Table of Contents ............................1

Usage Notice ...................................2

Safety Information ...............................2

Precautions .........................................3

Eye Safety Warnings ..........................5

Product Features ................................5

Introduction ......................................6

Package Overview ..............................6

Product Overview ...............................7

Main Unit .............................................. 7

Control Panel ....................................... 8

Input/Output Connections .................... 9

Remote Control .................................. 10

Installation .....................................11

Connecting the Projector ..................11

Connect to Computer/Notebook ........ 11

Connect to Video Sources ................. 12

Powering the Projector On / Off ........13

Powering On the Projector ................. 13

Powering off the projector .................. 14

Warning Indicator ............................... 14

Adjusting the Projected Image ..........15

Adjusting the Projector’s Height ........15

Adjusting the Projector’s Zoom /

Focus ................................................. 16

Adjusting Projection Image Size ........ 16

User Controls ................................18

Control Panel & Remote Control ......18

Control Panel ..................................... 18

Remote Control Battery Installation ... 19

Remote Control .................................. 20

On-screen Display Menus ................24

How to operate .................................. 24

Menu Tree .......................................... 25

IMAGE ............................................... 27

IMAGE | Advanced ............................ 29

IMAGE | Advanced | Signal (RGB) ... 31

DISPLAY ............................................ 32

DISPLAY | 3D ................................... 35

SETUP ............................................... 36

SETUP | Security ............................... 38

SETUP | Audio Settings ..................... 40

SETUP | Advanced ............................ 41

OPTIONS ........................................... 42

OPTIONS | Advanced ........................ 44

OPTIONS | Lamp Settings ................. 45

OPTIONS | Optional Filter Settings ... 46

Appendices ....................................47

Troubleshooting ................................47

Replacing the Lamp ..........................53

Installing and Cleaning the

Dust Filter .........................................55

Compatibility Modes .........................56

Computer/Video/HDMI/Mac

Compatibility ...................................... 56

3D Input Video Compatibility ............. 57

RS232 Commands and Protocol

Function List .....................................58

RS232 Pin Assignments .................... 58

RS232 Protocol Function List ............ 59

Ceiling Mount Installation ..................63

Optoma Global Ofces .....................64

Regulation & Safety Notices .............66

Table of Contents

English

Usage Notice

Safety Information

The lightning ash with arrow head within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufcient

magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH

VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE

CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

Class B emissions limits

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Important Safety Instruction

1. Do not block any ventilation openings. To ensure reliable operation of

the projector and to protect from over heating, it is recommended to

install the projector in a location that does not block ventilation. As an

example, do not place the projector on a crowded coffee table, sofa,

bed, etc. Do not put the projector in an enclosure such as a book case

or a cabinet that restricts air ow.

2. Do not use the projector near water or moisture. To reduce the risk

of re and/or electric shock, do not expose the projector to rain or

moisture.

3. Do not install near heat sources such as radiators, heaters, stoves or

any other apparatus such as ampliers that emits heat.

4. Clean only with dry cloth.

5. Only use attachments/accessories specied by the manufacturer.

6. Do not use the unit if it has been physically damaged or abused.

Physical damage/abuse would be (but not limited to):

 Unit has been dropped.

 Power supply cord or plug has been damaged.

 Liquid has been spilled on to the projector.

 Projector has been exposed to rain or moisture.

 Something has fallen in the projector or something is loose inside.

Do not attempt to service the unit yourself. Opening or removing covers

may expose you to dangerous voltages or other hazards. Please call

Optoma before you send the unit for repair.

7. Do not let objects or liquids enter the projector. They may touch

dangerous voltage points and short out parts that could result in re or

electric shock.

8. See projector enclosure for safety related markings.

9. The unit should only be repaired by appropriate service personnel.

Produkt Specifikationer

Mærke:	Optoma
Kategori:	videoprojektorer
Model:	DХ346
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	314.6 mm
Dybde:	223.6 mm
Højde:	101.7 mm
Vægt:	2350 g
Brugervejledning:	Ja
Produktfarve:	Sort
Indbygget skærm:	Ingen
Produkttype:	Bærbar projektør
Wi-Fi:	Ingen
Bluetooth:	Ingen
Naturligt aspektforhold:	4:3
Understøttede videotilstande:	1080i,1080p,480i,480p,576i,576p,720p
3D:	Ja
Indbyggede højttaler(e):	Ja
Relativ luftfugtighed ved drift (H-H):	0 - 85 %
Format til analogt signal:	NTSC 3.58,NTSC 4.43,NTSC J,NTSC M,PAL,PAL 4.43,PAL B,PAL D,PAL G,PAL I,PAL M,PAL N,SECAM B,SECAM D,SECAM G,SECAM K,SECAM K1,SECAM L
Udgangseffekt (RMS):	2 W
Antal HDMI-porte:	1
DVI-port:	Ingen
Antal USB 2.0-porte:	1
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ingen
Skærmvisning (OSD):	Ja
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	225 W
Driftstemperatur (T-T):	5 - 40 °C
Markedspositionering:	Bærbar
Hurtig start guide:	Ja
Kabler inkluderet:	VGA
Batterier inkluderet:	Ja
Understøttede grafikopløsninger:	1024 x 768 (XGA),1280 x 1024 (SXGA),1600 x 1200 (UXGA),640 x 480 (VGA),800 x 600 (SVGA)
Sammensat videoindgang:	1
Understøttede billedformater:	4:3,16:9
Støjniveau:	- dB
Fjernbetjening inkluderet:	Ja
Strømkilde:	Vekselstrøm
Strømforbrug (strømbesparelse):	191 W
Placering:	Loft
DC-in-stik:	Ingen
LED-indikatorer:	Ja
Indbygget kortlæser:	Ingen
Full HD:	Ja
Antal lamper:	1 Lampe( r)
Bæretaske:	Ja
Bæredygtighedscertifikater:	RoHS
Mikrofonindgang:	Ja
Cardbus PCMCIA slot type:	Ingen
Slot til kabellås:	Ja
Driftshøjde:	0 - 3000 m
Plug and play:	Ja
Antal farver:	1.073 milliarder farver
Lyd (L, R) indgang:	2
Kontrastforhold (typisk):	18000:1
Horisontal scanningsområde:	15.3 - 91.1 kHz
HDMI-version:	1.4a
Antal VGA-porte (D-sub):	3
AC (strøm) indgang:	Ja
Kabellåseslids type:	Kensington
Lyd (L, R) udgang:	1
Garantibevis:	Ja
Zoom kapacitet:	Ja
Brændviddeområde:	21.8 - 23.98 mm
Fjernbetjeningstype:	IR
Projektor lysstyrke:	3000 ANSI lumens
Projektionsteknologi:	DLP
Projektor indbygget opløsning:	XGA (1024x768)
Skærmstørrelse kompatibilitet:	22.9 - 300 "
Projiceringsafstand:	1.2 - 12 m
Ensartethed:	80 %
Trapezkorrektion, vertikal:	-40 - 40 °
Matrix størrelse:	0.55 "
Vertikalt scanningsområde:	24 - 85 Hz
Blændeområde (F-F):	2.41 - 2.55
Forskydning:	115 %
Throw-forhold:	1.95 - 2.15:1
Zoom type:	Vejledning
RS-232-porte:	1
Levetid for lyskilde:	5000 t
Lampeeffekt:	190 W
Levetid for lyskilde (økonomisk tilstand):	6500 t
Lyskilde type:	Lampe
3D Ready:	Ja
Antal af S-video-indgange:	1
Seriel grænsefladetype:	RS-232
Optisk diskafspiller type:	Ikke inkluderet
Zoomforhold:	1.1:1
Understøttede 3D-formater:	Frame packing,Side by side,Top and bottom
Strømforbrug (økonomi tilstand):	191 W
Støjniveau (økonomisk tilstand):	29 dB
Maksimal analog opløsning:	1600 x 1200 pixel
Adgangskodebeskyttelse type:	Bruger
