Side 1/12

- 1-1 -

ENGLISH

CAUTION

The power cord provided with this monitor is de-

signed for safety and must be used with a properly

grounded outlet to avoid possible electrical shock.

Do not remove the monitor cabinet as this can

expose you to very high voltages and other hazards.

Trademark

IBM, PC, PS/2, PS/V, Personal System/2 are registered trade-

marks of International Business Machines Corp.

Apple Macintosh is a registered trademark of Apple Computer, Inc.

Quadra is a trademark of Apple Computer, Inc.

UNIX is a registered trademark in the United States and other

countries, licensed exclusively through X/Open Company Limited.

E NERGY STAR is a U.S. registered mark.

1. INTRODUCTION ..................................................... 1-2

1.1 Features ........................................................ 1-2

1.2 Internal Preset Memory Capability ................ 1-3

1.3 Power Management Function ....................... 1-3

1.4 DDC .............................................................. 1-3

1.5 Location Considerations ............................... 1-3

1.6 Cleaning Your Monitor .................................. 1-3

1.7 Unpacking ..................................................... 1-4

1.8 Tilt/Swivel Base............................................. 1-4

Screen Position Adjustment .......................... 1-4

1.9 Quick Operation Chart .................................. 1-4

2. PART NAME............................................................ 1-5

2.1 Control Names .............................................. 1-5

2.2 Function ........................................................ 1-5

3. INSTALLATION AND CONNECTION ..................... 1-6

3.1 AC Power Connection ................................... 1-6

3.2 Signal Cable Connection .............................. 1-6

3.2.1 Connecting to any IBM VGA Compatible

System ................................................... 1-6

3.2.2 Connecting to an Apple Macintosh

Computer ............................................... 1-6

4. OSD(On Screen Display) FUNCTIONS .................. 1-7

4.1 How to adjust the screen .............................. 1-7

4.2 Adjustment Items .......................................... 1-8

5. TROUBLESHOOTING ............................................ 1-10

6. SPECIFICATIONS................................................... 1-12

CONTENTS

MANUFACTURER DECLARATION FOR CE-MARK-

ING:

We, NEC-Mitsubishi Electric Visual Systems Corpo-

ration, declare under our sole responsibility, that this

product is in conformity with the following standards:

EN60950

EN55022 Class B

EN61000-3-2

EN61000-3-3

EN55024

following the provisions of:

73/23/EEC Low Voltage Directive

89/336/EEC EMC Directive

WARNING!

This product is not designed for use in life support

devices and NEC-Mitsubishi Electronics Display makes

no representations to the contrary. Life support devices

are those devices which are used to measure, diagnose,

or evaluate the tissue, systems or functions of the

human body; or other devices employed to support or

sustain life or good health.

- 1-2 -

INTRODUCTION

Congratulations on your purchase of the high resolution

color monitor. We designed this monitor to provide you

with years of reliable trouble-free operation.

This guide tells you how to connect, adjust and care for your

monitor. This guide also provides technical specifications

and instructions for troubleshooting any basic problems

you may experience with your monitor.

1.1 Features

This monitor is a 43cm/17"(41cm/16" Diagonal Viewable

Image) intelligent, microprocessor-based monitor compat-

ible with most analog RGB (Red, Green, Blue) display

standards.

It provides crisp text and vivid color graphics with both PC

and Macintosh platforms.

• The monitor’s wide auto-scanning compatibility range

makes it possible to upgrade video cards or software

without purchasing a new monitor.

• Digitally controlled auto-scanning is done using an

internal microprocessor, for horizontal scan frequen-

cies between 31kHz and 96kHz, and vertical scan

frequencies between 55Hz and 160Hz. The micropro-

cessor-based intelligence allows the monitor to oper-

ate in each frequency mode with the precision of a fixed

frequency monitor.

• The monitor contains resident memory for pre-pro-

grammed screen display standards and is also capable

of storing additional user adjustment parameters.

• The monitor is capable of producing a non-interlaced

maximum addressable resolution format of 1600 dots

x 1200 lines. This display is well suited for windowing

environments.

• Because of the analog signal inputs, the monitor can

display an unlimited palette of colors that can be

manually adjusted to suit your specific needs.

• The monitor has a power management function ac-

corded to VESATM-DPMSTM-standard. To save energy,

the monitor must be connected to a system compliant

with the VESATM -DPMSTM-standard. (Refer to your

computer and/or video card instructions for proper

operation.)

• To ensure ease of installation and ongoing use, the

monitor features On Screen Display (OSD) of all moni-

tor set-up and adjustment functions.

• For use in a variety of applications, the monitor com-

plies with UL 1950, CSA C22.2 No.950-95 and EN60950

for safety, FCC Class-B and EN55022 Class-B for EMI,

pr EN50279 (MPR-III), ISO 9241-3, ISO9241-7 and

ISO9241-8 for ergonomics. The monitor also complies

with TCO’99 guideline for environmental safe use.

• The monitor features the world's standa rd

DIAMONDTRON NF CRT upgraded with improved

focus and convergence for supersharp and pure pic-

ture images.

• The monitor complies with Video Electronics Standards

Association (VESATM) DDCTM1/2B(EDID) specification.

If your computer is Plug & Play compliant setup will be

done automatically.

• The CRT provides fine 0.25mm aperture grille pitch/

Maximum addressable resolution of 1600x1200.

• The monitor has a brightness enhancement function

(S.B.Mode: Super Bright Mode) and it is designed to

accentuate pictures, moving pictures and for gaming as

well as multimedia applications.
