Panasonic WV-CW244 Manual

Panasonic Overvågningskamera WV-CW244

Læs gratis den danske manual til Panasonic WV-CW244 (3 sider) i kategorien Overvågningskamera. Denne vejledning er vurderet som hjælpsom af 24 personer og har en gennemsnitlig bedømmelse på 3.7 stjerner ud af 12.5 anmeldelser. Har du et spørgsmål om Panasonic WV-CW244, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/3
T h e E a s y t o I n s t a l l , V a n d a l P r o o f , W e a t h e r P r o o f ,
a n d C o s t E f f e c t i v e C a m e r a S o l u t i o n
PRELIMINARY
Vandal Proof Color Cameras
WV-CW244 Series
R
For ceilings and walls For existing junction boxes
Flush Mount Type
WV-CW244F
Surface Mount Type
WV-CW244S
These high-performance cameras are tough enough
Panasonic announces the new WV-CW244 Series of basic vandal proof cameras. Inside their com
The optional heater unit allows them to be used under eaves outdoors as well as inside, in extreme col
The die cast aluminum body
Withstands Severe Shocks
The body is die cast aluminum, the
dome 3.5mm thick polycarbonate,
and the lens unit is spring-mounted to
protect the camera from shocks.
IP66 standard
Impervious to Rain and Wind
Dust and moisture resistance meet
IP66 international standards, allowing
use under eaves outdoors as well as
indoors.
Heater unit: WV-CW3H (Optional)
Ideal for Extreme Temperatures
The optional heater unit adjusts auto-
matically to cold or extreme tempera-
ture fluctuations, helping to prevent
dew condensation.
2x Variable Focus Lens
A 2x zoom lens with a focal length that
varies from 3.8 to 8.0 mm is standard equip-
ment, ensuring the best possible image of
the spot under surveillance.
High Sensitivity in Lighting
as Low as 1lx (0.1fc)
Minimal lighting required is 2.4lx (0.24fc)
when using the standard smoke-colored
dome. When equipped with the optional
WV-CW2C clear dome cover, these ultra-
sensitive cameras work well in light as low
as 1lx (0.1fc), making it
possible to obtain clear
color images in darkened
spaces.
Replaceable Lenses
The standard lens can be removed and
replaced with any CS-mount lens.
480-Line Horizontal Resolution
Using a 1/3-type 768 (H) x 494 (V) pixel
CCD, these cameras deliver razor sharp
images with 480 lines of horizontal resolution.
Loaded With Outstanding
Compensation and Correction
Features
These cameras come equipped with a full
range of Back-Light Compensation (BLC),
Electronic Light Control (ELC), Aperture
Correction, and Auto Tracing White Balance
(ATW) features, enabling them to produce
clear, color images in entrances, windows,
and other strongly backlit environments.
Multi-Channel Camera System
Compatible
When installed with an AC 24-volt power
source, Internal, Line-Lock, and VD2 chan-
nels can be used simultaneously, making it
simple to configure multi-channel systems
using multiple cameras.
Current WV-CW244 Series
Possible
Installation
Optional Clear Dome Cover
WV-CW2C

Produkt Specifikationer

Mærke: Panasonic
Kategori: Overvågningskamera
Model: WV-CW244
