Privileg PV2FC10BS7A0S Manual

Privileg Opvaskemaskine PV2FC10BS7A0S

Læs gratis den danske manual til Privileg PV2FC10BS7A0S (8 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 14 personer og har en gennemsnitlig bedømmelse på 3.5 stjerner ud af 7.5 anmeldelser. Har du et spørgsmål om Privileg PV2FC10BS7A0S, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

ENQuick Guide

Program Programs description

Drying

phase

Auto

Door

Available

options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that for

this use, it is the most ecient programme in terms of its combined ener-

gy and water consumption, and that it is used to assess compliance with

the EU Ecodesign legislation.

3:35 8.7 0.59

2. Auto Intensive 65°- Automatic program for heavily soiled dishes and

pans (not to be used for delicate items). 2:00 - 3:10 14.0 - 17.0 1.50 - 1.85

Auto Mixed -55° Automatic program for normally soiled pans and dishes.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

4. Glass - 45° Program for delicate items, which are more sensitive to high

temperatures, for example glasses and cups. 1:40 12.0 1.20

5. Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes

with no dried food residues. Without drying. - 0:30 9.0 0.50

Sanitizing - 65° Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

- 1:50 12.0 1.30

Extra 50° - Program that allows to wash very big items loaded in the low-

er rack. Please apply detergent directly to tub instead of detergent dis-

penser. Upper rack should be removed with this cycle.

- - 1:30 11.0 1.20

8. Pre-Wash - Use to refresh crockery planned to be washed later. No deter-

gent to be used with this program. - - 0:10 4.5 0.01

9. Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning

performance in a short time without the need to pre-treat dishes. 1:25 11.5 1.10

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 1 kg); it is not unu-

sual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently prevent-

ing scale buildup on heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per Eco cycles with water hardness level set to . 6 3

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser Ashould be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the ap-

pliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device . Introduce the C

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved Usage of detergent not designed for dishwashers

may cause malfunction or damage to the appliance.

1. On-O / Reset button with indicator light

2. Program selection button with indicator light

3. Half Load button with indicator light / Tablet (Tab)

4. Eco program indicator light

5. Display

6. Program number and remaining time indicator

7. Tablet (Tab) indicator light

8. Closed water tap indicator light

9. Rinse Aid rell indicator light

10. Salt rell indicator light

11. Push & Go button with indicator light

12. Delay button with indicator light

13. Start/Pause button with indicator light / Drain out

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation

Instructions.

After installation, please remember to remove all transport protection

parts from the dishwasher.

CONTROL PANEL

54 6 7 11 129 10

FIRST TIME USE More information in the Daily Reference Guide on website.

PROGRAMS TABLE

Quick Guide

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not

needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

DELAY - The start of the program may be delayed for a period of time

between and hours.0:30 24

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab) - If you use powder or liquid detergent, this option

should be o.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

PUSH&GO - button is an easily distinguishable button that allows you

direct access to the Push&GO program, a wash and dry cycle that

ensures great cleaning performance in a short time. You don’t have to worry

which program to choose, Push&GO cycle will do the work for you.

EXTRA - makes it possible to carry out a heavy-duty wash cycle of

large crockery up to a max height of 53cm. baking pans, oven grids,

dripping pans, hob grids, large saucepans, serving dishes, pizza dishes,

stainless-steel hood lters. Remove the upper rack to load bulky crockery.

Release the two locks (right and left) and pull out the rack.

When the upper rack is tted, the locks must be always

closed.

In order for the water to reach the crockery everywhere,

arrange it as shown in the Figure.

Do not start the dishwasher without the upper rack

using wash cycles other than EXTRA.

To carry out the wash cycle Extra pour the detergent

DIRECTLY INTO THE TUB and not into the dispenser.

HALF LOAD using the upper or lower rack - If there are not many

dishes to be washed, a half load cycle may be used in order to save

water, electricity and detergent. Remember to load the upper or lower

rack only, and to reduce the amount of detergent accordingly.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1 2 3 4

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in

aclockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

UPPER RACK

(loading

example for the

upper rack)

Load delicate and

light dishes: glas-

ses, cups, saucers,

low salad bowls.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

loading example

for the lower rack)

For pots, lids, plates, salad

bowls, cutlery etc. Large plates

and lids should ideally be pla-

ced at the sides to avoid inter-

ferences with the spray arm.

The lower rack has tip-up sup-

ports which can be used in a

vertical position when arrang-

ing plates or in a horizontal po-

sition (lower) to load pans and

salad bowls easily.

CUTLERY BASKET

The basket is equipped

with top grilles for im-

proved cutlery arrange-

ment. The cutlery basket

should be positioned

only at the front of the

lower rack.

Knives and other uten-

sils with sharp edges must be placed

in the cutlery basket with the points

facing downwards or they must be po-

sitioned horizontally in the tip-up com-

partments on the upper rack.

LOADING THE RACKS CAPACITY: 10 standard place-settings

CARE AND MAINTENANCE More information in the Daily Reference Guide on website.

Produkt Specifikationer

Mærke:	Privileg
Kategori:	Opvaskemaskine
Model:	PV2FC10BS7A0S
