Side 1/9
TD-000515-01-D
*TD-000515-01*
Digital Processor Monitor
User Manual
DPM 100 | DPM 100H | DPM 300 | DPM 300H
®
2
TD-000515-01-D
Introduction
QSC’s DPM is a powerful solution for today’s D-Cinema audio systems. From server to speakers, the DPM offers a complete set of tools to facilitate all
the signal processing, audio distribution, monitoring and automation control services required in a modern D-Cinema sound system.
The DPM builds on the legacy of QSC’s DCM and DCP products to provide all signal processing and monitoring functions for Digital Cinema in a
single integrated system. Designed to be used with QSC’s Digital Cinema Amplifiers (DCA) and featuring advanced Intrinsic Correction™ settings for
QSC’s Digital Cinema Speakers (DCS), the DPM optimizes loudspeaker performance while simplifying cinema sound system wiring and configuration.
The DPM 100 and DPM 100H are configurable for passive and bi-amp operation. The DPM 300 and 300H are also configurable for tri-amp and
quad-amp operation. Though optimized to receive audio content directly from a D-Cinema server, the DPM is also compatible with all analog cinema
processor formats and features an 8 channel analog input for integration with 35 mm audio systems.
The DPM is more than an audio processor. Whether designing a system for a single auditorium or designing a large multiplex, the DPM offers the
flexibility in configuration, networking, audio distribution and advanced management services to get the job done.
Features
• Digital inputs accept AES-3 audio from a D-Cinema server or other digital audio source
• Analog inputs accept audio from film processors or other 8 channel analog audio sources
• Additional analog inputs accommodate non-sync and Mic/Line sources
• Additional digital inputs include HDMI® (DPM 100H and DPM 300H only) and SPDIF
• The DPM 100H and DPM 300H include Dolby Audio™ (featuring Dolby Digital Plus™) and DTS-HD® decoding.
• QSC Intrinsic Correction settings for optimal performance of QSC cinema speakers
• Master volume and full cinema processor EQ on all channels
• Booth monitor with front panel control for easy operation
• Passive or 2-way crossovers for three screen channels (all models)
• 3-way or 4-way crossovers for three screen channels (DPM 300 and 300H only)
• Compatible with all existing QSC DCA amplifiers
• Bypass mode – routes audio around failed components to ensure that the show will go on.
• Control and monitoring via Ethernet including full SNMP support
• Continued development of software and firmware will add new capabilities via easy updates
Package Contents
1. DPM 100, DPM 100H, DPM 300 or
DPM 300H
2. User Guide TD-000515
3. IEC power cord
4. Euro style connector plug kit
5. Limited Warranty TD-000453-01
Rack Mounting
The DPM is designed to be mounted in a standard 19" (480 mm) equipment rack and requires 2 vertical rack spaces. Mount the DPM using four
screws and washers. Tighten securely. The DPM comes with rear rack support ears. Make sure that the rear mounting points are securely fastened to
rear rack rails or rack side walls.
Warranty
For a copy of the QSC Limited Warranty, visit the QSC website at www.qsc.com
Para una copia de la Garantía Limitada de QSC, visite el sitio web de QSC, en www.qsc.com
Pour obtenir une copie de la garantie limitée de QSC, visitez le site de QSC à www.qsc.com
Eine Kopie der beschränkten QSC-Garantie finden Sie auf der QSC Webseite unter www.qsc.com.
如果您想要 有限保修的複印本，请造访 音频产品的网站QSC QSC www.qsc.com
Для получения копии ограниченной гарантии QSC посетите веб-сайт QSC Audio Products, расположенный по адресу www.qsc.com.
www.qsc.com    QSC 


    QSC      
