Side 1/3

Installation
1. Connect the telephone handset cord to the handset jack
2. Connect the telephone line cord to the line cord jack
3. Connect the other telephone line cord to the telephone wall socket
4. Adjust the desired level (L/H) of the ringer signal with the switch on the under side
of the telephone (see pictures below)
Owners Manual
PRT15I
PRT25I
PRT55I
PRT15I PRT25I PRT55I

How To Use
1. Tone/Pulse switch
On the bottom of telephone base is the P/T switchable dialer. If you have touch tone
service then slide the switch to the T(Tone)position; if you have rotary dial service
then slide the switch to the P(Pulse) position.
2.Making and Answering Calls
To get a dial tone or answer an incoming call, lift the handset. To hang up, either
replace the handset or simply press the HANDSET CRADLE.
--Receive landline calls
When the landline number called, the telephone indicator will blink with a RED light;
pick up the handset to receive the incoming calls directly.
If the indicator color is BLUE, pick up handset then press SWITCH to receive the
incoming calls.
--Receive mobile phone calls
Connect your mobile phone to the vintage phone using the 3.5mm auxillary cable.
When mobile phone called, if the indicator color is BLUE, pick up the handset to
receive the incoming calls directly; if the indicator color is RED, pick up handset and
press SWITCH to transfer landline to mobile phone, then press “ ” button to
receive incoming calls.
3. Ringer H/L switch
You can choose the loudness of the ringing of the phone by the ringer switch located
on the bottom of telephone base to either H (High)or L(Low)position
4. Last Number Redial(REDIAL)
The feature may be used to speed dial the last number dialed. Simply pick up the
handset listen for dial tone and then momentarily press the REDIAL button, the last
number dialed will dial out automatically.
5. Flash Function(
(
(
(( )
)
)
))F
If you get a busy tone after entering the number, press the FLASH butoon first, after
hearing the dial tone, institute a dial tone for another call.
Press the FLASH button to terminate a call, and institute a dial tone for another call to
getting another call from call waiting.
6.VOL-&VOL+
When the phone connected with mobile phone,VOL- and VOL+ switch located on the
bottom of telephone base can adjust the volume of the mobile phone receiver
earphone.
Produkt Specifikationer
Mærke: | Pyle |
Kategori: | Telefon |
Model: | PRT55I |
Type: | Analog telefon |
Vægt: | 1900 g |
Brugervejledning: | Ja |
Produktfarve: | Kobberfarve |
Indbygget skærm: | Ingen |
Volumenkontrol: | Digital |
Kabler inkluderet: | Lyd (3,5 mm) |
Håndsæt, type: | Forbundet håndsæt |
Telefonsvarer: | Ingen |
Kapacitet for telefonbog: | 0 entries |
Nummervisning: | Ingen |
LED-indikatorer: | Ja |
Monteringstype: | Skrivebord |
Genopkald: | Ja |
Antal håndsæt inkluderet: | 1 |
Samtaleanlæg: | Ingen |
Ældre telefon: | Ja |
LED på base: | Ja |
Analog linjekabel: | Ja |
