Side 1/7

P/N: 180201400001A

*180201400001A*

UPort 1200/1400/1600 Series

Quick Installation Guide

USB- -to Serial Converter

Version 9.2, May 21 20

Technical Support Contact Information

www.moxa.com/support

 2 . A 20 1 Moxa Inc ll rights reserved.

- - 2

Overview

Moxa’s USB- -to serial product provides a wide range of easy- -to use

solutions for adding Windows COM ports and Linux tty ports through a

PC’s USB port.

The UPort 1200/1400/1600 series are the following models:

• - - UPort 1250: 2 port RS 232/422/485 USB- -to serial converter

• UPort 1250I: 2 232/422/485 USB- -port RS - -to serial converter w/

isolation protection

• UPort 1410: 4 232 USB- -port RS - - to serial converter

• UPort 1450: 4 232/422/485 USB- -port RS - -to serial converter

• UPort 1450I: 232/422/485 USB 4- -port RS - -to serial converter w/

isolation protection

• UPort 1610 232 USB- - -8: 8 port RS - -to serial converter

• UPort 1650 232/422/485 USB- - -8: 8 port RS - -to serial converter

• UPort 1610 16: 16- -port RS-232 USB- -to serial converter

• UPort 1650 16: 16- -p -ort RS 232/422/485 USB- -to serial converter

Before connecting UPort USB-to-serial converters to your computer’s

USB port, we recommend installing the UPort driver first. To do this,

follow the installation procedure described in the “Installing the UPort

1200/1400/1600 Driver” section below. The installation procedure was

done on a PC running a Windows platform. UPort converters can be

connected to any upstream type A USB port that is on the PC host or on

an upstream hub. UPort converters are hot pluggable, and therefore

there is no need to power down your computer prior to installation.

After installing the driver, connect the UPort to an upstream host or

hub. The Found New Hardware wizard will locate the appropriate

drivers automatically. Once the drivers are found, various windows will

pop up as the UPort’s serial port is being installed. When the Found

New Hardware Wizard finishes installing the UPort, use the operating

system’s Device Manager to check and/or modify the port settings.

The new COM port will . be listed under Ports (COM & LPT)

Ordering Information

Package Checklist

Before installing the UPort, verify that the package contains the

following items:

• 1 UPort 1200/1400/1600 USB- -to serial converter

• USB cable: CBL-USBA/B-100

• 100 to 240 VAC power adapter (excluding T models, UPort

1250/1410)

• 1 power cord suitable for your region (excluding T models, UPort

1250/1410)

• 1 serial adapter: mini DB9F- -to TB (excluding UPort 1410/1610

series)

• - WK- -44 01: 19” rackmount L brackets (2 L shaped plates with 8

screws; for UPort 1600- 16 series)

• Quick installation guide (printed)

• Warranty card

NOTE

Notify your sales representative if any of the above items is

missing or damaged.

Produkt Specifikationer

Mærke:	Moxa
Kategori:	Ikke kategoriseret
Model:	UPort 1450I
Opbevaringstemperatur (T-T):	-20 - 75 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Driftstemperatur (T-T):	0 - 55 °C
Effektkrav:	12 - 48 VDC
Kompatible operativsystemer:	Windows 2000, XP/2003(x86 & x64)
Grænseflade:	USB 2.0; Serial (RS-232, RS-422, RS-485)
Stik:	USB (B), DB9
Dataoverførselshastighed:	480 Mbit/s
Porte, antal:	4
Datalink-protokol:	TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, Data+ (B), Data-(A)
