DAILY REFERENCE

GUIDE

You can download the Safety Instructions and the Use and Care Guide, by visiting our website

docs.whirlpool.eu and following the Instructions on the back of this booklet.

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

1.Upper rack

2. Foldable flaps

3.Upper rack height adjuster

4.Upper spray arm

5.Lower rack

6.Cutlery basket

7.Lower spray arm

8.Filter Assembly

9.Salt reservoir

10.Detergent and Rinse Aid dispensers

11.Rating plate

12.Control panel

0000 000 00000

Service:

1011

CONTROL PANEL

1. On-Off/Reset button with indicator light

Program selection button with indicator light

Half Load button with indicator light / Key lock

Eco program indicator light

5. Key lock indicator light

6. Display

7. Program number and remaining time indicator

Tablet (Tab) indicator light

9. Closed water tap indicator light

10. Rinse Aid refill indicator light

11. Salt refill indicator light

12. Tablet (Tab) button with indicator light

13. Delay button with indicator light

14. Start/Pause button with indicator light / Drain out

4 8

5 6 7 10

129

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see

PROGRAMS DESCRIPTION) and should be filled when the SALT REFILL

indicator light

in the control panel is lit.

1.Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2.Position the funnel

(see figure)

and fill the salt

reservoir right up to its edge (approximately 1 kg);

it is not unusual for a little water to leak out.

3.Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, we recommend carrying out the

procedure before the washing cycle is started.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

• Switch on the appliance by pressing the ON/OFF button.

• Switch off the appliance by pressing the ON/OFF button.

• Hold down button START/PAUSE for 5 seconds, until you hear a

beep.

• Switch on the appliance by pressing the ON/OFF button.

•

The current selection level number and the salt indicator light both flash.

• Press button P to select the desired hardness level (see WATER

HARDNESS TABLE).

• Switch off the appliance by pressing the ON/OFF button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specifically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL

indicator light switches off.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result .

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser B should

be filled when the RINSE AID REFILL indicator light

in the control

panel is lit.

1. Open the dispenser by turning the cap

in an anticlockwise

direction.

2. Carefully introduce the rinse aid as far as the maximum (110 ml)

reference notch of the filling space - avoid spilling it. If this happens,

clean the spill immediately with a dry cloth.

3. Screw the cap back on.

NEVER pour the rinse aid directly into the tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satisfied with the drying results, you can

adjust the quantity of rinse aid used.

Turn the adjuster C.

The factory setting is for a medium level.

• If you see bluish streaks on the dishes, set a low number (1-2).

• If there are drops of water or limescale marks on the dishes, set a high

number (5-6).

A Rinse aid dispenser

cap.

(Unscrew the cap to fill

the dispenser).

B Rinse aid dispenser

C Rinse aid dosage

adjuster.

(You can set up to a max.

of 6 levels).

FILLING THE DETERGENT DISPENSER

Open the detergent dispenser and measure out the detergent

according to Programs Table.

D Lid opening button

(Press to access the

containers)

E Cover

(Detergent containers).

Remove detergent resi-

dues from the edges of

the containers before

closing the cover until it

clicks.

F Pre-wash detergent

container.

Detergent for pre-wash

(pour in the powder or liquid detergent after consulting the PROGRAMS

TABLE).

G Wash detergent container.

Detergent for wash (pour in the powder, liquid or tablet detergent

after consulting the PROGRAMS TABLE).

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

F CGD

D FG

Produkt Specifikationer

Mærke:	Privileg
Kategori:	Opvaskemaskine
Model:	RSBC 3B19 X
Bredde:	445 mm
Dybde:	570 mm
Højde:	820 mm
Indbygget skærm:	Ja
Skærmtype:	LCD
Ledningslængde:	1.3 m
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	237 kWh
Placering af apparat:	Delvist indbygget
Installationsrum bredde:	450 mm
Installationsrum dybde:	560 mm
Støjniveau:	49 dB
Antal vaskeprogrammer:	6
Forsinket start-timer:	Ja
Børnesikring:	Ja
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	10 L
Bestik rum type:	Kurv
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	10 kuverter
Cyklustid:	180 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Eco, Glass/delicate, Intensive, Normal, Pre-wash
Halv belastning:	Ja
Tørringsklasse:	A
Årligt vandforbrug:	2800 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.83 kWh
Antal temperaturindstillinger:	4
Indikator for resterende tid:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Produktstørrelse:	Slimline (45 cm)
Integreret timer:	Ja
Vandpåfyldning:	Cold, Hot
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
