Thank you for purchasing this Panasonic product.

■

The Operating Instructions correspond to the rmware’s main version 4.00 and higher.

■Before operating this product, please read the instructions carefully and save this manual

for future use.

■

Before using your projector, be sure to read “Read this rst!” (

x pages 2 to 9).

TQBJ0522-2

DLPTM Projector Commercial Use

Operating Instructions

Functional Manual

ENGLISH

Model No. PT-DZ13KE

 PT-DS12KE

 PT-DW11KE

 PT-DZ10KE

The projection lens is sold separately.

2 - ENGLISH

Read this rst!

WARNING: THIS APPARATUS MUST BE EARTHED.

WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain

or moisture.

This device is not intended for use in the direct eld of view at visual display workplaces. To avoid

incommoding reexions at visual display workplaces this device must not be placed in the direct

eld of view.

The equipment is not intended for used at a video workstation in compliance BildscharbV.

The sound pressure level at the operator position is equal or less than 70 dB (A) according to ISO 7779.

WARNING:

1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.

2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualied

service personnel.

3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong

earthingtype mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you

are unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the

earthing plug.

WARNING:

This is a class A product. In a domestic environment this product may cause radio interference in which case

the user may be required to take adequate measures.

CAUTION: To assure continued compliance, follow the attached installation instructions, which include

using the provided power cord and shielded interface cables when connecting to computer or

peripheral device. If you use serial port to connect PC for external control of projector, you must

use a commercial RS-232C serial interface cable with ferrite core. Any unauthorized changes or

modications to this equipment will void the user’s authority to operate.

This is a device to project images onto a screen, etc., and is not intended for use as indoor lighting in a

domestic environment.

Directive 2009/125/EC

Importer’s name and address within the European Union

Panasonic Marketing Europe GmbH

Panasonic Testing Center

Winsbergring 15, 22525 Hamburg, Germany

Product information (for Turkey only)

EEE Yönetmeliğine Uygundur.

EEE Complies with Directive of Turkey.

Produkt Specifikationer

Mærke:	Panasonic
Kategori:	videoprojektorer
Model:	PT-DW11KE
Vekselstrømsindgangsspænding:	120 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	530 mm
Dybde:	548.5 mm
Vægt:	24000 g
Produktfarve:	Sort
Lampe type:	UHM
Produkttype:	Projektor til stort spillested
Wi-Fi:	Ingen
Bluetooth:	Ingen
Naturligt aspektforhold:	16:10
Understøttede videotilstande:	1080i,1080p,480i,480p,576i,576p,720p
Relativ luftfugtighed ved drift (H-H):	10 - 80 %
Format til analogt signal:	NTSC,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM
Antal HDMI-porte:	1
HDCP:	Ja
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
Strømforbrug (standby):	0.2 W
Strømforbrug (typisk):	1000 W
Driftstemperatur (T-T):	0 - 45 °C
Ethernet LAN-datahastigheder:	10,100 Mbit/s
Batterier inkluderet:	Ja
Understøttede grafikopløsninger:	1920 x 1200 (WUXGA),640 x 480 (VGA)
Sammensat videoindgang:	1
Understøttede billedformater:	16:10
Støjniveau:	45 dB
Fjernbetjening inkluderet:	Ja
Strømkilde:	Vekselstrøm
Placering:	Desktop,Ceiling
Indbygget kortlæser:	Ingen
Full HD:	Ja
Antal lamper:	2 Lampe( r)
AUX-indgang:	Ingen
Cardbus PCMCIA slot type:	Ingen
Slot til kabellås:	Ja
Kontrastforhold (typisk):	10000:1
Horisontal scanningsområde:	15 - 100 kHz
Antal VGA-porte (D-sub):	1
Brændviddeområde:	- mm
Tidsforskydning:	Ingen
Fjernbetjeningstype:	IR
Projektor lysstyrke:	12000 ANSI lumens
Projektionsteknologi:	DLP
Projektor indbygget opløsning:	WUXGA (1920x1200)
Skærmstørrelse kompatibilitet:	70 - 1000 "
Projiceringsafstand:	- m
Ensartethed:	90 %
Trapezkorrektion, vertikal:	-40 - 40 °
Matrix størrelse:	0.96 "
Vertikalt scanningsområde:	24 - 120 Hz
RS-232-porte:	2
Levetid for lyskilde:	- t
Lampeeffekt:	380 W
Lyskilde type:	Lampe
Seriel grænsefladetype:	RS-232
Optisk diskafspiller type:	Ikke inkluderet
Trapezkorrektion, horisontal:	-15 - 15 °
Matrix-type:	3-panel (p-Si TFT aktiv)
Støjniveau (økonomisk tilstand):	37 dB
Horisontalt område for optisk linseforskydning:	-20 - 20 %
Vandret område for optisk linseforskydning:	-55 - 55 %
Dot clock scanningsfrekvens:	20 Mhz
Progressiv scanning output:	Ja
