Side 1/6

Model Nos. 943-A, B, C, D, BK

Tomato Saber™

Operating

Instructions

355 East Kehoe Blvd. • Carol Stream, IL 60188 USA

Telephone: 630-462-8800 • Fax: 630-462-1460

Toll Free: 1-800-PCASTLE

www.princecastle.com

Prince Castle’s Tomato Saber™ slicer is designed to

precisely slice whole tomatoes. With the exclusive Perma-

Tight™ disposable blade cartridge system, this unit never

requires blade tightening or adjusting. Engineered for

durability and long life, the Tomato Saber™ features self-

lubricating bearings, a safety shield, and a contoured

Tomato Pusher Assembly. The unit is shipped with a

Tomato Catcher, Table Stop Assembly, and a cleaning

brush.

Hazard Communication Standard (HCS) — The

Procedure(s) in this equipment manual include the use

of chemical products. These chemical products will be

highlighted with bold face letters followed by the

abbreviation (HCS) in the text of the manual. See the

Hazard Communication Standard (HCS) Manual for

the appropriate Material Safety Data Sheet(s) (MSDS).

TABLE OF CONTENTS

Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . 3

Ordering/Service Information. . . . . . . . . . . . . . . . . . . . 3

Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

LIMITED WARRANTY

This product is warranted to be free from defects in material and/

or workmanship for a period of one (1) year from date of original

installation, not to exceed 18 months from date of shipment from

our factory . Blade with the exception of the blade cartridge

cartridge is warranted to be free from defects at time of delivery

only.

Any component which proves to be faulty in material and/or

workmanship will be replaced or repaired (at the option of Prince

Castle, Inc.) without cost (including freight and duty) to the

customer for parts or labor.

This warranty is subject to the following exceptions/conditions:

• Use of products other than tomatoes will void this warranty.

• This equipment is portable; charges for on-location service

(e.g., trip charges, mileage) are not included in the

provisions of this warranty.

• Damage caused by carelessness, neglect and/or abuse (e.g.,

dropping, tampering or altering parts), equipment damaged

in shipment, by fire, flood or an act of God is not covered

under this warranty.

SET-UP

1. After you have removed the Tomato Saber™ from the

carton, inspect the unit for signs of damage. If there is

damage to the unit:

• Notify carrier within 24 hours after delivery.

• Save carton and packing materials for inspection

purposes.

• Contact your Prince Castle dealer for replacement or

the Prince Castle Customer Sales Department at 1-

800-722-7853 if purchased directly.

2. Verify that all parts have been received.

• Tomato Saber™ slicer with Perma-Tight blade

cartridge.

• Tomato Catcher — neatly catches sliced tomato.

• Table Stop Assembly — stabilizes unit for easier

slicing.

3. Place slicer on prep table or flat surface.

TIP: Use the ripest tomatoes first.

OPERATION

IMPORTANT:

The Tomato Saber™ is designed to slice

tomatoes only. Using it to slice other products may damage

the slicer and will void the warranty.

1. Grasp handle and pull all the way back to end of

stroke.

2. Insert tomato in front of the Tomato Pusher Assembly

with the core side down. See .figure 1

figure 1

3. Push handle with a quick, firm stroke all the way

through the blades and until the pusher stops. The

tomato will be completely sliced. See .figure 2

figure 2

4. Remove tomato slices from Tomato Catcher.

5. Place tomato slices in a clean, sanitized 1/6 size

tomato pan with false bottom.

6. Save end pieces and any slices with green core centers

(stem) showing. These are used for Fajita products.

7. Place pan in prep table. (Additional pans should be

covered and placed in walk-in cooler. Maximum 3

hour total holding time with no longer than 1 hour in

walk-in, no more than 2 hours at prep table.)

Identify pans stored in walk-in with the 1 hour

“remove from walk-in” time.

Daily cleaning of the tomato slicer will keep this piece of

equipment clean and free from build-up. However, if

residual tomato juice is allowed to remain on the tomato

slicer for long periods, a hard white deposit will form on

the cutting blades which becomes very hard to remove and

will dull the blades.
