Side 1/2
Wi-Fi 7 PCIe Card (Included Qualcomm NCM865)
HERALD-BE
Quick Installation Guide
Installing the Wi-Fi/Bluetooth PCIe card
Important
1
2
3
5
4
5
PCIe p1-x1 slot
USB cable
USB 2.0 connector
on the motherboard
Make sure all cables are properly connected.
1. Install the Wi-Fi/Bluetooth PCIe card in a
PCIe p1-x1 slot.
2. Connect one end of the USB cable to the
USB connector on the card.
3. Connect the other end of the USB cable
to the USB 2.0 connector on the
motherboard.
4. Use a screw to securely fasten the card in
place.
5. Tighten the antenna onto the
RP-SMA connectors on the
Wi-Fi/Bluetooth PCIe card as
illustrated.
6. Power on your system
and proceed to
install the
necessary
driver.
Antenna
Wi-Fi 7 PCIe Card (Included Qualcomm NCM865)
HERALD-BE
Quick Installation Guide
G52-B9052XC
Specifications Wi-Fi 7 PCIe Card (Included Qualcomm NCM865)
Network Standard Wi-Fi 7, Bluetooth 5.4
Input Interface PCI-E p2-x1 slot
Transmission Data Rate 5.8 Gbps Max Speed
Compatible OS Windows 11
Operate Frequency (Bandwidth) 2.4Ghz, 5Ghz, 6GHz (320Mhz)
Size 120mm x 70mm (L x W)
Compatible MSI's Motherboard Intel
®
Z590 / B560 / Z690 / B660 / Z790 / B760
AMD
®
X670 / X570 / B650 / B550
Packing Contents
Antenna
Screw
USB Cable
Wi-Fi/Bluetooth PCIe card
* These pictures are for reference only and may vary without notice.
* The packing contents may vary according to the model you purchased.
