Side 1/4

100.614 User Manual UK

Effect Aqua Splash-proof Bluetooth Party Speaker :

Item ref: 100.614UK

User Manual

Make waves with the Effect Aqua, the splash resistant party speaker with multicolour LED light show. Perfect

for karaoke kings and queens, simply connect the included microphone to showcase your talents and sing-

along with your favourite tracks. Play your tunes wirelessly via Bluetooth from your smart device, use the

inbuilt media ports or even FM radio. This speaker is light enough to be taken anywhere, even outdoors

thanks to its splash resistance and internal rechargeable battery with up to 6 hours play time from a single

charge.

• Stylish and rugged design with IPX4 splash resistance

• Connect to your smart device via Bluetooth

• Wired microphone included

• LED multicolored light effect in grille

• Media player with inbuilt FM radio, USB, Micro SD/TF and AUX ports

• 6.3mm Microphone and Guitar jack sockets

• Integrated smartphone/tablet holder

• Internal rechargeable battery with up to 6 hours playback

• Ideal for outdoor events, kar ke, house parties, kids' rooms and more ao

Technical Specifications and Features

Speaker

8" Driver 20W RMS

Frequency range

50 - KHz Hz 18

Bluetooth version

5.0+EDR

Bluetooth range

Up to 18m (in clear line of sight)

FM Frequency range

87.5MHz-108MHz

Battery type

7.4 00mA internal rechargeable Lithium Ion V 44

Battery life

Up to 6 hours (max volume)

Charge time

3 Hours from flat

Input connections

Bluetooth, USB, Micro SD/TF AUX (3.5mm), micro USB (DC 5V/2 - charge only) , A

Power input

DC 5V/2A

Dimensions

400 x 290 x 203mm

Weight

3.08 kg

Controls Diagram:

100.614 User Manual UK

Unit Controls and Features:

1. DC in 5V micro USB port: Use the charging cable supplied and connect to a compatible USB power

source for charging or constant power.

2. USB port: Multimedia playback via a USB flash drive or other compatible USB device.

3. Micro SD (TF) slot: Multimedia playback via a compatible Micro SD/TF card (max 64GB)

4. AUX in jack: Use to connect to audio output devices with a compatible 3.5mm lead (not supplied).

5. Micropho /guitar s: ne jack Connect the wired microphone sup ied for constant voice playback or pl

record g; and/or connect a separate guitar for constant playback.in

6. Microphone volume: Rotate to increase or lower the connected microphone volume (Mic-In only).

7. Volume ntrolco : Rotate to increase or lower the master volume.

8. Echo volume: Rotate to increase or lower the echo effect of a connected microphone ic-In onl(M y).

9. Power/mode button ( ): Long press to power the unit on or off. Short press to switch between

modes (Blue h/AUX/FM/Record toot ).

10. EQ button: Press repeatedly to alter the equalizer sound settings; EQ1 EQ2 is normal, is bass boost,

EQ3 is Rock.

11. Bluetooth pairing button ( ) : Press to enter Bluetooth pairing mode to connect with compatible

devices.

12. Track and station control buttons (<>): Short press to move to the previous or next track in BT/USB

mode, or previous/next station in FM radio mode.

13. Play/pause button ( ): Long press to turn the LED Light show on off. ort press in BT/or Sh USB

mode to play or pause the current track or in FM mode to perform a channel scan .

14. LED charging indicator: Glows red when the unit is connected to a compatible USB power source and in

charging mode. Goes out when fully charged.

15. Reset aperture: Press using a pin or sharp object to reset the unit to factory settings when required.

Charging the battery:

• Fully charge the Effect s internal battery before first use. Use the USB cable provided and only connect to a ’

suitable 5V USB power supply.

• During charging, the LED charging indicator (14) will glow red and go out when the unit is fully charged.

Note: If the Effect is used while connected to a USB power source, the indicator will always glow, even

when the unit is fully charged.

Blueto Mode: oth

• Select Bluetooth mode by short pressing the Power/mode button ( ) repeatedly until you hear the relevant 9

voice prompt or alternatively by pressing the Bluetooth Pairing button (11).

• The Effect w enter Bluetooth pairing mode and become discoverable from your smart device. ill

• Enter the Bluetooth device list on your smart device and search for “QTX-Effect Aqua” and select to pair.

• Your device may ask you for a pairing confirmation or code, enter if prompt . When successful, “ ”0000 ed a

pairing tone can be heard.

• Once paired, the Effect will automatically reconnect to your device when both are in Bluetooth mode and

within 18m of each other.

• You can now use the unit Play/pause ( ) and ack control buttons ( ) to control the music on your ’s 13 Tr 12

connected smart device.

USB Micro SD/TF modes: &

• The Effect is fitted with a media player which can pl compatible music files from the USB (ay 2) or

MicroSD/TF port (3) on the top of the unit.

• Simply insert the relevant dia and the unit will automatically enter er USB or Micro SD/TF mode and me eith

a voice prompt can be heard. Alternatively, you can select the relevant mode short pressing the by

Power/mode button ( 9) repeatedly until you hear the relevant voice prompt.

• You can now use the unit Play/pause ( ) and ack control buttons ( ) to control t music on your ’s 13 Tr 12 he

inserted media.
