<變數 1> Contents

Contents

Safety Information ........................................................................................... 2

Specifications ...................................................................................................3

Package contents.............................................................................................6

Rear I/O Panel ..................................................................................................7

LAN Port LED Status Table .................................................................................7

Overview of Components ................................................................................8

CPU Socket .........................................................................................................9

DIMM Slots ........................................................................................................10

PCI_E1~3: PCIe Expansion Slots ......................................................................11

JFP1, JFP2: Front Panel Connectors ...............................................................12

SATA1~4: SATA 6Gb/s Connectors....................................................................12

M2_1: M.2 Slot (Key M) .....................................................................................13

ATX_PWR1, CPU_PWR1: Power Connectors....................................................13

JUSB1~2: USB 2.0 Connectors .........................................................................14

JUSB3: USB 3.1 Gen1 Connector .....................................................................14

CPU_FAN1, SYS_FAN1~2: Fan Connectors ......................................................15

JTPM1: TPM Module Connector .......................................................................16

JCI1: Chassis Intrusion Connector ...................................................................16

JAUD1: Front Audio Connector ......................................................................... 17

JCOM1: Serial Port Connector .........................................................................17

JLPT1: Parallel Port Connector........................................................................17

JBAT1: Clear CMOS (Reset BIOS) Jumper .......................................................18

EZ Debug LED: Debug LED indicators ..............................................................18

JRGB1: RGB LED strip connector .....................................................................18

BIOS Setup ..................................................................................................... 19

Entering BIOS Setup .........................................................................................19

Resetting BIOS ..................................................................................................20

Updating BIOS ...................................................................................................20

Software Description .....................................................................................21

Installing Windows

10 .....................................................................................21

Installing Drivers ..............................................................................................21

Installing Utilities ..............................................................................................22

Thank you for purchasing the MSI

B450M PRO-VDH PLUS

motherboard. This User Guide gives information about

board layout, component overview, BIOS setup and software

installation.

Safety Information

y The components included in this package are prone to damage from electrostatic

discharge (ESD). Please adhere to the following instructions to ensure successful

computer assembly.

y Ensure that all components are securely connected. Loose connections may cause

the computer to not recognize a component or fail to start.

y Hold the motherboard by the edges to avoid touching sensitive components.

y It is recommended to wear an electrostatic discharge (ESD) wrist strap when

handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is

not available, discharge yourself of static electricity by touching another metal object

before handling the motherboard.

y Store the motherboard in an electrostatic shielding container or on an anti-static

pad whenever the motherboard is not installed.

y Before turning on the computer, ensure that there are no loose screws or metal

components on the motherboard or anywhere within the computer case.

y Do not boot the computer before installation is completed. This could cause

permanent damage to the components as well as injury to the user.

y If you need help during any installation step, please consult a certified computer

technician.

y Always turn off the power supply and unplug the power cord from the power outlet

before installing or removing any computer component.

y Keep this user guide for future reference.

y Keep this motherboard away from humidity.

y Make sure that your electrical outlet provides the same voltage as is indicated on

the PSU, before connecting the PSU to the electrical outlet.

y Place the power cord such a way that people can not step on it. Do not place

anything over the power cord.

y All cautions and warnings on the motherboard should be noted.

y If any of the following situations arises, get the motherboard checked by service

personnel:

 Liquid has penetrated into the computer.

 The motherboard has been exposed to moisture.

 The motherboard does not work well or you can not get it work according to

user guide.

 The motherboard has been dropped and damaged.

 The motherboard has obvious sign of breakage.

y Do not leave this motherboard in an environment above 60°C (140°F), it may

damage the motherboard.

Produkt Specifikationer

Mærke:	MSI
Kategori:	Linse
Model:	B450M PRO-VDH PLUS
Bredde:	244 mm
Dybde:	244 mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	4
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	4
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Hurtig installationsvejledning:	Ja
Kabler inkluderet:	PCIe
Lyd-output kanaler:	7.1 kanaler
Strømkilde type:	ATX
Processorserie:	AMD Ryzen™ 7
Maksimal intern hukommelse:	64 GB
Mikrofonindgang:	Ja
Understøttede Windows-operativsystemer:	Windows 10 x64
Processorproducent:	AMD
Drivere inkluderet:	Ja
HDMI-version:	1.4
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Understøttet datalagringsdrev typer:	HDD & SSD
HDD-størrelse:	2.5/3.5 "
Antal PS/2-porte:	1
Processor sokkel:	Stik AM4
Antal understøttede HHD'er:	4
DirectX-version:	12.0
Kompatibel processor serie:	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Bundkort chipset familie:	AMD
Bundkort chipsæt:	AMD B450
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	1866,2133,2400,2667,2800,2933,3000,3066,3200,3466 MHz
Antal SATA III-stik:	4
LAN Kontroller:	Realtek 8111H
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	8
USB 3.2 Gen 1 (3.1 Gen 1) stik:	6
CPU-ventilatorstik:	Ja
ATX strømstrik (24 stikben):	Ja
Indbrudsttik til kabinet:	Ja
Antal kabinetventilatorstik:	3
Antal DVI-D-porte:	1
Motherboard form faktor:	micro ATX
RAID-niveauer:	0, 1,10
Strømstik til ventilator:	Ja
PCI Ekspres x16 (Gen 3.x) slots:	1
TPM-stik:	Ja
Grafikadapter familie:	AMD
Parallelt stik:	Ja
PCI Ekspres x1 (Gen 2.x) slots:	1
EPS strømstik (8-pin):	Ja
Seriel port overskrifter:	1
Antal monteringshuller:	8
12V strømstik:	Ja
Header med RGB-LED-ben:	Ja
Maksimal UDIMM hukommelse:	64 GB
Lydstik:	Ja
Understøttede hukommelsesmodulkapaciteter:	2GB, 4GB, 8GB, 16GB, 32GB
Hjælpeprogrammer inkluderet:	Ja
Understøttet UDIMM modul kapacitet:	2GB, 4GB, 8GB, 16GB, 32GB
