PL01-1000 Polylift - April 2012
Page 1 of 4
PL01-1000 Polylift - April 2012
Page 2 of 4
MISSION STATEMENT
“PolyJohn is a family owned, state of the art, plastics manufacturing company
dedicated to providing its employees with a work environment committed to
excellence, and its customers with innovative products, services and technology
that meet or exceed their requirements.”
THANK YOU FOR PURCHASING POLYJOHN PRODUCTS!
Look for us on the Web @ www.PolyJohn.com
Optional Roof Installation Instructions
1. Replace the PL01-0007G short lifting arm with the longer
2. Place the roof on the unit as shown in
the diagram at the .right
3. Starting with one side, make sure that
the tip of the roof upright is in
the corner of the ledge on
side of the PolyLift body.
Using a drill with
a 7/16 drill bit, drill
a hole through the
molded in hole in the
roof and all the way
the side of the unit.
4. Place a PC-000126
Washer on a PC-000125
Bolt and push this
through the roof and
through the body. Place
a PC-000126 Washer on the
inside with a PC-000127 Nut
and tighten.
To put the roof up, make sure the lifting arm is in the down posi-
tion. Swing the roof into position, and lock in place using the
lifting arm. Be sure that the top of the arm is tight against the
stop on the underside of the roof.
POLYLIFT™
Highrise Portable Restroom
Technical Information
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
www.polyjohn.co.uk
sales@polyjohn.co.uk
POLYJOHN
CANADA
PolyJohn Canada
P.O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
www.polyjohncanada.ca
info@polyjohncanada.ca
Height w/Roof 91 in 231 cm
Height w/o Roof 69 in 175 cm
Length w/Roof in Down Position 61 in 155 cm
Length w/o Roof 53 in 135 cm
Width w/Roof in Down Position 35 in 89 cm
Width w/o Roof 33 in 84 cm
Weight w/Roof 287 lb 129 kg
Weight w/o Roof 251 lb 113 kg
Holding Tank Capacity 38 gal 144 ltr
Speci cations
The PL01-1000 PolyLift Highrise
Portable Restroom is designed for
Highrise Construction Sites. Easi-
ly mobile on caster wheels, simply
hooks up to a crane for highrise
portability. An added feature of a
urinal is conveniently located on
the outside rear of the restroom.
An optional roof is also available.
Shipped fully assembled.
General Overview
PC-000490 - Toilet Paper Dispenser
(4) PC-000105 - Rivet
PC-000760 - Toilet Paper Rod
PC-000205M - Lock Keyed Alike
(3) PC-000171 - Hinge 3” S.S. Spring Loaded
(18) PC-000105 - Rivet
PL01-0003 - Door Assembly
PL01-0012 - Door Latch
PC-000121 - 1/4” x 1-1/4” Fender Washer S.S.
PC-000122 - 1/4” x 2-1/4” Truss Head Screw
PC-000140 - 1/4“-20 Nylon Lock Nut S.S.
PC-000168 - 5/16” x 7/8” Flat Washer
PC-000210 - 6” Caster Wheel w/Swivel
(8) PC-000177 - 5/16“-18 x 1” Hex Head Bolt
(8) PC-000161 - 5/16“-18 x 3/4” Flat Washer
(8) PC-000173 - 5/16”-18 Nylon Lock Nut
**NOT SHOWN
PC-000204 - Toilet Seat
PC-100784 - Weight Load Limit Plate
(1) PC-000108 - Rivet
(1) PC-000106 - 3/16” Backup Washer
PC-000211 - 6” Fixed Caster Wheel
(8) PC-000177 - 5/16“-18 x 1” Hex Head Bolt
(8) PC-000161 - 5/16“-18 x 3/4” Flat Washer
(8) PC-000173 - 5/16”-18 Nylon Lock Nut
PL01-0005 - Base Frame Assembly
PL01-0002
Waste Tank
PL01-0001 - Main Body Shell
(4) PC-000104 - Rivet
(6) PC-000106 - 3/16” Backup Washer
(2) PC-000107 - Rivet
PL01-0010 - Serial Number I.D. Plate
(2) PC-000105 - Rivet
(2) PC-000189 - 3/8” x 2” Hex Head Bolt S.S.
(2) PC-000146 - 3/8” Nylon Lock Hex Nut S.S.
(2) PC-000144 - 3/8” Lock Washer
