Side 1/8

Models: Z4CX - Z5CX - Z65CX - Z46CX - Z57CX - Z69CX

Z-Series

Coaxial Speakers

Z-Series Haut-parleurs coaxiaux

Z-Series Altavoces Coaxiales

Shallow Mount Design - Flush prole tweeter and a compact basket design for easy installation

Z-Series Cone - High-quality polypropylene cone material for great sounding audio

Butyl Rubber Surround - Excellent durability for prolonged performance and improved lateral

cone stability

Ferrouid Filled Tweeter - Enables enhanced thermal contact for improved reliability and

optimum damping for the voice coil

Design à faible profondeur - Tweeters à prol afeurant et conception compacte pour faciliter

l’installation

Cone de la série Z - Matériau conique en polypropylène d’excellente qualité pour un son parfait

Haut parleur en caoutchouc Butyle - Excellente durabilité pour une performance prolongée et une

meilleure stabilité du cône latéral

Tweeters uides Ferro - Permet un contact thermique amélioré pour une meilleure abilité et un

amortissement optimal pour la bobine mobile

Diseño Bajo del Montaje - Altavoces de Agudos de Alto Perl, con un diseño compacto de cesta

para una instalación sencilla

Cono de Series Z - Material de Cono de Polipropileno de Alta Calidad para un Gran Sistema

de Sonido

Caucho Butílico - Excelente durabilidad para un rendimiento prolongado y una mejor estabilidad

del cono lateral

Altavoces de Agudos recubiertos de Ferrouido - Permite el contacto térmico mejorado para una

mayor abilidad y óptima amortiguación de la bobina de voz

CARACTERÍSTICAS

CARACTÉRISTIQUES

FEATURES

Z-Series Coaxial Speakers

SPECIFICATION Z4CX Z5CX Z65CX

Peak Power (watts) 120 Watts 140 Watts 160 Watts

Rated Power (watts 30 Watts 35 Watts 40 Watts

Frequency Response 99Hz-20KHz 78Hz-20KHz 75Hz-20KHz

Impedance 4 Ohm 4 Ohm 4 Ohm

Sensitivity 86dB 86dB 87dB

Cone Material Polypropylene Polypropylene Polypropylene

Tweeter PEI PEI PEI

Mounting Depth 43mm (1-11/16”) 44mm (1-3/4”) 46mm (1-13/16”)

Mounting Diameter 103 mm (4-1/16”) 118mm (4-5/8”) 126mm (5”)

Z46CX Z57CX Z69CX

Peak Power (watts) 120 Watts 140 Watts 220 Watts

Rated Power (watts) 30 Watts 35 Watts 55 Watts

Frequency Response 120Hz-20KHz 71Hz-20KHz 85HZ-20KHz

Impedance 4 Ohm 4 Ohm 4 Ohm

Sensitivity 87dB 87dB 88dB

Cone Material Polypropylene Polypropylene Polypropylene

Tweeter PEI PEI PEI

Mounting Depth 50mm (2”) 56mm (2.25”) 70mm (2.75”)

Mounting Diameter 142mm x 89mm

(5.59” x 3.50”)

181mm x 128mm

(7.12” x 5.04”)

155mm x 222mm

(6.10” x 8.74”)

INSTALLATION GUIDELINES

Ensure the audio system is turned off before making any connections to the amplier, speakers or

source unit. Failure to do so could result in permanent damage to the audio system.

When wiring the speakers ensure that the wire is protected from sharp objects and always use rubber

grommets when wiring through metal panels. Ensure all terminals and connections are protected from

the vehicle chassis and from each other as failure to do so could result in permanent damage to the

audio system.

When connecting the speakers to the source unit or ampliers ensure you connect the positive and

negative output wire from the source unit to the corresponding speaker terminals. This will ensure the

audio system will be in phase.

1. Ensure there is adequate clearance and depth for the speaker to be mounted.

2. Use the supplied template to mark out & cut the correct diameter hole.

3. Drill four holes for the mounting screws.

4. Separate the grille from the frame

5. Insert the speaker and grille and afx with the screws provided

6. Complete installation by replacing the grille into the grille frame.
