2.4Ghz Vehicle Camera & Video Monitor System

with Wireless Video Transmission

Waterproof Rated Cam, Night Vision,

7’’ -inch Display (for Bus, Truck, Trailer, Van)

www.PyleUSA.com

1. ATTENTION

Before operating the Monitor please read this manual thoroughly

and retain it for future reference.

For your safety, please do not watch videos on the monitor when

driving. Except professional repair-men, do not modify the machine.

lf the machine doesn‘t work, please consult customer services or send

the machine to local maintenance departments.

Warning: Please install this machine in the place where laws and

regulations allows it, our company take no responsibility for illegal

product installation.

Notice: The machine may appear darkscreen phenomenon when

starting up in the cold days, after power on and machine's temperature

gradually rises up, the display screen would gradually return to normal.

2. PRODUCT FUNCTION AND APPLICATION INTRODUCTION

2-1. PRODUCT FUNCTION

Wireless Monitor

• 7'' -inch LCD Video Display

Monitor

• Digital Wireless Receiver

Built-into Display

• Aspect Ratio: 16:9 Widescreen

• System: PAL/NTSC Auto

Switching

• Anti-Glare Sun Shade

• Universal Stand Mount

• Resolution: 800 x 480 Pixels

• Brightness: 350 cd/m2

• OSD Menu with Front Panel

Button Controls

• Brightness Color Contrast

Adjustable

• 4-Pin Video System Connectivity

Jacks

• DC Reverse 12-24 Volt Trigger

with Auto Activation

• Dimensions: (L x W x H):

7.1'' x 2.9'' x 4.7''

System Features:

• Camera & Monitor Vehicle Safety Video System

• Digital Wireless 2.4Ghz Signal Transmitter & Receiver

• Ability to Connect up to 4 Cameras (2 Wireless 2 Wired)

• Designed for Car/Truck use 12/24 Volt Systems

• Includes All Necessary Cables & Wiring

2-2. PRODUCT APPLICATION

This product adopted high resolution TFT color digital screen and

2.4G digital wireless technologies, which used embedded processor

and embedded operating system, combined several latest technologies

in the IT eld, such as audio and video compression/decompression

technology, special shockprooftechnology. It has no radiation, low

power consumption, icker-free and gorgeous vivid color and could

be easily installed and widely used in various kinds of vehicles.

2-3. PRODUCT INTRODUCTION

A. Front panel introduc

• Monitor Panel Introdu

1. 2.4G Antenna

2. Display Screen

3. Metal LOGO plate

4. Open or Exit the menuMENU:

5. Decrease the screen brightness valueBrightness Decrease:

6. Brightness increase: increase the screen brightness value

7. Power: Under power o state, press shortly to start up, press and

hold to power o; under power on state, press shortly to close the

display screen, press and hold to power o

8. Volume Decrease: Decrease the volume

9. Volume Increase: Increase the volume

10. MODE: Up, down, left, right rotation

11. Remote Control Window

3 4 5 6 7 8 9 1 0 1 1

Wireless Camera

• Includes (1) Rearview Camera

• Digital Wireless Transmitter

Built-into Camera

• Wireless Range: Over 300' Feet

• Weatherproof Marine Grade

Construction

• IP68 Rating Water & Fog Resistant

• LED Lights with IR Night Vision

Illumination

• Low Lux Light Performance

• Image Sensor: SHARP Color 1/4'' CMD

• System: PAL/NTSC Auto Switching

• Video Output 1.0V pp-75 Ohm

• Lens Angle: 170 Degree

• Min. Illumination: 0.2 Lux

• Auto Image Adjustment

• Camera Dimensions (W x H x D):

3.18" x 2.95" x 2.17"

• Size: 86.5mm*14.5mm*17mm
