Side 1/99

Operating Instructions

Functional Manual

FULL HD LCD Display For business use

Model No. TH-55AF1U

55-inch model

TH-49AF1U

49-inch model

TH-42AF1U

42-inch model

TH-55AF1W

55-inch model

TH-49AF1W

49-inch model

TH-42AF1W

42-inch model

English Please read these instructions before operating your set

and retain them for future reference.

* This manual is common to all the models regardless of suffixes of the

model number.

U : for US, Canada and Mexico

W : for EU, CIS, South East Asia and Middle East Asia

DPQP1005ZA/X1

English

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that

you will have many years of enjoyment from your new LCD

Display.

To obtain maximum benefit from your set, please read these

Instructions before making any adjustments, and retain them

for future reference.

Retain your purchase receipt also, and note down the model

number and serial number of your set in the space provided

on the rear cover of these instructions.

Visit our Panasonic Web Site http://panasonic.com

Table of Contents

Before use

● Illustrations and screens in this Operating Instructions

are images for illustration purposes, and may be

different from the actual ones.

● Descriptive illustrations in this Operating Instructions

are created mainly based on the 55-inch model.

Important Safety Instructions 5

..........................

FCC STATEMENT 6

..............................................

Important Safety Notice 7

...................................

Safety Precautions 9

...........................................

Precautions for use 12 ........................................

Accessories 16

....................................................

Accessories Supply 16 ··········································

Remote Control Batteries 17 ··································

Kensington security 17 .......................................

Connections 18

....................................................

AC cord connection and fixing 18

····························

Cable fixing 18 ····················································

Video equipment connection 19

······························

Before connecting 20 ············································

HDMI 1 and HDMI 2 terminals connection 21

·············

DVI-D IN / DVI-D OUT terminal connection 22 ···········

PC IN terminal connection 23

·································

VIDEO IN terminal connection 24 ····························

COMPONENT/RGB IN terminal connection··········· 25

SERIAL terminal connection 25

·······························

IR IN/IR OUT terminal connection 28 ·······················

AUDIO OUT terminal connection 28

·························

USB terminal connection 28 ···································

Using microSD card 29 ·········································

USB (OpenPort PLATFORM) terminal connection 30 ··

Micro-USB terminal connection 31

···························

Identifying Controls 32

........................................

Main unit 32 ························································

Remote Control Transmitter ·······························

Basic Controls 35

................................................

Selecting the input signal 37

···································

RECALL························································· 38

Volume Adjustment ·········································· 38

Sound mute On / Off 38

·········································

OFF TIMER ····················································

Produkt Specifikationer

Mærke:	Panasonic
Kategori:	Skærm
Model:	TH-42AF1U
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	947 mm
Dybde:	72 mm
Højde:	541 mm
Vægt:	15600 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	21000 g
Pakkedybde:	203 mm
Pakkebredde:	1123 mm
Pakkehøjde:	743 mm
Skærm diagonal:	42 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ingen
Kompatible hukommelseskort:	MicroSD (TransFlash),MicroSDHC
Wi-Fi:	Ja
HD-type:	Fuld HD
Skærmteknologi:	LED
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	500 cd/m²
Responstid:	8 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm diagonal (metrisk):	106.4 cm
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 80 %
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
HDCP:	Ja
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
Understøttede videoformater:	AVC,H.263,H.264,MPEG2,MPEG4,VP8,WMV
Understøttede lydformater:	AAC,AMR,MP3,OGG,WMA
VESA montering:	Ja
Panel montering grænseflade:	200 x 200 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	110 W
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Strømforbrug (slukket):	0.3 W
Kabler inkluderet:	Vekselstrøm
Batterier inkluderet:	Ja
Operativsystem installeret:	Android 4.4
Understøttede billedformater:	JPG
Fjernbetjening inkluderet:	Ja
Impedens:	8 ohm (Ω)
Certificering:	EC 60950-1:2005 + Am 1:2009 + Am 2:2013\nEN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, AS/NZS 60950.1:2011 Inc A, EN55022:2010+AC:2011 A, EN55024:2010, EN61000-3-2:2014, EN61000-3-3:2013, AS/NZS CISPR22:2009 + A1:2010
Kabellængde:	2 m
Indbygget kortlæser:	Ja
Antal indbyggede højttalere:	2
Pc lydindgang:	Ja
USB version:	2.0
Antal USB-porte:	4
Processorfrekvens:	1 GHz
Processorserie:	ARM Cortex
Driftshøjde:	0 - 2800 m
Processormodel:	Cortex-A9
Intern lagerkapacitet:	8 GB
Lyd (L, R) indgang:	1
Kontrastforhold (typisk):	1300:1
Kontrastforhold (dynamisk):	50000:1
Pixel pitch:	- mm
Hældningsvinkelområde:	0 - 45 °
USB-stik type:	Micro-USB B,USB Type-A
TV-tuner, integreret:	Ingen
Aktiv skærmområde (B x H):	927 x 521 mm
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
Hældningsindstilling:	Ja
Fjernbetjening (IR) indgang:	1
Fjernbetjening (IR) udgang:	1
Panel levetid:	60000 t
Driftstimer (timer/dage):	24/7
Panellås:	Ja
Computersystem:	Ja
Multi-display understøttes:	Ja
Antal DVI-D-porte:	2
Strømstyring:	Ja
Computersystem type:	System på chip (SoC)
Batteri til fjernbetjening:	AAA
Mini VGA (D-Sub) indgangsporte:	1
