Since 1978

Wireless Flash Trigger

PFT-28

Instruction Manual

Thank you for purchasing the Polaris PFT-28 professional wireless

flash trigger kit.

For the best performance, please read the manual carefully before using.

１．Features:

➤Versatile, reliable remote flash trigger for camera speed

light and studio lights up to 100 meters /300 feet away

➤Easy to control the lighting in the cordless

➤Ideal for multi-flash photography

➤Works on the 2.4GHz frequency reducing radio

interference and an extended range (up to 100 meters /

300 feet) – no need to have line-of sight alignment, either,

as radio waves will pass through walls, windows and floors.

４．Channel Setting: ５．Operation:

 Turn the power of POLARIS Karat Flash Meter (the meter)

and PFT-28 Receiver (the receiver) OFF

 Mount PFT-28 Transmitter (the transmitter) to the synch

terminal of the meter

 Mount the flash on the receiver hot shoe socket

 If your flash or studio light does not have a hot shoe,

connect the studio light to the flash or studio light to the

ACC socket of the receiver

 Set the channel selector at same position on both the

transmitter and receiver. To use multiple flash units,

be sure to set all the receivers to the same channel

 Turn the power of the meter and the receiver ON

 Choose “Flash Light” mode or “Flash Duration” mode

on the MENU display of the meter

(*Set the preferences of ISO value and Shutter Speed (T)

if needed. For more detail of setting the meter,

please refer to the page 15 of 『Instruction Manual』

on the following link; http://en.aspen.co.jp/download )

 Press the measuring button on the meter

 Fire the flash and measured Aperture (F) value and

Flash Ratio (FR) are displayed on the meter. In the case of

FD mode, duration time of strobe is displayed as well.

(*Press the measuring button of the meter again, the flash

fires again and the meter takes a new reading)

 PFT-28 channel selector is inside the battery hatch

 Follow the OPEN direction icon to slide out the battery cover

and set the channel

 16 channels selectable for the Transmitter and Receiver

 Please make sure the Transmitter and Receiver are on the

same channel

*Note:

Since the PFT-28 does not transmit TTL settings,

use of a flash or light unit with full manual control is

recommended. You will need to set the power output

manually.

*Note:

Please note that the flash may fire, if you change the channel

while the power of the Receiver turn on.

２．Included:

Remove the PFT-28 kit from the box and confirm that

you have all the items listed below:

• PFT-28 Transmitter

• PFT-28 Receiver

• Φ6.3 conversion plug

• Φ3.5-Φ2.5 plug code (27.5mm)

• Instruction Manual

★PFT-28 Transmitter

３．Name of Parts:

The parts are identified as follow:

６．Specifications:

Wireless Frequency System: 2.4GHz

Operating Distance: up to 100 meters / 300 feet

Channel: 16 channels

Sync: 1/250s

Transmitter Power: 1 x CR2032 battery

Receiver Power: 2 x AAA battery

Function: Wireless Flash Trigger

(for camera speed light or studio light)

Weight: Transmitter 32g (*without battery)

Receiver 40g (*without battery)

Dimension: Transmitter 64 x 41 x 15mm

Receiver 37 x 79 x 21mm

(*excluding protrusions)

Receiver includes ¼” – 20 tripod mount

Safety standard CE, FCC, Canada IC

RoHS compliance

７．For your Safety:

⚠ Do not disassemble or modify

⚠ Keep Dry

⚠ Keep out of reach of children

⚠ Do not use in the presence of flammable gas

⚠ Do not expose to high temperatures

⚠ Remove battery and store in dry cool place when not in use

Distributor/Sales Agent ASPEN CORPORATION

6-3-5 Shinbashi, Minato-Ku, Tokyo

105-0004 JAPAN

Tel: 81-3-3433-3948 Fax: 81-3-3433-3832

E-mail: office@aspen.co.jp

URL: http://en.aspen.co.jp

*Specifications and appearance are subject to change without notice due to improvement.

1 Synch Socket

2 Auxiliary fitting for the Meter

3 Battery Cover

★PFT-28 Receiver

*Note:

Contact your local retail shop or distributor for Warranty

and Service.

1 Hot Shoe Socket 4 Hot Shoe Foot with Screw

2 Power Switch 5 Battery Cover

3 Indicator Light 6 ACC Socket

●Battery Installation

Printed in JAPAN

Slide the battery cover in the direction indicated by the arrow
