Planar Simplicity Series

www.planar.com

Planar Simplicity Series

Safety Instructions

Warnings and Precautions

KNOW THESE SAFETY SYMBOLS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

This symbol indicates high voltage is present inside.

It is dangerous to make any kind of contact with any

inside part of this product.

This symbol alerts you that important literature

concerning operation and maintenance has been

included with this product.

CAUTION: FCC/CSA regulations state that any unauthorized

changes or modications to this equipment may void

the user’s authority to operate it.

CAUTION: To prevent electric shock, match the wide blade of plug

to the wide slot, and fully insert the plug.

TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC

SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE.

The Socket-outlet should be installed near the apparatus and be easily

accessible.

Read and follow these instructions

when connecting and using your Public

Information Display:

• Unplug the display if you are not going to use it for an extensive

period of time.

• Unplug the display if you need to clean it with a slightly damp cloth.

The screen many be wiped with a dry cloth when the power is off.

However, never use alcohol, solvents or ammonia-based liquids.

• Consult a service technician if the display does not operate normally

when you have followed the instructions in this manual.

• The casing cover should be opened only by qualied service

personnel.

• Keep the display out of direct sunlight and away from stoves or any

other heat sources.

• Remove any object that could fall into the vents or prevent proper

cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• Keep the display dry. To avoid electric shock, do not expose it to

rain or excessive moisture.

• If turning off the display by detaching the power cable, wait for 6

seconds before re-attaching the power cable for normal operation.

• To avoid the risk of shock or permanent damage to the set do not

expose the display to rain or excessive moisture.

• When positioning the display, make sure the power plug and outlet

are easily accessible.

• IMPORTANT: Always activate a screen saver program during your

application. If a still image in high contrast remains on the screen for

an extended period of time, it may leave an ‘after-image’ or ‘ghost

image’ on the front of the screen. This is a well-known phenomenon

that is caused by the shortcomings inherent in LCD technology. In

most cases the after-image will disappear gradually over a period

of time after the power has been switched off. Be aware that the

after-image symptom cannot be repaired and is not covered under

warranty.

Produkt Specifikationer

Mærke:	Planar
Kategori:	overvåge
Model:	SL5551
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	1239 mm
Dybde:	62 mm
Højde:	711 mm
Vægt:	16000 g
Produktfarve:	Sort
Pakkevægt:	18000 g
Skærm diagonal:	55 "
Skærmopløsning:	1920 x 1080 pixel
USB-port:	Ja
HD-type:	Fuld HD
Skærmteknologi:	LCD
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	350 cd/m²
Responstid:	9 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
LED-baggrundsbelysning type:	Edge-Lit LED
Indbyggede højttaler(e):	Ja
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	1
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
VESA montering:	Ja
Panel montering grænseflade:	400 x 200,400 x 400 mm
Strømforbrug (standby):	- W
Strømforbrug (typisk):	179 W
Driftstemperatur (T-T):	5 - 40 °C
Kabler inkluderet:	AC, HDMI, RS-232
Fjernbetjening inkluderet:	Ja
Certificering:	FCC Class A, UL, CE
Antal indbyggede højttalere:	2
Pc lydindgang:	Ja
Understøttet placering:	Indendørs
Formål:	Detail
Vis antal farver:	16,78 millioner farver
Lyd (L, R) indgang:	1
Kontrastforhold (typisk):	1200:1
Pixel pitch:	0.63 x 0.63 mm
Lyd (L, R) udgang:	1
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
Fjernbetjening (IR) indgang:	1
Panel levetid:	- t
Driftstimer (timer/dage):	16/7
RS-232 grænseflade:	Ja
Facet bredde (bund):	14.5 mm
Facet bredde (øverste):	12.6 mm
Orientering:	Horisontal/vertikal
Facet bredde (side):	12.6 mm
