Side 1/129

*Actual resolution: 3840 × 2160p

Operating Instructions

Functional Manual

UHD LCD Display For business use

Model No. TH-86EQ1W

86-inch model

TH-75EQ1W

75-inch model

TH-65EQ1U TH-65EQ1W

65-inch model

TH-55EQ1U TH-55EQ1W

55-inch model

TH-50EQ1U TH-50EQ1W

50-inch model

TH-43EQ1U TH-43EQ1W

43-inch model

English Please read these instructions before operating your set

and retain them for future reference.

DPQP1242ZA/X1

* This manual is common to all the models regardless of suffixes of the

model number.

English

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that

you will have many years of enjoyment from your new LCD

Display.

To obtain maximum benefit from your set, please read these

Instructions before making any adjustments, and retain them

for future reference.

Retain your purchase receipt also, and note down the model

number and serial number of your set in the space provided

on the rear cover of these instructions.

Visit our Panasonic Web Site

https://panasonic.net/cns/prodisplays/

Table of Contents

Before use

● Illustrations and screens in this Operating Instructions

are images for illustration purposes, and may be

different from the actual ones.

● Descriptive illustrations in this Operating Instructions

are created mainly based on the 55-inch model.

Important Safety Instructions 4 ..........................

FCC STATEMENT 5 ..............................................

Important Safety Notice 6 ...................................

Safety Precautions 8 ...........................................

Precautions for use ........................................ 11

Accessories 13 ....................................................

Accessories Supply 13 ··········································

Remote Control Batteries 14 ··································

Attaching the USB Memory Cover 15 ·······················

Cautions when moving 15 .................................

Eyebolt ............................................................ 16

Connections 17 ....................................................

AC cord connection and fixing / Cable fixing 17 ··········

Video equipment connection 19 ······························

Before connecting 20 ············································

HDMI 1 and HDMI 2 terminals connection 20 ·············

DVI-D IN terminal connection 21 ·····························

PC IN terminal connection 22 ·································

AV IN terminal connection 23 ··································

SERIAL IN terminal connection 24 ···························

IR IN / IR OUT terminal connection 25 ······················

AUDIO OUT terminal connection 26 ·························

USB terminal connection 26 ···································

Identifying Controls 28 ........................................

Display 28 ··························································

Remote Control Transmitter ······························· 30

Basic Controls 31 ................................................

Selecting the input signal 33 ···································

RECALL························································· 33

Volume Adjustment ·········································· 34

Sound mute On / Off 34 ·········································

OFF TIMER ···················································· 34

ASPECT Controls 35 ...........................................

Digital ZOOM 36 ...................................................

On-Screen Menu Displays 37 .............................

Adjusting Position 39 ..........................................

Auto setup 39 ······················································

Produkt Specifikationer

Mærke:	Panasonic
Kategori:	Skærm
Model:	TH-65EQ1W
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	1459 mm
Dybde:	82 mm
Højde:	835 mm
Vægt:	27000 g
Produktfarve:	Sort
Pakkevægt:	38000 g
Pakkedybde:	280 mm
Pakkebredde:	1655 mm
Pakkehøjde:	1078 mm
Skærm diagonal:	65 "
Skærmopløsning:	3840 x 2160 pixel
Berøringsskærm:	Ingen
USB-port:	Ja
HD-type:	4K Ultra HD
Skærmteknologi:	VA
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	350 cd/m²
Responstid:	8 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm diagonal (metrisk):	163.9 cm
LED-baggrundsbelysning type:	Direct-LED
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 80 %
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
HDCP:	Ja
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Browsing:	Ja
VESA montering:	Ja
Panel montering grænseflade:	400 x 400 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	185 W
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Strømforbrug (slukket):	0.3 W
Kabler inkluderet:	Vekselstrøm
Batterier inkluderet:	Ja
Sammensat videoindgang:	1
Fjernbetjening inkluderet:	Ja
Antal indbyggede højttalere:	2
Understøttet placering:	Indendørs
Antal USB-porte:	1
Formål:	Universel
Vis antal farver:	1.06 milliarder farver
Lyd (L, R) indgang:	1
Kontrastforhold (typisk):	4000:1
Kontrastforhold (dynamisk):	50000:1
Lyd (L, R) udgang:	1
Aktiv skærmområde (B x H):	1428 x 803 mm
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
HDCP-version:	2.2
Fjernbetjening (IR) indgang:	1
Fjernbetjening (IR) udgang:	1
Driftstimer (timer/dage):	18/7
RS-232C:	Ja
Multi-display understøttes:	Ja
Antal DVI-D-porte:	1
Facet bredde (bund):	14.5 mm
Facet bredde (øverste):	13.5 mm
Orientering:	Horisontal/vertikal
Facet bredde (side):	13.5 mm
