ELECTRICAL CONVECTOR HEATER
EN - 1
PCL-300 Standard Sirocco
PCL-303 with ventilation Mistral
We thank you for the purchase of this Profile product.
Note: It is important that you read this manual before
using the product. And be sure to save this manual for
possible use later.
Technical information
Mains voltage: 220V – 240V AC (50Hz)
Power: - In position 0 OFF
- In position 1 750W
- In position 2 1250W
- In position 3 2000W
IPX0 (no protection against water)
Overheat protection
Frost protection
Variable, built-in thermostat
ON/OFF switch
With handle for easy moving
Ideal for usage in dry areas up to a maximum of
60m³.
Can be used freestanding or wall-mounted
Safety precautions
To ensure safe operation of your heater, the appliance
must be assembled and connected in accordance with
the indications in the manual. When these instructions
are ignored, the liability of the supplier/manufacturer
becomes null.
The appliance is only suitable for domestic use within
the home.
Do not use the appliance in humid spaces, such as
bathrooms and utility spaces.
When the heater is covered, then this can result in a
fire hazard.
Place the appliance only upright and on a level, dry
base.
Do not use the appliance without the feet fitted or
when fitted incorrectly.
The surfaces, and especially the grate, become very
hot during operation. Make sure that small children
cannot touch these surfaces.
No objects may be inserted through the appliance's
grate opening. This can disrupt the working of the
heater and burn the object, or even cause danger of
electrocution.
Never use the appliance in combination with a time
switch. The automatic operation of heaters can result
in a hazard during your absence.
Never leave your appliance unattended. Also always
pull the plug out of the socket when you leave the
room.
Do not run the mains lead across the hot appliance.
Electrical heaters are designed as additional heating
and are not suitable for main heating during the cold
season.
When the appliance has fallen, then first disconnect
the power supply, before returning the appliance to its
upright position and if necessary remove what caused
it to fall.
Position the heater at a distance of at least 100cm
from obstacles and ensure that the hot air flow of
the appliance is not blown against any easily
combustible objects (such as curtains and/or heat-
sensitive plastics).
Do not use an extension lead.
Connection
The heater is supplied with a socket plug. Never
operate the appliance with a damaged mains lead
and/or plug, or after a malfunctioning of the heater has
occurred or after it has been damaged in any possible
way.
The replacement of a mains lead and/or plug should
only be performed by a qualified expert, who is familiar
with the applicable regulations.
Installation
Freestanding:
Carefully turn the radiator on its side to fit the feet.
Attach all feet (fig.1) and secure them by means of
the included screws.
Every foot requires 2 screws. Do not use the radiator
with the feet incorrectly fitted!
Fig. 1
Wall-mounted:
You can also mount this heater on to the wall, using
the 2 included wall supports.
Respect the minimum distance from objects.
Drill 2 holes into the wall with a horizontal distance
of 418mm between them for the upper wall support
and insert the included plugs. Make sure that you
install the heater straight up.
The lower wall supports must be attached on the
lower corners of the appliance; use for this the
holes that were originally intended for the
attachment of the 2 feet. If necessary, these lower
supports can also be attached to the wall.
Operation and functions
Operation:
Put the wattage switches in position 0.
Insert the plug into the wall socket.
ELECTRICAL CONVECTOR HEATER
EN - 2
PCL-300 Standard Sirocco
PCL-303 with ventilation Mistral
Press the switch(es) with the desired wattage to
operate the radiator.
Use:
The thermostat will automatically maintain your desired
room temperature.
Switch on one or a number of switches depending on
the speed at which you want to obtain the desired
temperature.
o Switch 1: 750W
o Switch 2: 1250W
o Switch 1 and 2: 2000W
o Only for the PCL-303:
Switch on the TURBO switch to activate the
ventilator, which circulates the hot air in the room.
Turn the thermostat clockwise until you hear a ‘click’.
This sound means that the heater is now activated.
When the indicator light is on, the heating is active. =>
In the minimum setting, you activate the frost
protection.
By turning the thermostat clockwise, you increase the
temperature setting. By turning anticlockwise, you
reduce the temperature setting.
The thermostat automatically switches the heating on
and off when the set temperature has been reached.
Remark
Allow the radiator to completely cool down before
moving it and always use the handle intended for this
purpose.
Overheat protection: if this is activated, the radiator
switches itself off. In this case, switch off the radiator
and pull the plug from the wall socket. Allow it to cool
down and remove any obstacles before continuing to
operate the radiator.
Cleaning
We recommend carefully cleaning the heater once a
month to remove dirt and dust. This is to allow the
heater to operate efficiently and safely.
Always turn off the thermostat and pull the plug from
the wall socket. Make sure the appliance has
completely cooled down before cleaning it.
Clean the housing with a clean, soft and lightly damp
cloth. Never clean the heating elements or thermostat
in water. Blow as much dust as possible off the
heating elements. This lengthens the working life and
reduces the risk of fire.
Keep the box for storage during periods that you are
not using the ceramic heater. After all, the heater must
also be kept free of dirt and dust during storage.
Guarantee
The guarantee period for the PCL-300 & PCL-303
amounts to 2 years and commences on the date of
purchase. During the guarantee period, Eltra NV will
repair any defects attributable to material or production
faults. Eltra NV may choose to either repair or replace the
defective appliance.
Eltra NV is not obliged to repair or replace appliances
if they have become defective as a result of damage,
inappropriate use, or modifications or adaptations
made after the purchase date.
Take any defective appliance together with the original
receipt back to the shop where the appliance was
purchased. Always add a note with a description of the
problem.
Damage
Eltra NV can under no circumstances whatsoever be
held responsible for damage of whatever nature if the
appliance was not correctly installed according to the
specified installation instructions, nor for damage as a
result of unforeseen circumstances, such as natural
disasters and lightening strike. All such resulting costs
are consequently at the expense of the buyer and are
not covered by the guarantee conditions.
www.profile.eu
Eltra nv, Pachtgoedstraat 2, 9140 Temse, BELGIUM
Eltra DIYeuronet, Frontstraat 14, 5405 AM Uden,
THE NETHERLANDS
