Side 1/105

Operating Instructions

Functional Manual

FULL HD LCD Display For business use

Model No. TH-55SF1HU

55-inch model

TH-49SF1HU

49-inch model

TH-42SF1HU

42-inch model

TH-55SF1HW

55-inch model

TH-49SF1HW

49-inch model

TH-42SF1HW

42-inch model

English Please read these instructions before operating your set

and retain them for future reference.

* This manual is common to all the models regardless of suffixes of the

model number.

U : for US, Canada and Mexico

W : for EU, CIS, South East Asia and Middle East Asia

DPQP1107ZA

English

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that

you will have many years of enjoyment from your new LCD

Display.

To obtain maximum benefit from your set, please read these

Instructions before making any adjustments, and retain them

for future reference.

Retain your purchase receipt also, and note down the model

number and serial number of your set in the space provided

on the rear cover of these instructions.

Visit our Panasonic Web Site http://panasonic.com

Table of Contents

Before use

● Illustrations and screens in this Operating Instructions

are images for illustration purposes, and may be

different from the actual ones.

● Descriptive illustrations in this Operating Instructions

are created mainly based on the 55-inch model.

Important Safety Instructions 4

..........................

FCC STATEMENT 5

..............................................

Important Safety Notice 6

...................................

Safety Precautions 7

...........................................

Precautions for use 10 ........................................

Feature of This Unit 12

........................................

Accessories 12

....................................................

Accessories Supply 12 ··········································

Remote Control Batteries 13 ··································

Kensington security 13 .......................................

Connections 14

....................................................

AC cord connection and fixing 14

····························

Cable fixing 14 ····················································

Video equipment connection 15

······························

Before connecting 16 ············································

HDMI 1 and HDMI 2 terminals connection 17

·············

DVI-D IN / DVI-D OUT terminal connection 18 ···········

PC IN terminal connection 19

·································

VIDEO IN terminal connection 20 ····························

COMPONENT/RGB IN terminal connection··········· 21

SERIAL terminal connection 21

·······························

IR IN/IR OUT terminal connection 24 ·······················

AUDIO OUT terminal connection 24

·························

USB terminal connection 25 ···································

DIGITAL LINK terminal connection

·························· 26

Identifying Controls 27

........................................

Main Unit 27 ·······················································

Remote Control Transmitter ·······························

Basic Controls 29

................................................

Selecting the input signal 31

···································

RECALL························································· 31

Volume Adjustment ·········································· 32

Sound mute On / Off 32

·········································

OFF TIMER ····················································

Produkt Specifikationer

Mærke:	Panasonic
Kategori:	Skærm
Model:	TH-55SF1HU
Vekselstrømsindgangsspænding:	110 - 127 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	1229 mm
Dybde:	72 mm
Højde:	699 mm
Vægt:	24900 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	33000 g
Pakkedybde:	922 mm
Pakkebredde:	1444 mm
Pakkehøjde:	223 mm
Skærm diagonal:	54.6 "
Skærmopløsning:	1920 x 1080 pixel
USB-port:	Ja
HD-type:	Fuld HD
Skærmteknologi:	LED
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	700 cd/m²
Responstid:	8 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Understøttede videotilstande:	1080p
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 80 %
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
HDCP:	Ja
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
VESA montering:	Ja
Panel montering grænseflade:	400 x 400 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	190 W
Driftstemperatur (T-T):	0 - 40 °C
Strømforbrug (slukket):	0.3 W
Kabler inkluderet:	Vekselstrøm
Batterier inkluderet:	Ja
Understøttede grafikopløsninger:	1920 x 1080 (HD 1080)
Fjernbetjening inkluderet:	Ja
Impedens:	8 ohm (Ω)
Antal indbyggede højttalere:	2
Pc lydindgang:	Ja
Antal USB-porte:	1
Driftshøjde:	0 - 2800 m
Skærmoverflade:	Mat
Kontrastforhold (typisk):	1300:1
Kontrastforhold (dynamisk):	50000:1
Pixel pitch:	- mm
Aktiv skærmområde (B x H):	1209 x 680 mm
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
Hældningsindstilling:	Ja
Fjernbetjening (IR) indgang:	1
Fjernbetjening (IR) udgang:	1
Panel levetid:	60000 t
Driftstimer (timer/dage):	24/7
Multi-display understøttes:	Ja
Antal DVI-D-porte:	2
Facet bredde (bund):	6.3 mm
Facet bredde (øverste):	6.3 mm
Orientering:	Horisontal/vertikal
Facet bredde (side):	6.3 mm
