MULTI-ZONE QUICK CONNECT

DUCTLESS MINI-SPLIT SYSTEM

MODELS: 3PAMSHHQC18-MZ02 / 3PAMSHHQC24-MZ03

OWNER’S MANUAL

SAFETY & PRECAUTIONS

CONTINUEDCONTINUED

HEADLINE

(Continued)

Safety Instructions ..............................................................................................................................4

Safety Precautions .............................................................................................................................5

Preparation Before Use ......................................................................................................................7

Parts Breakdown By Box ...................................................................................................................8

Informational Quick Guide ..................................................................................................................9

CONTENTS

IMPORTANT NOTE: Read the manual carefully. Make sure to save this manual for future reference.

Illustrations in this manual are for explanatory purposes only, your actual product may look slightly

dierent.

STEP 1: Marking the Wall (Using Template) .......................................................................... 16

STEP 2: Installing the Wall Bracket ....................................................................................... 17

STEP 3: Drilling the Line Set Bundle Hole ............................................................................ 18

STEP 4: Installing the Wall Unit ............................................................................................. 18

STEP 5: Securing the Outdoor Unit .................................................................................. 19

STEP 6: Installing a Drain Joint (Optional) ........................................................................ 20

STEP 7: Installing the Line Set, Opening Unit Valve Caps ................................................ 22

STEP 8: Electrical Connections ........................................................................................ 26

STEP 9: Connecting the Drain Tube .................................................................................. 30

STEP 10: Turning on the Wall Unit .................................................................................... 30

STEP 11: Checking for Leaks ........................................................................................... 30

Maintenance ..................................................................................................................................... 31

Protection .........................................................................................................................................32

Troubleshooting ................................................................................................................................ 33

Identication of Parts .......................................................................................................................34

Display Introduction .........................................................................................................................35

INSTALLATION INSTRUCTIONS

NOTE: For detailed remote control instructions, see the Remote Control Manual.
