STEREO CASSETTE PLAYER
RQ-SX52
RQ-SX32
Operating Instructions
Bedienungsanleitung
Istruzioni per l’uso
Mode d’emploi
Instrucciones de funcionamiento
Gebruiksaanwijzing
Bruksanvisning
Betjeningsvejledning
Návod k obsluze
Instrukcja obsìugi
Nhctpykunr go ˙kcgjyataunn
Note:
The illustrations show .
EB on the packaging indicates the United Kingdom.
Before connecting, operating or adjusting this product, please
read these instructions completely. Please keep this manual for
future reference.
Niniejsza instrukcja zostaìa opracowana na podstawie oryginal-
nej publikacji firmy MATSUSHITA ELECTRIC INDUSTRIAL
CO., LTD.
RQ-SX52
EG EB
Matsushita Electric Industrial Co., Ltd. ptuvrw
Osaka 542-8588, Japan
sxz{y
RQTT0392-E
F1200KB0
First of all recharge.
Zuerst aufladen.
Prima ricaricare.
D’abord recharger.
Cargue primero la batería.
Laad eerst de batterij op.
Ladda först upp batteriet.
Oplad først.
Nejprve nabijte akumulátorovou baterii.
Najpierw naìaduj akumulator.
Cha≠aja gepeÎaprlnte.
≥For UK, the shape of
the charger is different.
RFEV330P-HT
RQ-SX52
RFEV333P-HT
RQ-SX32
RP-BP62EYDRFCT0005-HRFAT0002-H
RFEB119B-U
(for UK)
RFEB110E-U
(for Continental Europe)
≥Use numbers indicated when asking for replacement parts.
Specifications
∫ CASSETTE PLAYER
Track system: 4 track, 2 channel, stereo
Frequency range
(Normal/High/Metal): 40–18000 Hz (j6 dB)
∫ GENERAL
Output jack: HEADPHONES; 80 ≠
Power output: 1.5 mWi1.5 mW (RMS…max.)
Power requirement:
Rechargeable battery; DC 1.2 V (included rechargeable battery)
Battery; DC 1.5 V (one R6/LR6, AA, UM-3 battery)
Dimensions (WtHtD): 108.8k75.0k17.8 mm
109.2k75.2k18.2 mm
Mass: 155 g
(with rechargeable battery)
150.8 g
(with rechargeable battery)
∫ CHARGER
Input: AC 220–230 V (for Continental Europe)/
AC 220–240 V (for UK),
50 Hz, 4 W
Output: DC 1.2 V, 175 mA
Play time:
[Approximate operating time in hours (in hold mode, at 25 oC, on a flat, stable
surface).]
RQ-SX32
RFEV033P-SS
RQ-SX52
(A) When the rechargeable battery (included) is fully recharged [requires
4 hours]
≥Operating conditions may reduce the operating times shown above.
Note
Specifications are subject to change without notice.
Mass and dimensions are approximate.
Battery type
Rechargeable (A)
Panasonic alkaline
Both together (A)
17
58
75
RQ-SX52
15
50
65
RQ-SX32
Tape
RQ-SX52
RQ-SX52
RQ-SX32
RQ-SX52
RQ-SX52
RQ-SX32
