to any of the unit’s connectors.

21. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions

may result in ﬁre, electric shock or other hazards.

22. Safety Check - Upon completion of any service or repairs to this MOTU product, ask the service technician to perform safety checks to determine that the product is in safe operating conditions.

ENVIRONMENT, HEAT AND VENTILATION

Operating Temperature: 10°C to 40°C (50°F to 104°). The product should be situated away from heat sources or other equipment that produces heat. When installing the product in a rack or any other location, be sure there is adequate

space around the product to ensure proper ventilation. Improper ventilation will cause overheating and can damage the unit.

TO REDUCE THE RISK OF ELECTRICAL SHOCK OR FIRE

Do not handle the power cord with wet hands. Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

Do not expose this apparatus to rain or moisture. Do not place objects containing liquids on it.

AC INPUT

100 - 240VAC ~ • 50 / 60Hz • 0.5A max

3-prong plug

Grounding prong

Properly grounded 3-prong outlet

Grounding lug

Screw

3-prong plug
