Side 1/3
Note
Product operation guide and download info, please find the Download Index file
stored in the memory of BL-818GT and you can read or install accordingly under
internet connection.
Note
Do not stick anything on
back cover.
Risk of explosion if Battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
G-Sensor button:
Press & hold 1 second to calibrate G-sensor.
Charging the BL-818GT
BL-818GT Function buttons Acquiring Satellite Signal
Update firmware
Please make sure you have everything included in the package.
Please FULLY charge the BL-818GT for the first time use by connecting the
supplied Micro USB cable through computer or car’s cigarette adaptor.
Power button: Press and hold to power on/off.
󴏎 Download and extract the firmware from Qstarz web site
http://racing.qstarz.com/Download.html
➁ Power off BL-818GT and connect with computer via Micro USB cable.
➂ Copy the firmware file FW.qst to the root directory of BL-818GT
internal memory.
➃ Unplug the Micro USB cable, and firmware update will begin
automatically. LEDs will light on alternately during the update
process.
➄ Once firmware update is completed, the device will turn off
automatically.
󴏎Remove the back cover by pushing the battery cover release tab with
your thumbnail.
➁Insert the battery, and align the battery contacts with the terminals in
the battery compartment.
➂Place the back cover over the battery compartment, and press it
downward until it clicks into place.
Note
Connect your BL-818GT device with Computer, and browse the root directory of
BL-818GT in My Computer. Find the “DownloadIndex_BL-818GT.html” file and click
it with internet connection. A download webpage will pop-up, then click on the
link and you can have latest product information for BL-818GT.
Hold on Power button to power on BL-818GT.
Place the device outside under clear view of sky to acquire GPS
signals.
Acquiring GPS signals may take few minutes. The GPS LED is turning
to solid green when it has connected with GPS satellites.
Device Charging and Updating firmware.
Shut down the device. (Inside the rubber cover)
BL-818GT unit
Low Power
Recharging
Device power off
GPS position is fixed
Searching for device
Bluetooth connected
GPS is not connected with satellite
1. Fully charged.
2. Device power off
1. Searching for GPS satellite signal
2. Device power off
1. GPS position is fixed
2. Device power off
Note
Before exporting the data to computer please turn off the power.
GNSS Support
Picture Screen might be slightly varied according to different APP
version. For detail operation, please refer to the operating guide on
manual of QRacing APP.
A 10Hz BLE GPS Receiver and provide real time lap timing via
QRacing APP
Adopt high sensitivity GNSS chip and 3-axis accelerometer
Bluetooth 4.0 enabled device
Update rate up to 10Hz excellent for High speed racing (updating
every 0.1 second)
G-Sensor button design to calibrate G-sensor immediately
5 LED indications to view device status
Case: Rugged, without water-resistant
Power Supply: Rechargeable Lithium-Ion battery, 20 hours
operation (typical use)
Temperature: Operating -10~60 / Charging 0~45 / Storage ℃ ℃
-20~60℃
Please take out the battery and store it in dry/cool places when
not use for a long period.
If the device isn’t used in temperature between -10 ~ 60 , its ℃ ℃
battery charging capability will decrease.
Leave the device far from heat or high temperature
environment. And also, do not expose your device in
temperature higher than 145 /60 to prevent the inside ℉ ℃
battery from overheating, exploding or burning itself. The
Lithium battery inside the device should be recycled.
Do not attempt to dismantle the device by yourself.
Unauthorized hacking may damage the unit, and void your
warranty.
GPS LED
2 short beeps
EN Ver. A 2019.08
Product Specifications
Product Care
QRacing APP
(iOS version / Android version)
Start Racing
Product Compatibility
Please download QRacing APP on App Store or Google Play.
QRacing APP is a racing data analysis APP combining GPS data with
video overlay support. Read the operating guide on the manual of
QRacing APP.
BL-818GT is compatible with most iOS and Android devices via the
Qstarz BLE GPS View App. Expect for no brand and newest devices.
*Download the Qstarz BLE GPS View APP on App Store or Google Play
Store.
➁ Confirm GPS position is fixed View Analysis Data on your QRacing APP➆
➂ Turn on your mobile device’s Bluetooth feature
-iPhone Setting > General > Bluetooth > On
-Android phone Settings > Wireless & Networks > Bluetooth: On
➃ Start QRacing APP on your mobile phone
➄ Register a new account. Login and add your BL-818GT
in Setting Page of QRacing APP
➅ Start to real-time Racing
QRacing
* The mobile phone photo is illustrated by iPhone. The support OS and
versions for QRacing APP, please refer to the description on Qstarz
website.
Press Power button
2 seconds.
Switch On BL-818GT
