Side 1/4

Coaxial loudSpeaker Manual

Manuel de Coaxial

Features:

Models: RX4CX, RX46CX, RX5CX RX57CX, RX65CX, RX69CX

• -Advancedlaminatingprocessproducesexcellentsti󰘯nesstoweightratio,superiordampingqualitiesLAMINATE-TREATED PAPER CONE

• -Excellentreproductionofhighfrequencies19mm BALANCED DRIVE MYLAR TWEETER

• -Hightemperaturelight-weightvoicecoilstructureforincreasedsensitivityPOLYMIDE VOICE COIL FORMER

• -PremiumdesignforexcellentsensitivityandlongtermreliabilityTRIPLE-LAYER UV TREATED FOAM SURROUND

• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment

Coaxial Speaker Owner’s Manual

RX4CX RX46CX RX5CX RX57CX RX65CX RX69CX

RMSPowerHandling(watts) 40W 40W 40W 50W 50W 60W

PeakPowerHandling(watts) 80W 80W 80W 100W 100W 120W

Impedance(ohms) 4 4 4 4 4 4

CutOutDimension(mm)/in. (93)3.7 (143X88)5.6X3.5 (120)4.75 (188X131)7.4X5.2 (144)5.7 (221X154)8.7X6.1

MountingDepth(mm)/in. (50)2.0 (51.5)2.1 (55)2.2 (71)2.8 (64)2.5 (76)3.0

BASIC INSTALLATION

SelectingtheplacementofyournewRXCoaxialspeakerscouldbeaseasyas

usingtheexistingfactorylocationsormayrequireyoutocreateanewlocation.

Speakerplacementinthedoor,dash,orreardeckisthemostcommon.See

yourlocalPhoenixGoldDealerforadditionallocationandmountingassistance.

DOORS/REARDECK

1.Manyvehiclesalreadyhavefactorylocations(Figure1)tohousethe“DROP

IN”featureoftheRXCoaxialspeakers.Ifnoexistinglocationsareavailable

orarenotused,checkthedesiredlocationforadequatecutoutareaand

anydepthobstructions.Makesuretoallowsu󰘲cientclearanceforwindow

tracks,structuralbraces,trunklidsprings,etc.

2.Assumingenoughareaanddepthisavailable,usetheprovidedtemplate

andtracethespeakercutoutandmountingholesontothesurfaceofthe

mountinglocation.

3.Ifthemountingsurfaceisnotstructurallystrongenoughtoaccommodate

screws,(i.e.plastic,cardboard)usetheprovidedspeedclipswhichwillact

asanutforthesuppliedscrews.

4.Alwaysprovidewaterprotection,ifnotsuppliedinthevehicle.Wesuggest

usingarainshieldorequivalent.Ifindoubt,pleasecontactyour

PhoenixGoldDealer.

SPEAKERINSTALLATIONWITHOUTGRILL

PhoenixGoldhasprovidedafoammountinggasket.Wheninstallingyour

newcomponentspeakersinafactorylocationmakesuretousethefoam

mountinggasketasshownin󰘰gure1.Forreversemountedspeakersplacethe

foamgasketinfrontofthespeaker.ThiswillensureanairtightsealforyourR

speakers.

Formorecustomapplications,orcaseswherethefactorygrillwillnotbeused,

ahighexcursionprotectivegrillhasbeenprovided.Wheninstallingyournew

componentspeakerswiththeprovidedRXgrilluse󰘰gure2.

SPECIFICATIONS: Duetocontinualproductimprovement,allspeci󰘰cationssubjecttochangewithoutnotice.

Figure 1

Mountingthespeakerinafactorylocation.

Figure 2

Mountingthespeakerinacustomapplication.
