Tip: Some features require extra

memory, to expand your phone’s storage

capacity, install a micro SD card.

3. Micro-SD card

(optional)

Lightly press the

card holder and

push it carefully

toward the corner

of the

compartment. The card holder can

now be ipped up vertically. Place the

memory card in the black plastic

bracket. Make sure that the memory

card contacts face down and that the

card is placed in accordance with the

marked area (see gure). Do not

scratch or bend the card contacts.

Push the metal holder back down,

press it at and slide it until it snaps

into place.

1. Receiver/

loudspeaker

Make calls holding the

phone to your ear

2. Display

3. Speed dials

Speed dial the num-

bers saved under M1,

M2 and M3

4. Left soft key

Press to open main

5. Right soft key

press to open phone-

book

6. Call key

Make and answer

calls;

Press once to open

the call log

7. Camera key

8. Arrow keys

Press to open

shortcut functions;

press to open

messages;

scroll up and down in

menus and lists

9. End key

Press to end a call;

press to return to

standby;

press and hold to turn

the

phone on or off

10. Numerical

keys

Press to enter num-

bers;

long press key 1, to

call your voice mail-

box (phone number

must be stored);

when writing, press

to input numbers or

characters

11.

key

Press to enter

“*”/ “+” / “P”/“W“;

when writing, press to

enter special charac-

ters

12.

key

Long press to toggle

between Silent and

normal mode

13. Headset

socket

For 3.5 mm standard

headset

14. Torch key

Switch torch on and

off

15. LED

Blue = battery full

16. LED

Red = battery charg-

ing

17. Camera LED and torch

18. Camera lens

19. SOS button

20. Loudspeaker

21. Micro-USB

port

For charger

22. + and - keys

Adjust ring volume

and loudspeaker

volume

23. Charging cradle

24. Cradle contacts

Install the SIM card, memory card and

battery

The SIM card and memory card holders are

located inside the battery compartment.

CAUTION

Only use batteries, charger and

accessories that have been approved for

use with this particular model. Connecting

other accessories may be dangerous and

may invalidate the phone’s type approval

and guarantee.

1. Remove the cover

by placing your

thumb on the back

of the phone casing

and pushing the

cover downwards.

If the battery is

installed, slide your

ngernail in the

notch next to the

battery to lift it up.

2. Insert the SIM card

(required)

Inser the SIM card

by carefully slide it

under the metal

bracket. Make sure

the contacts on the

SIM card face down and the cut off

corner is aligned with the immersed

shape of the bracket. Do not scratch or

bend the card contacts. Try not to

touch the contacts with your ngers.

English

QSG_Primo_by_Doro_406_en_A3(A7)_v1.0

English

Version 1.0

1313

Specications

Network:

GSM 900/1800 MHz

Dimensions:

102 mm x 50 mm x 20 mm

Weight:

115 g

Battery:

3.7V/1050 mAh Li-ion

battery

Operating ambient

temperature:

Min: 0°C (32°F)

Max: 40°C (104°F)

Charging ambient

temperature:

Min: 0°C (32°F)

Max: 40°C (104°F)

Storage

temperature:

Min: -20°C (-4°F)

Max: 60°C (140°F)

Changes and errors excepted.

IMPORTANT!

Use only compatible memory cards

with this device. Compatible card type:

microSD, microSDHC.

Incompatible cards may damage the

card itself, the device and corrupt any

data stored on the card. Depending on

the market some phones may have a

pre-installed memory card.

4. Insert the battery

(required)

Push it into the

battery

compartment.

Ensure that the

three contacts on

the battery touches the three spring

contacts in the battery compartment.

5. Replace the cover and press it all the

way around to make sure it is closed.

When the battery performance is low and

the phone is still on, the empty battery

symbol ashes to indicate the battery state

and an alarm signal will sound. To recharge

the battery, connect the mains adapter to

the micro USB connector on the bottom

side of the phone.

Alternatively you can place the telephone in

the charge cradle connected to the mains

adapter via the USB cable.

During charge, the red charge LED is on.

The battery charge icon moves during

charge (visible in the upper right corner

of the display). It takes approximately 3

hours to fully charge the battery. When fully

charged the charge icon stops moving.

Power on the phone

Press and hold the red key on the

phone at least 2 seconds to turn it on or off.

If the SIM card is valid and protected with a

PIN code (Personal Identication Number),

Enter PIN

is displayed.

Enter the SIM PIN code and press

( upper left corner of keypad). Delete

with

Delete

( upper right corner of

keypad).

Set the language

By default the phone’s menu language

is determined by the SIM card. You can

always switch between the languages

supported by the phone.

1. Press

Settings

2. Select

Phone settings

3. Select

Language

4. Select language from the list â

Answer a call

1. Press or

Answer

to accept the call

or press

Reject

to reject the call (busy

signal).

Alternatively, you can press to

reject the call directly.

2. Press to end the call.

Create phonebook entry

1. Press

Phonebook

2. Select

Add new contact

3. Select whether you want to save the

contact on the SIM card or in the phone.

4. Enter a name for the contact.

5. Press .

6. Enter the phone number including the

area code.

7. Then press

Options

Save

Tip: For international calls, always enter a

+ symbol before the country code to be

able to use the phonebook optimally in

any country.

Press the

key twice to enter the inter-

national area code .+

Speed dial (M1, M2)

Note!

The contacts for the speed dial keys

must already be stored in the Phonebook.

M1 and M2 setup

1. Press

Contacts

2. Select a contact for

keys.

3. Press

Options

Speed dial

4. Select the line

Save

5. Conrm the

Save?

with

Yes

SOS calls

As long as the phone is switched on, it is

always possible to place an SOS call by

entering the main local emergency number

for your present location followed by .

Some networks accept calls to emergency

numbers without a valid SIM card. Contact

your service provider for more information.

Note! Credit is NOT required - but the SIM

card must be registered and activated.

Emergency numbers are only intended

for urgent assistance, and should only

Set time and date

1. Press

Settings

2. Select

Time and date

3. Select

Set time/date

4. Enter the time (HH:MM) â .

5. Enter the date (DD.MM.YYYY) â .

6. Select

Make a call

1. Enter the phone number with the area

code. You can delete digits with

Clear

2. Press to dial. Press

Abort

cancel the call.

3. Press to end the call.

Tip: For international calls, always enter a

+ symbol before the country code to be

able to use the phonebook optimally in

any country.

Press the

key twice to enter the inter-

national area code .+

be called in an emergency. Please do

not misuse the emergency number as

this may prevent someone with a real

emergency from getting through.

Volume control

You can adjust the volume during a call

using the side keys

+/-

. The volume level is

shown on the display.

Enter text

Select character

• Press a numerical key repeatedly until

the desired character is shown.

• Wait a few seconds (until the blue or

yellow background of the character has

disappeared) before entering the next

character.

Special characters

• Press

to view a list of special

characters.

• Select the desired character with

(to move left and right) and press

enter.

Move the cursor within text

• Use the keys

to move the

cursor within the text.

Upper case, lower case and numerals

• Press

to choose the input mode.

The symbol at the top left in the display

indicates the input mode.

Primo

™

406

Instructions
