Side 1/40

www.vogels.com

RISE

Motorized Display Lift

Floor-Wall Solution

2005 & 2008

Installation & User Manual

DE Produkthandbuch

FR Manuel de produit

NL Producthandleiding

CONTENTS

Important Safety Information 2

Declaration of Conformity 10

Mounting Instructions 19

User Instructions 30

Product Data Sheet 33

Checklist 35

Contact Details 40

RISE

2005 & 2008

Important Safety Information - GB

Important safety information for both

installer and user

Installer: Before starting the installation

read the safety instructions, the mounting

regulations and rest of this product

manual carefully. Failure to read, thoroughly

understand, and follow all instructions can

result in serious personal injury, damage to

equipment, or voiding of factory warranty!

It is the certified installer’s responsibility to

make sure all mounting systems/accessories

are properly assembled and installed using

the instructions provided. User: Please

carefully read the below safety

information and user manual (if included)

before using the height adjustable mount or

trolley. This ensures a proper working unit and

avoids accidents.

Electrical Safety

Connect unit to a properly grounded outlet

only. Make sure, the unit can be

immediately separated from the power

outlet. Only use unit in dry rooms, protect it

from water and other liquids. Only wipe unit

with dry cloth. Do not open lift unit. RISK OF

ELECTRIC SHOCK. There are no serviceable

parts inside. In case of dysfunction unplug

unit from power outlet and call an

authorised technical service person. Do not

overrun line cord or damage it in any other

way. Replace damaged line cords

immediately with new identical ones.

Mechanical safety

Assure installation of unit by authorized

service person only. Only use original

mounting parts provided with the system

and do not use attachments not

recommended by the manufacturer. Do

not improperly load unit: For the max. load

of unit please refer to the page with the

specification sheet in this manual. Do not

exceed: Use with heavier screens may result

in instability causing tipping over resulting in

death or serious injury! The height adjustable

feature of this unit will not function properly

if the weight exceeds the given maximum

load. Use this mounting system only for its

intended use as described in these

instructions. Do not hang on unit. VERY

HEAVY UNIT. Severe risk of injury when unit

tips over due to improper usage.

The socket connections of the unit and

the wall socket must be easily accessible.

Disconnect mains plug before moving the

product.

Always keep product’s motion path free

from obstacles. Before moving the unit up or

down assure at least a safety distance of

20 cm/ 7.9 inch from any part of the unit

to any other fitment in order to avoid

shear traps or squeezing points. In case of

accident please release operating panel.

Movement of unit will stop immediately.

Anti-Collision – Function and intended use

Collision detection is a system to detect

contact between the display lift system and

an object, in order to mitigate the effects of

the impact.

This collision detection system is intended

for protection of the display lift hardware,

however is explicitly not intended as a safety

mechanism to prevent personal injury.

Does your unit have wheels?

Only operate unit on plane and stable floors.

Move unit on plane floors only. Risk of tilting

when overrunning

floorunevennesses, door sills and similar.

VERY HEAVY UNIT. Severe risk of injury when

unit tips over.

Lock brakes of front wheels when

operation unit. Always move your trolley

with the screen in the lowest position.

The unit is not dripping or splash water

protected. Do not place objects filled with

liquids on or spray the unit. To reduce the

risk of electric shock: Always unplug the unit

from the electrical outlet before cleaning.

Mounting regulations WARNING

A correct mounting is extremely important and this is not the responsibility of Vogel’s Products. Faulty mounting may

result in injury to persons or damage to equipment. Vogel’s Products will not be responsible in any way if the product

has been mounted incorrectly.

Mounting fittings are not included with the product for reasons of safety, since the properties and bearing strength of

walls/ceilings are specific for each case. Suitable mounting fittings must be selected based on the material of the wall/

ceiling.

Obtain advice from a specialist in the field or from a specialist shop concerning the choice of mounting fittings. It is the

responsibility of the installer to ensure that the wall/ceiling can support at least four times the combined weight of the

screen/projector and bracket. The maximum load for this product is given in these mounting instructions. The

instructions for installation and use of the screen/projector must also be followed with respect to the location and

attachment of the screen/projector.

In case of technical issues please contact your installer

Produkt Specifikationer

Mærke:	Optoma
Kategori:	Ikke kategoriseret
Model:	RISE 2005
Bredde:	915 mm
Dybde:	138 mm
Højde:	1786 mm
Vægt:	28500 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	31700 g
Monteringstype:	Gulv
Nem at installere:	Ja
Bæredygtighedscertifikater:	CE, TUV
Højdejustering:	Ja
Overholdelse af bæredygtighed:	Ja
Maksimal vægtkapacitet:	120 kg
Skruer inkluderet:	Ja
Højdejusteringsområde:	806 - 1786 mm
Forbedret kabelstyring:	Ja
Maksimal skærmstørrelse kompatibilitet:	86 "
Antal understøttede skærme:	1
Minimal skærmstørrelse kompatibilitet:	- "
Montering interface kompatibilitet (min.):	- mm
Montering interface kompatibilitet (maks.):	- mm
Motoriseret:	Ja
Løftehastighed:	50 mm/sek.
