SINGLE-ZONE DUCTLESS
MINI-SPLIT SYSTEM
OWNER’S MANUAL
MODELS: 3PAMSH30B-SZW, 3PAMSH30B-SZO, 3PAMSH36B-SZW, 3PAMSH36B-SZO
2 3
TABLE OF CONTENTS
IMPORTANT NOTE: Please check the applicable models, technical data, F-GAS data, and manufacturer
information on the indoor and outdoor product stickers before installation.
SAFETY INSTRUCTIONS ................................................................................................................... 3
PREPARATION BEFORE USE ............................................................................................................ 4
PRESET ............................................................................................................................................................................................. 4
SAFEGUARDING THE ENVIRONMENT .................................................................................................................................. 4
INSTALLATION INSTRUCTIONS ...................................................................................................... 6
INSTALLATION DIAGRAM .......................................................................................................................................................... 6
BEST INSTALLATION PRACTICES .......................................................................................................................................... 6
BOX PART BREAKDOWN ........................................................................................................................................................... 7
SUGGESTED TOOLS ................................................................................................................................................................... 7
SITE INSTRUCTIONS ................................................................................................................................................................... 8
INDOOR UNIT INSTALLATION .................................................................................................................................................. 9
OUTDOOR UNIT INSTALLATION ...........................................................................................................................................14
POWER AND WIRING ................................................................................................................................................................15
WIRING DIAGRAM.......................................................................................................................................................................16
EVACUATION INSTRUCTIONS ...............................................................................................................................................17
START-UP ......................................................................................................................................................................................17
CARE AND MAINTENANCE .............................................................................................................18
FRONT PANEL MAINTENANCE .............................................................................................................................................18
AIR FILTER MAINTENANCE .....................................................................................................................................................18
PROTECTION ......................................................................................................................................19
NOISE POLLUTION ....................................................................................................................................................................19
FEATURES OF PROTECTOR ...................................................................................................................................................19
FEATURES OF HEATING MODE .............................................................................................................................................19
ENERGY SAVING TIPS ......................................................................................................................20
TROUBLESHOOTING........................................................................................................................21
IDENTIFICATION OF PARTS ...........................................................................................................22
INDOOR UNIT ...............................................................................................................................................................................22
OUTDOOR UNIT ..........................................................................................................................................................................22
DISPLAY INTRODUCTION ...............................................................................................................23
DISPLAY SCREEN .......................................................................................................................................................................23
EMERGENCY BUTTON ..............................................................................................................................................................23
SAFETY INSTRUCTIONS
To guarantee the unit works normally, please
read the manual carefully before installation,
and try to install strictly according to this
manual.
Do not let air enter the refrigeration system
or discharge refrigerant when moving the air
conditioner.
Properly ground the air conditioner.
Check the connecting cables and pipes
carefully, make sure they are correct and
rm before connecting the power of the air
conditioner.
There must be an electrical disconnect
switch.
After installing, the consumer must operate
the air conditioner correctly according
to this manual, keep a suitable storage
for maintenance and moving of the air
conditioner in the future.
The Fuse of the unit:
Model Max Fuse
9K(115V)
Max Fuse is
located on
outdoor unit
product sticker.
12K(115V)
9K-12K(208/230V)
18K(208/230V)
24K-36K(208/230V)
A residual current device (RCD) with the rating
of above 10mA shall be incorporated in the
xed wiring according to the national rule.
Warning: Risk of electric shock can cause
injury or death: Disconnect all remote electric
power supplies before servicing.
The best length of the connecting pipe
between the indoor unit and outdoor unit is
less than 24.6ft (7.5 meters). It will aect the
eciency of the air conditioner if the distance
longer than that length.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
The batteries in remote control must be
recycled or disposed of properly. Disposal
of Scrap Batteries --- Please discard the
batteries as sorted municipal waste at the
accessible collection point.
If the appliance is xed wiring, the appliance
must be tted with means for disconnection
from the supply mains having a contact
separation in all poles that provide full
disconnection under over voltage category
III conditions, and these means must be
incorporated in the xed wiring in accordance
with the wiring rules.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order to
avoid a hazard.
The appliance shall be installed in accordance
with local electrical safety regulations and
National Electrical Codes (NEC).
The air conditioner must be installed by
professional or qualied persons.
The appliance shall not be installed in the
laundry room.
Regarding to installation, please refer to
section “Installation instructions”.
Regarding to maintenance, please refer to
section “Care and Maintenance”.
