1. This trim kit can be installed into a cabinet.The cabinet opening must have the following internal
dimensions as shown in , . g 1fip 4
A vent is required at the rear of the cabinet. It should travel the full height of the cabinet and the
cabinet should not be obstructed. Minimum dimension of vent: 45 mm x 600 mm ( ).fig 1, p 4
MINIMUM INSTALLATION HEIGHT 850 MM.
2. Electrical Connections The appliance is supplied with a mains plug attached and should only
be connected into an earthed socket that has been installed according to the relevant safety
If the plug is no longer accessible after the appliance has been built into the cabinet, a dual pole
isolator must be installed to conform to the relevant safety standards.
3. Appliance shall be provided with means for disconnection from the supply mains having a contact
separation in all poles that provide full disconnection under overvoltage
must be incorporated in the xed wiring in accordance with the wiring rules and accessible.fi
4. It is essential that the cabinet is xed to the wall for stability. The shelf must be able to support a fi
5. If the microwave oven is to be removed from the kitchen cabinet and used free standing, the built
in parts must be removed, and the oven returned to its original condition. Keep these installation
instructions for future reference so the installation process can be reversed.
TAKE CARE NOT TO KINK OR TRAP THE MICROWAVE ELECTRICAL CABLE.
The diagram may vary from the actual unit and is only for your reference.
Attention .............................................................................................................................................P1
Step 1. Unpacking list .........................................................................................................................P2
Step 2. Feature diagram .....................................................................................................................P3
Step 3. Cabinet Preparation ...............................................................................................................P4
Step 4. Microwave Oven Installation ..................................................................................................P5
Step 5. Cabinet Installation............................................................................................................. P6-7
Step 6. Finishing Installation......................................................................................................... P8-10
