Read this user manual and in
particular the safety notes,
before using the product.
Keep the user manual for future
reference and include it when passing the
product on to third parties.
Esprinet S.p.A. will not in any way be held
responsible for injury or damage caused to
persons or property arising from misuse of
the product.
Warnings
Avoid listening at extreme volumes,
particularly for prolonged periods of time
when using the product.
If you use the product at an excessively high
volume, you could permanently damage your
hearing. Listen at a moderate volume.
Audio warnings, alerts and environmental
noises may sound different when wearing the
product.
Be aware of how these signals differ in terms
of their sound so that you are able to recognize
the signals in corresponding situations.
Do not use the product when driving motor
vehicles, cycling, when operating machines or
in other situations where impaired awareness
of noises in your surroundings could pose a
risk to you or others. At the same time, also
observe the legal regulations and provisions in
the country where you use the product.
To prevent malfunction or damage to the
product, avoid accidental falls, do not crush,
puncture or exercise a high level of pressure
on the product.
Keep the product away from humidity, water
or other liquids.
Do not store or expose your product to any
source of heat, direct sunlight, radiators,
stoves or other heat sources such as the
dashboard of your car in the summer.
Do not try to modify, repair or disassemble the
product.
Do not use a damaged product.
Do not under any circumstances use
aggressive cleaning agents, alcohol or other
chemical solutions for cleaning as they can
damage the housing or even impair the
functionality of the product.
Do not immerse the product in water or other
liquids.
ere are no serviceable parts inside the
product. Never open/disassemble it.
Keep the product out of reach of children.
Never allow children or persons with
disabilities to use electrical products without
supervision.
Make sure that children do not play with the
plastic wrapping.
¬ey may swallow it when playing and
suffocate.
Make sure children do not remove any small
parts from the product and play with them.
Charging
When using for the first time, charge the
battery to its maximum capacity. To charge,
plug the charging cable into the product
charging port. When all lights stop flashing,
charging of the charging box will be complete.
Once the earphones are placed inside the
charging box, charging of the same will begin
and a red light will light up on each. When the
red light turns off, the headset will be fully
charged.
Turning on and Pairing
e earphones, once the case is opened,
will automatically turn on. e earphones
must be connected to the device within 5
minutes, otherwise they will go into power
saving mode. To activate the pairing mode
again, simply put the earphones back in the
charging case, close it again and wait a few
seconds before reopening it, following the
above procedure again. At this point activate
the Wireless function on the device, search
for RUNBEAT, select it once identified and
connect it. You will hear the "CONNECTED"
sound when pairing is complete. If a password
is requested, enter "0000".
Automatic reconnection
Once the headset and the pairing device have
been paired before, they will be automatically
reconnected when the pairing device’s
Wireless on and within the range of each
other.
MONO/STEREO function
You can use only one earbud to listen to
music and to take calls. is function (MONO
function) is available for both earbuds. To use
this function remove one earbud from the
charging box. To switch to the stereo mode,
remove at any time the second earbud.
Viceversa to switch to the mono mode, put
back one earbud in the charging box.
Operations:
- Power on: Remove the earphones from the
charging box.
- Power off: Press Place the earphones in the
case.
- Voice Assistant: click 5 times Left or Right
- Answer Call: single click; Hang Up Call: Double
click
- Reject calls: long press 2-3 s
- Play/Pause Music: single click Left or Right
- Previous song: double click Left
- Next song: double click Right
- Increase Volume: triple click Right
- Decrease Volume: triple click Left
Auto
power
off
1. Under the connection of phones, if you
disconnect the earphone, the earphone will
auto power off in 5 minutes.
2. If you don’t connect phone the earphone
will auto power off in 5 minutes.
Pairing
left
and right earphone
If the connection from right to left is lost, put
both earphones back to the charging case.
Wait a few seconds and then pick out the both
earphones from the charging case and they
will re-connect automatically. If this procedure
does not work, disconnect the earphones
from your device, wait a few minutes, then
reconnect them (both earphones must be
placed inside the charging case). For both
procedures is necessary that the earphones
inside the charging box are in charging, so
make sure that the charging case is sufficiently
charged to guarantee the charging of the
earphones.
Maintenance
1. Do not use abrasive cleaning solvents to
clean the product;
2. Do not touch the product with any sharp
object as this will cause scratching and
damage;
3. Please keep the product away from high-
temperature, dust and humidity.
Specifications
Wireless Version: 5.3
Input: DC 5V/1A
Earphone charging time: 1.5 hours
Charging box charging time: 1.5h
Earphone battery: 50mAh, Lithium Polymer
Battery Charging Box: 600mAh, Lithium
Polymer
Microphone sensitivity: 105+/-3dB
Frequency response: 20HZ-20KHZ
Rated power: 5mW
Maximum power: 10 mW
Operating range: 10m
Play Time: 12h
Talk Time: 5h
Music Time: 3h
Earphone size: 50*30*25mm
Box dimensions: 83*59*31,5mm
Usage temperature: 0 – 40°
Weight: 70g
Maximum radiated power: <20mW
Frequency: 2,402~2,480GHZ
Package contents: Earphones, charging box,
user manual and USB-C cable
CUSTOMER’S INFORMATION FOR
RIGHT WASTE OF THIS PRODUCT
(Directive 2013/56/EU)
is marking on the product or its packaging
means that the product at the end of its life,
inlcuding the unremovable battery, must
be separated from other types of waste to
recycle it responsibly.
Safely’s use of this product is guaranteed from
the respect of this instructions manual, keep it
and carefully use it for all life of the product.
e product doesn’t need any kind of technical
maintenance, NEVER DISASSEMBLE IT.
e battery inside the product is integrated
and not replaceable. Don not try to remove
li-ion/polymer battery included in inside the
product because can produce overheat’s
danger, burning and injury. e battery must
be removed only by qualified professional
techincians, that are able to remove it without
any kind of danger and to recycle it in the
respect of the law. Users should give free end
of life product into the local separate collection
centers or to the retailer, in reason of one to
one, or free if the product size is bigger than
25 cm. Adequated waste disposal permit to
award the product to recycling, treatment
with ecofriendy compatible disposal conduce
to prevent possible harm to the environment
or human health and promote the reuse and/
or product materials recycling. Unauthorized
waste disposal of electronic product, cell and
battery from houseold user involve currency
legislation sanctions.
is product complies with the
RoHS directive 2011/65/EU –
2015/863/EU. e Product has
the CE mark and therefore complies with
the safety standards established by the
European Union.
Hereby, Esprinet SpA declares that the
product is in compliance with Directive
2014/53/EU and 2015/863/EU. e full
text of the EU declaration of conformity is
available at the following internet address:
https://xchange.esprinet.com/comp/nilox/
runbeat.pdf
e power supplied by the battery charger
must be the 5 watts required by the radio
equipment, to reach the maximum charging
speed.
Nilox® is a trademark owned by Esprinet
S.p.A.
All brands are registered trademarks of their
respective owners.
Esprinet S.p.A., via Energy Park 20,
20871 Vimercate (MB) - Italy
Made in China.
www.nilox.com
for info and contacts write to contact@
esprinet.com
Instruction manual
Sports Earphones
MODEL: RUNBEAT
Rev01 - 07.2024
EN
