Side 1/8

NSPM390 SERIES

READ AND SAVE THESE INSTRUCTIONS

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY

TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If you

have questions, contact the manufacturer at the address or tele-

phone number listed in the warranty.

2. Before servicing or cleaning unit, switch power off at service panel

and lock service panel to prevent power from being switched on

accidentally. When the service disconnecting means cannot be

locked, securely fasten a prominent warning device, such as a tag,

to the service panel.

3. Installation work and electrical wiring must be done by a qualified

person(s) in accordance with all applicable codes and standards,

including fire-rated construction codes and standards.

4. Sufficient air is needed for proper combustion and exhausting of

gases through the flue (chimney) of fuel burning equipment to pre-

vent backdrafting. Follow the heating equipment manufacturer’s

guidelines and safety standards such as those published by the Na-

tional Fire Protection Association (NFPA), and the American Soci-

ety for Heating, Refrigeration and Air Conditioning Engineers

(ASHRAE), and the local code authorities.

5. When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. Do not use this unit with any separate solid-state speed control device.

8. To reduce the risk of fire, use only metal ductwork.

9. This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

A. Never leave surface units unattended at high settings. Boilovers cause

smoking and greasy spillovers that may ignite. Heat oils slowly on

low or medium settings.

B. Always turn hood ON when cooking at high heat or when flambeing

food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef

Flambe’).

C. Clean ventilating fans frequently. Grease should not be allowed to

accumulate on fan or filter.

D. Use proper pan size. Always use cookware appropriate for the size

of the surface element.

WARNING

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT

OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:*

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal

tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS.

If the flames do not go out immediately, EVACUATE AND CALL

THE FIRE DEPARTMENT.

2. NEVER PICK UP A FLAMING PAN - You may be burned.

3. DO NOT USE WATER, including wet dishcloths or towels - violent

steam explosion will result.

4. Use an extinguisher ONLY if:

A. You know you have a Class ABC extinguisher and you already

know how to operate it.

B. The fire is small and contained in the area where it started.

C. The fire department is being called.

D. You can fight the fire with your back to an exit.

* Based on “Kitchen Fire Safety Tips” published by NFPA.

INTENDED FOR DOMESTIC COOKING ONLY

CAUTION

1. For indoor use only.

2. To reduce risk of fire and to properly exhaust air, be sure to duct air

outside. Do not vent exhaust air into spaces within walls or ceilings or

into attics, crawl spaces, or garages.

3. Take care when using cleaning agents or detergents.

4. Avoid using food products that produce flames under the Range Hood.

5. For general ventilating use only. Do not use to exhaust hazardous or

explosive materials and vapors.

6. To avoid motor bearing damage and noisy and/or unbalanced impel-

lers, keep drywall spray, construction dust, etc. off power unit.

7. Your hood motor has a thermal overload which will automatically shut

off the motor if it becomes overheated. The motor will restart when it

cools down. If the motor continues to shut off and restart, have the

hood serviced.

8. For best capture of cooking impurities, the bottom of the hood should

be a minimum of 24" and a maximum of 30" above the cooking sur-

face.

9. Two installers are recommended.

10. This product is equipped with a thermostat which may start blower

automatically. To reduce the risk of injury and to prevent power from

being switched on accidentally, switch power off at service panel and

lock or tag service panel.

11. Please read specification label on product for further information and

requirements.

POWER

MODULE

To Register this Product Visit www.Nutone.com

CAUTION

Wear safety gloves before every installation

and/or manitenance operation

CONNECT DUCTWORK

Ducted Configuration

1. Take the damper and assemble it onto the hood’s discharge

opening, pressing slightly.

2. Use 6" round metal duct to connect the discharge collar on the

hood to the ductwork above.

3. Use duct tape to make all joints secure and air tight.

Non-Ducted Recirculation Configuration

1. Connect a 6” round metal duct to the discharge opening so

that the air is sent outside the cabinet and sent back into the

room.

2. Use duct tape to make all joints secure and air tight.

NON-DUCTED RECIRCULATION FILTER

INSTALLATION

1. Remove the metal wires (Fig. 9) and discard them.

2. Install the Non-ducted recirculation filter over the grease filter and

secure it with the metal wires supplied with the Non-ducted

recirculation Filter (Fig. 6).

INSTALL THE DUCTWORK

NOTE: To reduce the risk of fire, use only metal ductwork.

1. Decide where the ductwork will run between the hood and the

outside (Refer to Figure 1).

2. A straight, short duct run will allow the hood to perform most

efficiently.

3. Long duct runs, elbows, and transitions will reduce the performance

of the hood. Use as few of them as possible. Larger ducting may

be required for best performance with longer duct runs.

4. Install a roof or wall cap. Connect round metal ductwork to cap

and work back towards hood location. Use duct tape to seal the

joints between ductwork sections.

INSTALL THE HOOD

NOTE: the hood has to be installed, inside the cabinet, at minimum

1” from the rear wall cabinet and at 3” from the front wall cabinet.

The internal height of cabinet has to be minimum 16”.

The hood should be mounted centered over the cook top burners.

1. Remove the grid by moving the 2 slide fasteners “A” forward (Fig.2).

2. Cut a hole in the bottom of the cabinet, using the dimensions shown

(Fig. 3).

3. Adjust the position of the clasping side spring by means of the

proper “B” screw according to the thickness of the bored panel to

which it is going to be anchored (Fig. 4).

4. NOTE: For installations where the Power Pack is less than 30”

above cook top, it is recommended that the Power Pack be

mounted into a metal liner or non-combustible material. This will

allow easier cleaning and provide protection to the cabinetry

(Fig.5A).

5. Insert the hood in the cabinet and lock it by means of the side

spring.

6. Insert the hood in the cabinet (Fig. 5) or metal liner (Fig. 5A) and

secure with the (4) “C” mounting sheet metal screws.

(Fig. 5 - wood bottom installation; recommended thickness 1/2”-

3/4”).

(For alternate mounting, use machine screws with washers and

nuts. This alternate mounting method needs to be done prior to

installation of metal liner).

7. In the Non-Ducted Recirculation Configuration, install the Non-

ducted recirculation Filter before replacing the grid (see section

“Non-ducted recirculation filter installation”).

8. Replace the grid.

ROOF CAP

ROUND

DUCT

WALL

CAP

6”

ROUND

ELBOW

24” TO 30” ABOVE

COOKING SURFACE

CUT A HOLE IN THE BOTTOM OF

THE CABINET

10-1/4”

19-1/2”

POWER

MODULE

FIG. 6

FIG. 1

FIG. 2 FIG. 3

NON-DUCTED

RECIRCULATION FILTER

METAL WIRES

min 7/16”

max 13/16”

FIG. 4

FIG. 5

FIG.5A

METAL LINER
