100.615 User Manual UK

Effect: Portable Bluetooth Party Speaker

Item ref: 100.615UK

User Manual

Take the party with you wherever you go, with a portable Bluetooth speaker with colourful LED light show.

Perfect for karaoke kings and queens, simply connect the microphone to showcase your talents and record

sing-alongs with the voice record function. Play your tunes via Bluetooth from your smart device, use the

inbuilt media ports or even FM radio. This speaker is light enough to be carried by shoulder strap and features

an internal rechargeable battery with up to 3 hours power from a single charge.

• Stylish and rugged design

• Connect to your smart device via Bluetooth

• Wired microphone included for karaoke and voice record functions

• LED colour light effect in grille

• Media player with inbuilt FM/USB/AUX and Microphone ports

• Internal rechargeable battery with up to 3 hours playback

• Ideal for karaoke, house parties, kids' rooms and more

Technical Specificat and Features ions

Speaker

6.5" Driver 10W RMS

Frequency range

70Hz- KHz 18

Impedance

4.0 Ohms

Bluetooth version

5.0+EDR

Bluetooth range

Up to 10m (in clear line of sight)

FM Frequency range

87.5MHz-108MHz

Battery type

3.7V 2200mA internal rechargeable Lithium Ion

Battery life

Up to 3 hours (max volume)

Charge time

3 Hours from flat

Input connections

Bluetooth, USB, AUX (3.5mm), micro USB (DC 5V/1A - charge only)

Dimensions

300 250 x 180 mm (W x H x D) x

Weight

1.65kg

Controls Diagram:

100.615 User Manual UK

Unit Controls and Features:

1. Volume co rolnt : Rotate to increase or lower the master volume.

2. Power/mode button ( ): Long press to power the unit on or off. Short press to switch between

modes (Bluetooth/AUX/FM/Record ).

3. Play/pause button ( ): Long press to turn the LED Light show on off. ort press in BT/or Sh USB

mode to play or pause the current track, in FM mode to perform a channel scan and in record mode to

playback a recording.

4. Next track/station button ( ): Short press to move t the next track in BT/USB mode, or next o

station in FM mode. Long press with the microphone inserted to increase the echo/reverb effect. Short

press in record mode to begin the recording session.

5. Previous track/station button ( ): Short press to mov to the previous track in BT/USB mode, or e

previous station in FM mode. Long press with the microphone inserted to decrease the echo/reverb effect.

Short press in record mode to end the recording session.

6. DC in 5V micro USB port: Use the charging cable sup ied and connect to a compatible USB power pl

source for charging or constant power.

7. USB port: Multimedia playback via a USB flash drive or other compatible USB device.

8. AUX in jack: Use to connect to audio output devices with a compatible 3.5mm lead (not sup ied). pl

9. Microphone jack: Connect the wired microphone sup ied for voice playback or record g.pl in

10. LED charging indicator: Glows red when the unit is connected to a compatible USB power source and in

charging mode. Goes out when fully charged.

11. Reset aperture: Press using a pin or sharp object to reset the unit when required.

Charging the battery:

• Fully charge the Effect s internal battery before first use. Use the USB cable provided and only connect to a ’

suitable 5V USB power supply.

• During charging, the indicator will glow red and go out when the unit is fully charged. LED

Note: If the Effect is used while connected to a USB power source, the indicator will always glow, even

when the unit is fully charged.

Bluetooth Mode:

• Select Bluetooth mode by short p ssing the repeatedly until you hear the relevant re Power/mode button

voice prompt.

• The Effect w automatically enter Bluetooth pairing mode and become discoverable from your smart ill

device.

• Enter the Bluetooth device list on your smart device and search fo and select to pair. r “ ”QTX-Effect

• Your device may ask you for a pairing confirmation or code, enter if prompt . When successful, “ ”0000 ed a

pairing tone can be heard.

• Once paired, the Effect will automatically reconnect to your device when both are in Blue oth mode and to

within 10m of each other.

• You can now also use the unit’s Play/pause, Previous track/statio xt track/station n or Ne buttons

to control the music on your connected smart device.

USB mode:

• The Eff t is fitted with a media player which can play compatible music files from the USB port on the ec

back of the unit.

• Simply insert your USB dia and the unit will automatically enter USB mode and a voice prompt can be me

heard. Alternatively, you can select th USB mode by short pressing the e Power/mode button repeatedly

until you hear the relevant voice prompt.

• You can now play o scroll through the tracks using the r Play/pause Previo track/station , us or Next

track/station buttons on the front of the unit.

• The E ect also has a memory function which means it will contin from the last played track on the last ff ue

album played, on the last occasion it was inserted.
